8507 IP Horn Array Speaker
UG-8507-06102024
Firmware Version 5.5
support@algosolutions.com
Dec 18, 2024
User Guide
Algo Communication Products Ltd.
4500 Beedie Street, Burnaby
V5J 5L2, BC, Canada
1-604-454-3790
www.algosolutions.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8507 and is the answer not in the manual?

Questions and answers

Related Manuals for Algo 8507

Summary of Contents for Algo 8507

  • Page 1 8507 IP Horn Array Speaker User Guide UG-8507-06102024 Algo Communication Products Ltd. Firmware Version 5.5 4500 Beedie Street, Burnaby support@algosolutions.com V5J 5L2, BC, Canada Dec 18, 2024 1-604-454-3790 www.algosolutions.com...

  • Page 2: Table Of Contents

    8507 IP Horn Array Speaker Table of Contents Product Overview ..................................1 Setup and Installation ................................... 1 Getting Started ..................................1 Configuration ..................................2 Mounting....................................2 2.3.1 Install the Array Bracket ............................... 4 2.3.2 Assemble Linkage Arm ..............................5 2.3.3 Install the Mounting Bracket ............................
  • Page 3 8507 IP Horn Array Speaker API ......................................54 InformaCast ................................... 56 Syn-Apps ....................................57 Microsoft Teams ................................... 58 Device Management ................................... 58 ADMP ....................................58 Algo 8300 IP Controller ................................. 59 SNMP..................................... 60 RTCP ...................................... 61 System Configuration .................................. 62 Input/Output ..................................

  • Page 4: Important Warning And Safety Information

    IMPORTANT WARNING AND SAFETY INFORMATION Important Notice The 8507 Horn Array Speaker is AC mains powered. If the power plug is removed for direct connection to a mains supply, the connections should be performed by a qualified electrician according to local building codes.

  • Page 5: Aviso Importante

    Aviso Importante El Parlante 8507 de Arreglo Bocina “8507 Horn Array Speaker” está operado por energía de C.A. Si se retira el enchufe de energía para conexión directa a tomacorriente, un técnico cualificado deberá realizar las conexiones, de acuerdo con las normas de construcción locales.

  • Page 6: Product Overview

    1. Connect the 8507 to a PoE network switch and AC Mains power (optional). The blue LED in the bottom plastic cap will turn on with PoE power until the device boot up is completed. This typically takes about 30 seconds.

  • Page 7: Configuration

    A pole- mounted 8507 can rotate 90-degrees left to right if the pole center is at least 6 inches from a wall. To prevent personal harm, it is essential that: •...
  • Page 8 8507 IP Horn Array Speaker Figure 1. Pieces included with the 8507 Horn Array Speaker. UG-8507-18122024 support@algosolutions.com Page 3...

  • Page 9: Install The Array Bracket

    8507 IP Horn Array Speaker 2.3.1 Install the Array Bracket If no tilt is required, the array bracket may be installed in any position on the array as long as both mounting clips are used. If tilt is required, mount the adapter plate on the bottom of the array as shown below to allow downward tilt from a solid wall by up to 35 degrees.

  • Page 10: Assemble Linkage Arm

    8507 IP Horn Array Speaker 2.3.2 Assemble Linkage Arm For tilt angles of 0, 5, 10, and 15 degrees, the linkage arm is not required. For tilt angles of 20, 25, 30, and 35 degrees, the linkage arm is required and must be pre-installed according to the figure below.

  • Page 11: Install The Mounting Bracket

    Pole Mount (2 3/8” OD Pole) Note that for a full 90-degree rotation, the pole center should be at least 6 inches from any adjacent wall. Figure 5. Parts required to mount the 8507 Horn Array Speaker to a pole. Pole Installation Instructions To pole mount the universal mounting bracket, use the pole-mount bracket kit (8507PMB, not included).
  • Page 12 Figure 6. Parts required to mount the 8507 Horn Array Speaker to a wall. Wood Installation Instructions...
  • Page 13 8507 IP Horn Array Speaker Install the Horn Array Speaker to the Mounting Bracket Figure 7. How to install the Horn Array Speaker to the mounting bracket. UG-8507-18122024 support@algosolutions.com Page 8...

