toward the bottom edge (A) of the display assembly to clear the tab on the bottom of the lower-right corner. Then pull
the bezel toward the right side of the display assembly to clear the tab on the side (B) of the lower-right corner.
1
display back cover
2
tabs
7. Repeat
step 6
for the lower-left corner of the bezel. Then use your fingers to release the snaps around the rest of the
bezel and lift it away from the display panel.
