- Page 1 IQ/OQ - INSTALLATION AND OPERATIONAL QUALIFICATION LRE 700/1400 & LFE 700/1400...
- Page 2 The Installation and Operational Qualification document defines the minimum test procedures and acceptance criteria to be used to establish that the Arctiko appliance is installed and op- erated according to our specifications. The Installation Qualification is intended to verify that the appliance is delivered in corre- spondence with the ordered appliance and is installed in a correct environment.
-
Page 3: Table Of Contents
Index Basic information ........................3 Signature and device list......................... 4 Installation Qualification ......................5 Documentation verification ......................5 Appliance check points........................5 Environmental verification ......................7 Operational Qualification ......................8 Parameter verification and adjustment..................8 Placement of test probes........................ 9 Temperature mapping........................11 Alarm and temperature recovery verification................13 Deviations to criteria of acceptance (Deviation report)............16 Result of Installation and Operational Qualification............ -
Page 4: Basic Information
1 Basic information Model: _________________________ Serial number: _________________________ Date of qualification (DD/MM/YYYY): _________________________ Qualification carried out by (name): _________________________ Customer: _________________________ Location of the appliance: _________________________ _________________________ _________________________ COMMENTS 3/17 5084132-03... -
Page 5: Signature And Device List
1.1 Signature and device list Each person, who participates in the present IQ/OQ qualification, shall fill out the signature list below in order to establish traceability to the test signatures. All devices used for the execution of the current IQ/OQ shall be noted in below device list. SIGNATURE LIST NAME (CAPITAL LETTERS) JOB TITLE... -
Page 6: Installation Qualification
¨ 2 Installation Qualification The Installation Qualification is intended to verify that the appliance is delivered in corre- spondence with the ordered appliance and is installed in a correct environment. The IQ is concluded if all acceptance criteria are fulfilled. If any deviations are found during the qualification, such must be corrected and thereafter approved. - Page 7 APPLIANCE CHECK POINTS COMMENTS CHECK (√) Packaging & Ensure all packing material has been re- protection mate- moved rial Ensure all protection foil has been removed from the cabinet and display Cabinet Ensure no scratches on exterior cabinet Ensure no scratches on interior cabinet Ensure no cracks on plastic frames Door Ensure the door can open and close...
-
Page 8: Environmental Verification
2.3 Environmental verification Check and verify the following points: ENVIRONMENT COMMENTS CHECK (√) Ambient condi- Ensure by using a thermometer a maximum tions ambient temperature of: +25°C (freezer models) +43°C (refrigerator models) Ensure no direct sunlight on the appliance Ensure that the appliance is not located near heat sources Ensure that the room is well ventilated Surface... -
Page 9: Operational Qualification
3.1 Parameter verification and adjustment DESCRIPTION DEFAULT DEFAULT CHECK/ADJUST THE COMMENTS SETTINGS SETTINGS SET VALUE AND NOTE THE VALUE LRE 700 LFE 700 LRE 1400 LFE 1400 Password (PS)* Set point (St) Control delta / hysteresis (rd) Interval between 6 hrs. -
Page 10: Placement Of Test Probes
3.2 Placement of test probes Prepare the appliance for the Operational Qualification by mounting test probes. Place the test probes inside the appliance as described in below table and as shown in below illustration (see the red arrows). Each test probe must be loaded with a 25 gr. brass block (or equivalent) to ensure precise temperature measurement. - Page 11 LRE/LFE 1400 PROBE LOCATION Probe no. 1 45 cm distance from the top of the interior cabinet (left side of cabinet) Probe no. 2 72 cm distance from the top of the interior cabinet (left side of cabinet) Probe no. 3 45 cm distance from the bottom of the interior cabinet (left side of cabinet) Probe no.
-
Page 12: Temperature Mapping
3.3 Temperature mapping The following section verifies if the appliance operates within the defined maximum tempera- ture deviation and performance limits by performing temperature mapping. Before starting up the appliance, place the test probes inside the appliance like illustrated on the previous page. - Page 13 Verify if calibration of the appliance sensor is re- quired. Temperature of test We recommend to calibrate the appliance sensor if a temperature deviation of more than 0,5°C between Probe (center of appli- ance): the test probe placed in the center of the appliance and the temperature shown on the display is found Display temperature: (customers own quality standards may define other...
-
Page 14: Alarm And Temperature Recovery Verification
3.4 Alarm and temperature recovery verification The following section verifies the alarm functions and the temperature recovery after door open- ings. Before initializing and in between the following tests, allow the appliance to stabilize. OPEN DOOR ALARM, REMOTE ALARM AND TEMPERATURE RECOVERY TEST PROCEDURE RESULT PASSED (YES/NO) - Page 15 Verify the temperature recovery time after door opening by performing the following steps. Time of door opening: Let the appliance stabilize and thereafter open the Start temperature (test door for 1 minute (only one door shall be opened on probe placed in center of 1400 models).
- Page 16 LOW TEMPERATURE ALARM TEST PROCEDURE RESULT PASSED (YES/NO) Verify the function of the low temperature alarm by performing the following steps. Let the appliance stabilize. Note set point: Refrigerators: +4°C Freezers: -20°C AL setting: Note the setting of the AL parameter. Change the set point (parameter St) to the following value: Refrigerators: +10°C...
-
Page 17: Deviations To Criteria Of Acceptance (Deviation Report)
3.5 Deviations to criteria of acceptance If any deviations to the criteria of acceptance are found, the below table shall be filled out to document that a corrective action has been initiated and/or finalized. In case of deviations, which cannot be corrected on site, please contact the distributor of the appliance for support in correction of the deviation(s). -
Page 18: Result Of Installation And Operational Qualification
4 Result of Installation and Operational Qualification PRODUCT INFORMATION Manufacturer Model Serial number RESULT CHECK (√) Passed Failed CHECKED/TESTED BY DATE SIGNATURE AND STAMP VERIFIED BY DATE SIGNATURE AND STAMP 17/17 5084132-03... - Page 19 5084132-03...