  • Page 14: Wiring

    2.4 Wiring 2.4.1 Ethernet Wiring If the 8507 is installed outdoors or in a wet environment, an outdoor-rated network cable with an LLDPE jacket or equivalent for water and UV protection must be used. To meet IPX9 ingress protection, the wiring shroud must be installed. To do this, the bayonet plug must be assembled, the drain tube must be installed, and the shroud must be attached.

  • Page 15: Shroud Assembly

    1. Slide the drain tube (U) over the drain fitting. The tube must be clear to drain any moisture that accumulates in the 8507 into the shroud. 2. Attach the shroud (R and S). The smaller hole is for the ethernet cable and the larger hole is for the AC cable.

  • Page 16: Ac Electrical Wiring

    After you enter the IP address for your device into your browser, the web interface will appear. You must log in to view device settings. The default password is algo. This password can be changed under Advanced Settings → Admin after logging in. Changing the default password is highly recommended if the device is directly connected to a public network.

  • Page 17: Check Device Status

    8507 IP Horn Array Speaker 2.5.1 Check Device Status By default, the Status page is available with and without a login. The Status page can be made exclusive to logged-in users via Advanced Settings → Admin → General → Show Status Section on Status Page when Logged Out.

  • Page 18: Reset

    A large, round button located between the AC power cable and ethernet jack at the bottom of the device can only be used to reset the 8507 IP Horn Array Speaker at the time of power-up. To return all the settings in the 8507 to the factory default, reboot or power cycle the 8507.

  • Page 19: Basic Settings

    8507 IP Horn Array Speaker 3.1 Basic Settings Figure 9: Configure basic SIP settings in the web interface. Use these SIP settings to enter SIP server information and account credentials. You can ask your system administrator or hosted account provider for more details. After entering the information and saving the settings, check the Status tab to confirm the successful registration.
  • Page 20 (and multicast if configured) until the inbound call stops ringing. The 8507 will not answer the call on this extension. The 8507 can be a member of a hunt group or ring group to ring in conjunction with a telephone.

  • Page 21: More

    8507 IP Horn Array Speaker Display Name (Optional) Enter the name you want displayed when an SIP call is made. For the display name to be shown, the PBX and phone(s) must be configured to display this message as the Caller ID.

  • Page 22: More Ring Extensions

    2. Enter the Extension, Authentication ID, and Authentication Password. You may enter a Display Name if you’d like. The 8507 will auto-answer any inbound calls received on these numbers and provide a voice paging path and multicast if configured. Only a single call can be active at a time.

  • Page 23: Emergency Alerts

    8507 IP Horn Array Speaker Up to 10 SIP Ring extensions can be registered. To configure additional ring extensions, select Enabled beside an extension and enter the Extension, Authentication ID, and Authentication Password. If desired, a unique ringtone and multicast zone can be assigned to each extension.
  • Page 24 8507 IP Horn Array Speaker The 8507 can be used for emergency (e.g., lockdown, evacuation, reverse evacuation), safety (e.g., medical, workplace accident), and security events (e.g., OSHA or similar workplace regulations) alerting. Emergency alerts notify others of an emergency quickly and efficiently. Users can dial a pre-configured extension number to trigger and latch an emergency alert or announcement.
  • Page 25 8507 IP Horn Array Speaker Default Maximum Select the maximum time an announcement can be played. Announcement Time Announcement Selection Select Direct Extensions to register a separate extension for each Mode announcement. Select DTMF Selectable to register a single extension that accepts DTMF input to select which announcement to play.
  • Page 26 8507 IP Horn Array Speaker DTMF Selection Extension Enter the SIP extension for the DTMF Selection parameter. Authentication ID Enter the Authentication ID. It may also be called Username for some SIP servers or may be the same as the extension.
  • Page 27 8507 IP Horn Array Speaker Call-to-Cancel If using “DTMF 0”, the user should dial the main DTMF Selection extension and Call-to-Cancel select ‘0’ to cancel the announcement. Selection Mode Extension Enter the SIP extension for the Call-to-Cancel Selection parameter. Authentication ID Enter the Authentication ID provided by the System Administrator.
  • Page 28 8507 IP Horn Array Speaker Announcements Announcement # To configure an Emergency Alert extension, select Enabled for an announcement number. Up to 10 extensions can be registered allowing up to 10 different announcements. Audio files can be easily uploaded to create custom announcements.

