- Page 1 Refrigerator Freezer User Instruction PC 3122...
- Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user's manual.
-
Page 3: Table Of Contents
CONTENTS PART 1: SAFETY INFORMATION ........................2 PART 2: OVERVIEW ............................6 PART 3: REVERSE DOOR ..........................7 PART 4: INSTALLATION ..........................11 PART 5: DAILY USE ............................13 PART 6: INFORMATION SHEET ........................17 EN - 1 Copyright © 2015, Fast ČR, a. s. 08/2015... -
Page 4: Part 1: Safety Information
PART 1: SAFETY INFORMATION In the interest of your safety and to ensure the correct use, before installing and fi rst using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. -
Page 5: Daily Use
• It is dangerous to alter the specifi cations or modify this product in any way. Any damage to the cord may cause a short circuit, fi re and/or electric shock. • This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, offi ces and other working environments;... -
Page 6: Energy Saving
Installation Important! For electrical connection carefully follow the instructions given in specifi c paragraphs. • Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In that case retain packing. •... - Page 7 Packaging materials The materials with the symbol are recyclable. Dispose the packaging in a suitable collection containers to recycle it. Disposal of the appliance Disconnect the mains plug from the mains socket. Cut off the mains cable and discard it. EN - 5 Copyright ©...
-
Page 8: Part 2: Overview
PART 2: OVERVIEW PART 2: OVERVIEW Thermostat and Light 5. Freezer Drawers Glass Shelves 6. Leveling Feet Crisper Cover 7. Balconies Crisper This illustration is only for hinting, the detail please check your appliance. EN - 6 Copyright © 2015, Fast ČR, a. s. 08/2015... -
Page 9: Part 3: Reverse Door
PART 3: REVERSE DOOR PART 3: REVERSE DOOR Tool required: Philips screwdriver, Flat bladed screwdriver, Hexagonal spanner. • Ensure the unit is unplugged and empty. • To take the door off , it is necessary to tilt the unit backwards. You should rest the unit on something solid so that it will not slip during the door reversing process. - Page 10 Remove the pin with a screwdriver and fl ip the hinge bracket. Then refi t the pin to hinge bracket. Unscrew middle hinge. Then lift lower door and place it on a soft pad to avoid scratch. Move the hinge hole covers from left side to right side. EN - 8 Copyright ©...
- Page 11 Unscrew bottom hinge. Then remove the adjustable feet from both side. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it. Screw Unscrew Refi t the bracket fi tting the bottom hinge pin. Replace both adjustable feet. Transfer the lower door to the property position. EN - 9 Copyright ©...
- Page 12 Make the middle hinge reverse the direction 180°C, then transfer it to the left property position. Make the middle hinge pin in the upper hole of the lower door, then tight the bolts. 10. Place the upper door back on. Ensure the door is aligned horizontally and vertically so that the seal are closed on all sides before fi nally tightening the top hinge.
-
Page 13: Part 4: Installation
PART 4: INSTALLATION Install door external handle (if external handle is present) Rear spacer Screw the rear spacers at the rear of the unit. Screw Space Requirement • Keep enough space of door open. • Keep at least 50 mm gap at two sides. xxxmm xxxmm EN - 11... -
Page 14: Levelling The Unit
Levelling the unit To do this adjust the two levelling feet at front of the unit. If the unit is not level, the doors and magnetic seal alignments will not be covered properly. Positioning Install this appliance at a location where the ambient temperature corresponds to the climate class indicated on the rating plate of the appliance: Climatic class Ambient temperature... -
Page 15: Part 5: Daily Use
PART 5: DAILY USE First use Cleaning the interior Before using the appliance for the fi rst time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand new product, then dry thoroughly. Important! Do not use detergents or abrasive powders, as these will damage the fi nish. -
Page 16: Helpful Hints And Tips
Positioning the door balconies To permit storage of food packages of various sizes, the door balconies can be placed at diff erent heights. To make these adjustments proceed as follows: gradually pull the balcony in the direction of the arrows until it comes free, then reposition as required. -
Page 17: Defrosting Of The Freezer
Cleaning For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly. Caution! The appliance may not be connected to the mains during cleaning. Danger of electrical shock! Before cleaning switch the appliance off and remove the plug from the mains, or switch off or turn out the circuit breaker or fuse. -
Page 18: Troubleshooting
Troubleshooting Caution! Before troubleshooting, disconnect the power supply. Only a qualifi ed electrician of competent person must do the troubleshooting that is not in this manual. Important! There are some sounds during normal use (compressor, refrigerant circulation). Problem Possible cause Solution Temperature regulation knob is set at Set the knob at other number to... -
Page 19: Part 6: Information Sheet
PART 6: INFORMATION SHEET PART 6: INFORMATION SHEET Information Sheet INFORMATION SHEET: Philco Philco brand: Brand Philco Model identifi cation PC 3122 Type of appliance 3) Energy effi ciency class (A... low electricity consumption to G high electricity consumption) Electricity consumption per 365 days 1) kWh... - Page 20 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
