Altronix eBridge8E Installation Manual page 9

Eight (8) port eoc receiver with integral poe+ switch

Table of Contents

Fig. 5

0.75"

19.05mm

8.5"

216mm

1.625"

42mm

www.altronix.com

eBridge8E Rack Mount Chassis Mechanical Drawing and Dimensions:

1.625" x 19.125" x 8.5" (42mm x 486mm x 216mm)

19.125"

486mm

17.625"

447.7mm

AC POWER

- 9 -

1Gb

+ BAT –

eBridge8E