  • Page 29: Advanced Sip

    8507 IP Horn Array Speaker 3.5 Advanced SIP Figure 12: Configure Advanced SIP settings in the web interface. UG-8507-18122024 support@algosolutions.com Page 24...
  • Page 30 8507 IP Horn Array Speaker General SIP Transportation Select a transport layer protocol to use for SIP messages from the dropdown. These options include: • Auto: Will check the DNS NAPTR record, then try UDP/TCP. • • • TLS: Ensures the encryption of SIP traffic. In this mode, if the SIP...
  • Page 31 8507 IP Horn Array Speaker Outbound Proxy Enter the IP address for an outbound proxy. Register Period (seconds) Enter the maximum requested period where the device will re-register with the SIP server. The default setting is 3600 seconds (1 hour).
  • Page 32 8507 IP Horn Array Speaker Media NAT IP address for STUN server if present or IP address/credentials for a TURN server. ICE – TURN Server Enter the IP address or domain of the ICE server. ICE – TURN User Enter the username.
  • Page 33 8507 IP Horn Array Speaker Server Redundancy Server Redundancy Enable to configure up to two secondary backup servers. Feature When enabled, the device will attempt to register with the primary server but switch to a secondary server when necessary. The configuration allows re- registration to the primary server upon availability or to stay with a server until unresponsive.
  • Page 34 8507 IP Horn Array Speaker Interoperability Keep-Alive Method Select a keep-alive method: • None • Double CRLF: The device will send a packet regularly to maintain connection with the SIP Server if behind NAT. Keep-Alive Interval Set the interval in seconds that the CRLF message should be sent. 30 seconds is recommended.

  • Page 35: Multicast Configuration

    The 8507 IP Horn Array Speaker can be programmed as a multicast transmitter or receiver to scale communications in a simple and effective way. IP endpoints connected to the 8507 can be grouped into up to 50 multicast zones and paged via DTMF Selectable Mode or multiple SIP extensions.

  • Page 36: Multicast: Transmitter (Sender)

    8507 IP Horn Array Speaker The page pre-announce tone is generated from the transmitter. The speaker volume can be increased or decreased for each multicast receiver individually. 4.3 Multicast: Transmitter (Sender) Figure 13: Multicast transmitter mode settings. UG-8507-18122024 support@algosolutions.com Page 31...
  • Page 37 Multicast Type group paging” protocol and most multicast-enabled phones that use RTP audio packets. Select Regular (RTP) if you are only multicasting to Algo IP endpoints or multicast-enabled phones. To multicast page announcements to Poly phones, select Poly Group Page or Poly Push-to-Talk.
  • Page 38 8507 IP Horn Array Speaker Poly Group Paging/Push-to-Talk This section is used if the Multicast Type includes Poly Group Page or Poly Push-to-Talk. Poly Zone Enter the same Multicast IP Address and Port number configured on the Poly phones. Poly Group Selection Mode Select Single Group to broadcast on one pre-configured group.
  • Page 39 8507 IP Horn Array Speaker • DTMF Extension *10 for Zone 10 • DTMF Extension *11 for Zone 11 All DTMF codes and respective zones are available in Advanced Settings → Advanced Multicast. Poly Default Channel Select the default group for the multicast stream to be sent to. If...
  • Page 40 8507 IP Horn Array Speaker Transmitter (Sender) Zone Settings This section is used if the Multicast Type includes Regular (RTP). Zone Selection Mode Select Single Zone to broadcast on one pre-configured zone. Multiple SIP extensions can be registered on the Transmitter device. Each extension is mapped to a unique zone, allowing zones to be called directly (e.g., from speed-...
  • Page 41 8507 IP Horn Array Speaker All DTMF codes and respective zones are available in Advanced Settings → Advanced Multicast. Transmitter Single Select the default zone for the multicast stream to be sent to. If DTMF Selectable Zone Zone is chosen, this single zone setting will not apply to Paging since the zone will be dynamically selected per call using DTMF.

