2. Confirm that the far‐end Bluetooth device is powered on and waiting for a connection.
3. In the Available Devices group, click Refresh. A list of detected Bluetooth devices appears.
4. Click the name of the Bluetooth device that you want to use. The name and MAC address appear under
the selected device.
To configure the IP Pipe in TCP/UDP Server mode:
1. In the IP Pipe group, from the Mode drop‐down list, select SERVER.
2. From the Protocol drop‐down list, select the desired protocol, either TCP or UDP.
3. In the Server Port field, type the desired port value in the range 1 to 65535.
4. From the Connection Termination drop‐down list, select a disconnect method for the IP pipe. Options
are:
Always Connected
Sequence A sequence of characters received from the Bluetooth side used to disconnect the IP pipe.
Timeout The IP pipe connection disconnects if the configured timer expires with no data sent or
received.
