OPERATING INSTRUCTIONS
LCF 100/200/300/400/500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCF 100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Arctiko LCF 100

  • Page 1 OPERATING INSTRUCTIONS LCF 100/200/300/400/500...
  • Page 3: Table Of Contents

    Wiring diagram for LCF 100 / 200 / 300 ....... .
  • Page 4: User Instructions

    USER INSTRUCTIONS Congratulations on your new low temperature freezer. We trust that it will serve you for many years to come. In order to gain optimum benefit from your freezer, please read the following instructions thoroughly and act accordingly. The low-temperature freezers are used for freezing and long-term storing of medical prepara- tions ( vaccines, blood plasm, ect.) and other biological products.
  • Page 5 • If for any reason the appliance is disconnected from the mains, please wait 10 minutes before re- connecting. The electronic starting device needs this time to cool down, before a safe re-start can be made. 5. Before use. • Before use, the interior of the appliance should be cleaned with a mild soap solution, and wiped off with a dry clean cloth.
  • Page 6 10.Defrosting. In order for the freezer to work to its maximum efficiency the cabinet should be defrosted when a approx. 2mm thick ice layer has formed inside the cabinet. The ice layer is easily removed with a plastic or wooden scraper. Never use a sharp metal object which might will cause damage to the inner liner.
  • Page 7 16. Functions. How to see the set point: 1.Press and immediately release the SET key, the display will now show the set point value. 2.Press and immediately release the SET key or wait for 5 seconds to display the probe value again. How to lock and unlock the keyboard 1.Press the up and down keys simultaneously for more than 3.seconds.
  • Page 8: Dixell Xt111C For Lcf Models

    19. LN 2 or LCO 2 back-up On the rear side of the cabinet there is a label and a marking, where it is possible to insert either a temperature probe or a backup LN2 or LCO2 supply. The inner and outer skins are pre-drilled. Back-up inlet IMPORTANT NOTE !!! Do not attempt to drill or in other way make access to...
  • Page 9: General Description

    • In case of failure or faulty operation send the instrument back to the distributor with a detailed description of the fault. • Consider the maximum current which can be applied to each relay (see Technical Data). • Ensure that the wires for probes, loads and the power supply are separated and far enough from each other, without crossing or intertwining.
  • Page 10: Front Panel Commands

    Front panel commands LED2 E.S. LED1 SET: To display and modify target set point; in programming mode it selects a parameter or confirm an operation. TO SWITCH THE INSTRUMENT ON/OFF: If the function is enabled (par. onF=yES), by pressing the SET key for more than 4s the controller is switched OFF.
  • Page 11 TO see THE SETPOINT 1. Push and release the SET key to see the Set point value; 2. To come back to the normal display push again the SET key or wait 10s. TO CHANGE THE SETPOINT 1. Hold pushed the SET key for 3s to change the Set point value; 2.
  • Page 12 HOW TO CHANGE a parameter To change a parameter value operates as follows: 1. Enter the Programming mode 2. Select the required parameter. 3. Press the “SET” key to display its value. 4. Use “UP” or “DOWN” to change its value. 5.
  • Page 13: List Of Parameters

    List of Parameters REGULATION Differential: (-Full Sc. / Full Sc.) Intervention differential for set point. It can be set with positive value or with negative value. The kind of action (direct or inverse) depends on the S1C parameter (in or di). Minimum set point: (Down Sc.÷...
  • Page 14: Probes And Display

    Alarm delay:(0÷999 min) time interval between the detection of an alarm condition and alarm signalling. Delay of alarm at start-up: (0÷23.5h) time interval between the detection of the alarm condition after instrument power on and alarm signalling. Relay status with faulty probe: So1=oFF open; So1=on closed. Status of alarm relay after pushing a key.
  • Page 15: Digital Input

    DIGITAL INPUT Set point change during during the Energy Saving cycle: (Down Sc./Full Sc.) sets the variation of the set point during the Energy Saving cycle. Digital input operating mode: configure the digital input function: c-H = to invert the kind of action: direct - reverse;...
  • Page 16 To obtain an IP65 protection grade use the front panel rubber gasket (mod. RG-C) as shown in figure. The temperature range allowed for correct operation is 0÷60 °C. Avoid places subject to strong vibrations, corrosive gases, excessive dirt or humidity. The same recommendations apply to probes. Let air circulate by the cooling holes.
  • Page 17: Alarm Signals

    Digital input XT110C and XT111C have 1 free contact digital input. It is programmable in 5 different configurations by the “i1F” parameter. invert the kind of action: heatingcooling (I1F = C-H) This function allows to invert the regulation of the controller: from direct to inverse and viceversa. REMOTE ON/OFF (I1F = OFF) This function allows to switch ON and OFF the instrument.
  • Page 18: Connections

    XT111C: the alarm relay status depends on the tbA parameter: with tbA=yES the relay is disabled by pressing any key, with tbA=no the alarm relay remains enabled as long as the alarm lasts. The display signal remains as long as the alarm condition remains.
  • Page 19: Default Setting Values

    Default setting values Name Range °C/°F Set point LS1+US1 0/32 Differential -Full Sc./Full Sc. -1/-2 Minimum set point Down Sc./Set Maximum setpoint Set/Full Sc. Action type output in=Inverse; dir=directed Anti-short cycle delay 0 -250 sec. Minimum time a stage stays switched ON 0 -250 sec.
  • Page 20: Wiring Diagram For Lcf 100 / 200 / 300

    Wiring diagram for LCF 100 / 200 / 300...
  • Page 21: Wiring Diagram For Lcf 400 / 500

    Wiring diagram for LCF 400 / 500...
  • Page 24 WWW.ARCTIKO.COM LAMMEFJORDSVEJ 5 DK-6715 ESBJERG N DENMARK TEL. +45 70 20 03 28 +45 70 20 03 29 INFO@ARCTIKO.COM 50 80 002-01-GB WWW.ARCTIKO.COM...