  • Page 42: Multicast: Receiver (Listener)

    8507 IP Horn Array Speaker 4.4 Multicast: Receiver (Listener) Figure 14: Multicast receiver mode settings. UG-8507-18122024 support@algosolutions.com Page 37...
  • Page 43 This can be set via Basic Settings → Features → Page Speaker Volume. Multicast Type Select Regular if receiving multicast from other Algo IP endpoint(s) and/or multicast- enabled phone(s) that use RTP audio packets. Select Poly Group Page or Poly Push-to-Talk if receiving multicast paging compatible with Poly “on-premise group paging”...
  • Page 44 8507 IP Horn Array Speaker Receiver (Listener) Zone Settings Basic Receiver Zones Select one or more multicast zones for the device to listen to. Multicast zone priority will be based on the zone definition list order defined in Advanced Settings → Advanced Multicast.
  • Page 45 8507 IP Horn Array Speaker Poly Group Paging/Push-to-Talk Poly Zone Enter the Poly Zone (IP Address and Port) that matches the configuration of the Poly phones and Channels. Poly Receiver If using a Poly telephone as a Multicast Transmitter, a tone may be set for any of Channels the 25 Poly Groups configured on the device.

  • Page 46: Using Multicast

    8507 IP Horn Array Speaker 4.5 Using Multicast Page Zones The 8507 IP Horn Array Speaker can listen to up to 50 paging zones (See Additional Features → More Page Extensions for more details). The multicast IP addresses define these zones.

  • Page 47: Advanced Multicast

    8507 IP Horn Array Speaker 4.6 Advanced Multicast These settings are only visible when in Transmitter or Receiver multicast mode. This can be set in Basic Settings → Multicast. The default pre-populated multicast zone IP addresses and ports will work in most cases and should only be altered for rare cases.
  • Page 48 8507 IP Horn Array Speaker Transmitter Settings Transmitter Output Select an audio encoding format for the Transmitter device to use when sending Codec output to the Receivers. Supported formats include: • G.711 ulaw • G.722 • Opus Only G.711 and G.722 are supported when using Two-Way Paging mode.
  • Page 49 8507 IP Horn Array Speaker RTP Control Protocol (RTCP) RTCP Port Selection Select how a port will be chosen to send or receive RTCP packets. Note: If Next Higher Port is selected, ensure that the default multicast zone definitions are modified so that zones are only assigned to even-numbered ports, leaving the next higher odd-numbered ports free for RTCP packets.

  • Page 50: Audio Configuration

    Algo devices already multicast a tone by default. AUDIO CONFIGURATION In addition to voice paging, the 8507 IP Horn Array Speaker can play audio files for notifications such as emergency alerts, safety and security announcements, or shift changes. Audio files can be stored on the speaker and played in response to an event such as a ring, relay input, or automated schedule.

  • Page 51: Basic Audio Settings

    8507 IP Horn Array Speaker 5.1 Basic Audio Settings → Figure 16: Basic Settings Features. UG-8507-18122024 support@algosolutions.com Page 46...
  • Page 52 8507 IP Horn Array Speaker Inbound Ring Settings Ring settings apply to events triggered by Ring Extensions and Emergency Alerts. Emergency Alert tones are configured under Additional Features → Emergency Alerts. Ring/Alert Select an audio file to play when a ring event is detected on the SIP Ring Extension. Test Tone the audio file immediately using the Play, Loop, and Stop buttons.
  • Page 53 8507 IP Horn Array Speaker Inbound Page Settings Page Speaker Volume This setting is for gain control for SIP or multicast paging. The output level will depend on the streaming level. Page Speaker Volume will apply to all inbound multicast streams (for Receiver mode only) regardless of audio source or type.
  • Page 54 8507 IP Horn Array Speaker Page Timeout Set the maximum duration for a page. The page will end when the timeout limit has been reached. This is useful to ensure the paging system is not stuck in an active state in cases where someone accidentally forgets to hang up.

