Algo 8180 User Manual page 29

MD5 Checksum (TFTP Only)
For TFTP only an .md5 checksum file must also be uploaded to the
Provisioning server. This checksum file is used to verify that the .conf file
is transferred correctly without error.
A tool can be found at the website address below to generate this file.
http://www.fourmilab.ch/md5
The application doesn't need an installation. To use the tool, simply unzip
and run the application (md5) from a command prompt. The proper .md5
file will be generated in the same directory.
If using the above tool, be sure to use the "-l" parameter to
generate lower case letters.
Generating a generic configuration file
1. Connect an 8180 on the network
2. Access the 8180 Web Interface Control Panel
3. Configure the 8180 with desired options
4. Click on the System tab and then Maintenance.
5. Click "Backup" to download the current configuration file
6. Save the file settings.txt
7. Rename file settings.txt to algop8180.conf
8. File algop8180.conf can now be uploaded onto the Provisioning
server
For more Algo SIP endpoint provisioning information, see:
www.algosolutions.com/provision
- 29 -
