Multicast Master - Algo 8180 User Manual

Multicast Master

Multicast Mode
(Master Selected)
Zone Selection
Mode
Master Single Zone
Master Ring Mode
Note: Expanded Zones are only available in Slave mode. The Algo 8301
Paging Adapter & Scheduler, 8186 SIP Horn Speaker, and 8188 SIP
Ceiling Speaker can be used as Master device for Expanded Zones.
If master is enabled the 8180 will broadcast an
IP stream when activated in addition to playing
over its own speaker.
Single Zone always broadcasts on one IP
address. In DTMF mode the IP address
is determined by the zone selected. The
DTMF zones definitions can be found in the
"Advanced Settings > Advanced Multicast" tab.
IP address for multicast broadcast.
If control signal is selected the master 8180
will broadcast a message activating locally
selected WAV files in slave 8180s. If audio
stream is selected, the master 8180 will
broadcast an audio stream using the master's
selected ring tone.
- 20 -