  • Page 55: Tones

    5.2 Tones The 8507 includes several pre-loaded audio files that can be selected to play for various events. The web interface allows you to select a file and play it immediately over the speaker for testing, which is available in Basic Settings →...
  • Page 56 8507 IP Horn Array Speaker Files Download and Install Ring Tones from Tone files can be downloaded manually from the Algo website. the Algo Server Cache Rebuild Tone Cache Files Only needed when the tone cache is out of sync. The operation might take a long time, depending on the types and sizes of the tone files.

  • Page 57: Advanced Audio

    8507 IP Horn Array Speaker 5.3 Advanced Audio Figure 18: Configure advanced audio settings in the web interface. UG-8507-18122024 support@algosolutions.com Page 52...
  • Page 58 8507 IP Horn Array Speaker Functions Dynamic Range Compression Enable to compress the dynamic range of page audio to increase (DRC) loudness. Dynamic Range Compression Select the amount of compression gain from the dropdown menu. More Gain gain increases distortion.

  • Page 59: Integration

    Requesting systems can interact with Algo devices through a uniform and predefined set of stateless Algo RESTful API Guide operations. See the for more details. To configure API settings on your 8507 IP Horn Array Speaker, use the web interface and navigate to Advanced Settings → Admin → API Support. UG-8507-18122024 support@algosolutions.com...
  • Page 60 8507 IP Horn Array Speaker API Support RESTful API Enable a secure API for remote access and device control via HTTP. For more information, see the Algo RESTful API Guide. Authentication Method Speak to your IT Administrator for more information.

  • Page 61: Informacast

    HTTP GET requests. 6.2 InformaCast As a Singlewire Solutions Partner, Algo products have been certified for compatibility and interoperability. To set up your device with Informacast, use the web interface and navigate to Advanced Settings → Admin →...

  • Page 62: Syn-Apps

    8507 IP Horn Array Speaker 6.3 Syn-Apps As a Syn-Apps Partner, Algo products have been Syn-Apps Certified for compatibility and interoperability. Syn-Apps The SA-Announce feature cannot be used when Multicast Transmitter mode or Poly mode is enabled. To enable SA-Announce mode, set Multicast Mode to None in Basic Settings → Multicast.

  • Page 63: Microsoft Teams

    To connect your device to your ADMP account, use the web interface and navigate to Advanced Settings → Admin → ADMP Cloud Monitoring. Note that if you choose to use ADMP to manage your devices, the Algo 8300 IP Controller cannot be used at the same time.

  • Page 64: Algo 8300 Ip Controller

    Any Algo SIP endpoint device, including the 8507, can be monitored on the network via the 8300 dashboard. Note that if you choose to use the Algo 8300 IP Controller to manage your devices, ADMP cannot be used at the same time.

  • Page 65: Snmp

    8507 IP Horn Array Speaker 7.3 SNMP Simple Network Management Protocol (SNMP) can be used to monitor and manage the 8507. To configure your SNMP settings, use the web interface and navigate to Advanced Settings → Admin → Simple Network Management Protocol.

  • Page 66: Rtcp

    8507 IP Horn Array Speaker 7.4 RTCP Real-Time Transport Control Protocol (RTCP) can be used to monitor data delivery on the 8507. To configure your RTCP settings, use the web interface and navigate to Advanced Settings → Admin → RTP Control Protocol (RTCP).

  • Page 67: System Configuration

    8507 IP Horn Array Speaker SYSTEM CONFIGURATION 8.1 Input/Output Output Output Light Enable or disable the backlight on the button. If disabled, the light remains off even when the speaker is active. Heartbeat Light Enable this feature to have the blue light flash every 30 seconds. This is used to indicate that the speaker is powered and running.

