Step 5: Wire the Voltage and Current Inputs
Voltage Input Specifications
12
Typical Form A Digital Output Use
Select an MOV (metal oxide varistor) or clamping diode that ensures the
output terminals do not receive voltage greater than 350 V peak during
switching.
Connector Type
Wire
Inputs
1
Rated Inputs
Compliance
Overload
Dielectric Withstand
Impedance
Notes
1
Accuracy may be affected if the voltage on V1 falls below 50 V.
Potential Transformers
PTs are required for all systems with voltage levels greater than these above.
The meter inputs can be used with PTs that have secondaries rated between
50 VAC and 347 VAC +25%.
PTs should comply with IEC 61010-1, Pollution Degree 2, Overvoltage
Category III requirements.
Ring or split-ring, or bare wire.
14 to 12 AWG (2.1 mm
V1, V2, V3, V
REF
60 – 400 LN (103.5 – 690 LL) VAC RMS
(three phase)
60 – 400 L-N VAC (single phase)
Installation category III (Distribution).
Pollution degree 2.
1500 VAC RMS continuous
> 3250 VAC RMS, 60 Hz for 1 minute
Ω
> 2 M /phase to ground
2 2
to 3.3 mm )