  • Page 68: Network Settings

    8507 IP Horn Array Speaker 8.2 Network Settings Figure 19: Configure network settings in the web interface. UG-8507-18122024 support@algosolutions.com Page 63...
  • Page 69 8507 IP Horn Array Speaker Common Internet Protocol Use the dropdown to select IPv4 Only or IPv4 and IPv6. If IPv6 is also configured, it will have to be set up via DHCP or statically, similarly to the IPv4. DNS Servers Add one or multiple DNS servers when Supersede DNS provided by DHCP is enabled.
  • Page 70 8507 IP Horn Array Speaker IPv6 IPv6 Method The device can be set to a static or DHCP IP address. DHCP is an IP standard designed to simplify the administration of IP addresses. When selected, DHCP will automatically configure IP addresses for each device on the network.
  • Page 71 8507 IP Horn Array Speaker ICMPv6 Options Destination Unreachable messages Enable to restrict traffic by filtering ICMPv6 packets. Neighbor Discovery Redirect Enable to restrict traffic by filtering ICMPv6 packets. messages Anycast Echo Replies Enable to restrict traffic by filtering ICMPv6 packets.
  • Page 72 8507 IP Horn Array Speaker 802.1Q Virtual LAN If set, the speaker can be accessed by dialing its assigned extension from a telephone, device, or client. The speaker will auto-answer, play the default pre-announce tone, and allow voice paging until disconnected.
  • Page 73 8507 IP Horn Array Speaker 802.1X Port-based Network Access Control 802.1x Authentication Enable to add credentials to access LAN or WLAN that have 802.1X network access control (NAC). You can ask your IT Administrator for this information Authentication Mode Select the desired authentication mode.
  • Page 74 8507 IP Horn Array Speaker Differentiated Services Differentiated Services provide quality of service if the DSCP protocol is supported on your network. Differentiated Services can be specified independently for SIP control packets and RTP and RTCP audio packets. SIP (6-bit DSCP value) Enter the DSCP value for SIP packets.

  • Page 75: Admin

    8507 IP Horn Array Speaker 8.3 Admin Figure 20: Configure admin settings in the web interface. UG-8507-18122024 support@algosolutions.com Page 70...
  • Page 76 8507 IP Horn Array Speaker Admin Password Use this section to change the admin password for logging into your 8507 web interface. It’s recommended that you change the admin password from the default to secure the device on your network.
  • Page 77 8507 IP Horn Array Speaker General Device Name (Hostname) Algo Network Device Add a name to identify the device in the Locator Tool. Introduction Section on Status Page Turn On to show the introduction text on the login screen. Show Status Section on Status Page...
  • Page 78 8507 IP Horn Array Speaker Log Settings Log Level This setting should only be used after consulting with the Algo support team. Log Method Select a Log Method: • Local: The log file is saved in RAM on the device.
  • Page 79 8507 IP Horn Array Speaker Management Web Interface Protocol HTTPS is always enabled on the device. HTTP is enabled by default but may be disabled. To do so, select HTTPS Only mode so requests are automatically redirected to HTTPS. Note that no security certificate exists since the device can have any address on the local network.
  • Page 80 8507 IP Horn Array Speaker Simple Network Management Protocol SNMP Support The existing setting will respond to a simple status query for automated supervision. SNMP Community String Speak to your IT Administrator for more information. SNMPv3 Security Speak to your IT Administrator for more information.
  • Page 81 8507 IP Horn Array Speaker API Support RESTful API Enable a secure API for remote access and device control via HTTP. Algo RESTful API Guide. For more information, see the Authentication Method Speak to your IT Administrator for more information.
  • Page 82 8507 IP Horn Array Speaker SCI Support Simple Control Interface (SCI) is a separate control interface for certain applications. Its primary purpose is to support phones that may have programmable keys that can only send out HTTP GET requests. System Integrity...
  • Page 83 8507 IP Horn Array Speaker Syn-Apps The SA-Announce feature cannot be used when Multicast Transmitter mode or Poly mode is enabled. To enable SA-Announce mode, set Multicast Mode to None in Basic Settings → Multicast. SA-Announce Support Enable to convert unicast streams to multicast and deliver them to the target endpoints.
  • Page 84 Microsoft. ADMP Cloud Monitoring Enable ADMP Cloud The Algo Device Management Platform (ADMP) simplifies the process of Monitoring managing, monitoring, and maintaining Algo devices from any location. This feature requires a valid Account ID. To learn more about ADMP and visit the website.

  • Page 85: Time

    8507 IP Horn Array Speaker 8.4 Time Time and date are used for logging. Figure 25: Configure time settings in the web interface. General Timezone Select a time zone for your device to use. NTP Time Servers The device will attempt to use Timer Server 1 and work down the list if one or 1/2/3/4 more of the time servers become unresponsive.

  • Page 86: Provisioning

    8507 IP Horn Array Speaker This time value will be lost at power down or overwritten if a connection to the NTP server is available. Time and date are used for logging purposes and the scheduler feature. Manually Override Manual time and date are intended for testing purposes only. Time will be lost Time upon power down if the NTP server is reachable.
  • Page 87 Algo also offers a ZTP service that is meant to be used as a redirection service to your provisioning server or to configure your device with an Algo Device Management Platform (ADMP) account. ZTP is enabled by default and occurs before any other provisioning step.
  • Page 88 8507 IP Horn Array Speaker Settings Server Method Select a Server Method. • Auto: All three DHCP options (66, 160, 150) will be automatically checked for an active provisioning server • DHCP Option 66 Only: Only DHCP Option 66 will be checked for a provisioning server •...
  • Page 89 TFTP boot server address to the DHCP client to boot from. One of two files can be uploaded on the provisioning server (for access via TFTP, FTP, HTTP, or HTTPS): • Generic (for all Algo 8507 IP Horn Array) algop8507.conf • Specific (for a specific MAC address) algom[MAC].conf...
  • Page 90 8507 IP Horn Array Speaker (HTTP) Auth Password Speak to your IT Administrator for more information. (HTTPS) Validate Server Speak to your IT Administrator for more information. Certificate (HTTPS) Auth User Name Speak to your IT Administrator for more information.
  • Page 91 Since all necessary settings can be included in this file, the 8507 will be ready to work immediately after downloading the configuration file. The MAC address of each 8507 can be found on the back label of the unit.

  • Page 92: Maintenance

    8507 IP Horn Array Speaker 8.6 Maintenance Figure 22: Maintenance settings. Backup/Restore Configuration Download Configuration File Save configuration settings to a text file for backup or to set up a provisioning configuration file. Restore Configuration File Restore settings by uploading a backup file.
  • Page 93 8507 IP Horn Array Speaker Backup/Restore All User Files Download Backup Zip File Download the device configuration settings and the files in File Manager (ex., certificates, licenses, and tones) to a backup ZIP file. Restore from Backup Zip File Restore the device configuration settings and files in File Manager (ex., certificates, licenses, and tones) by uploading a backup zip file.

  • Page 94: Firmware

    8507 IP Horn Array Speaker 8.7 Firmware Figure 23: Configure firmware settings in the web interface. Installed Firmware Product Firmware Displays the current firmware on the device. UG-8507-18122024 support@algosolutions.com Page 89...
  • Page 95 8507 IP Horn Array Speaker Online Upgrade Check for Firmware Updates Click Check to check for the latest firmware. If the firmware is up to date, Latest Firmware will state Firmware up to date. If your firmware is outdated, the new firmware availability will be listed.

  • Page 96: File Manager

    Enabling this option could cause future upgrade issues. If you require downgrading, please contact support@algosolutions.com assistance. 8.8 File Manager The 8507 has 1GB of storage space for additional files. Figure 24: View files in the File Manager tab. UG-8507-18122024 support@algosolutions.com Page 91...
  • Page 97 Folder If you have any challenges with the device and work with the Algo support team to overcome or fix them, the debug folder will be used. The device will generate files containing information about the device and put them in the debug folder.

  • Page 98: System Log

    8507 IP Horn Array Speaker 8.9 System Log System log files are automatically created and can assist with troubleshooting if the device does not behave as expected. Figure 25: Configure system log settings in the web interface. 8.10 Logout Log out of the web interface.

  • Page 99: Specifications

    8507 IP Horn Array Speaker SPECIFICATIONS View 8507 technical specifications. FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
