User guide

CALYBOX
Energy manager
6050388
CALYBOX 110 - 1 zone
6050389
CALYBOX 120 - 2 zones
CALYBOX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CALYBOX 110 and is the answer not in the manual?

Questions and answers

Related Manuals for DELTA DORE CALYBOX 110

Summary of Contents for DELTA DORE CALYBOX 110

  • Page 1: User Guide

    6050389 CALYBOX 120 - 2 zones CALYBOX http://pro.deltadore.com DELTA DORE TALCO - Bonnemain - 35270 COMBOURG E-mail : deltadore@deltadore.com Device complying with the requirements of the directives: CEE 89/336 (Electromagnetic compatibility) and CEE 73/23 modified CEE 93/68 (Low voltage safety)
  • Page 2 This unit optimizes the energy management of your radiators, storage heaters, etc.). home: • Comfort or Economy mode programming of the hea- ting for 1 zone (CALYBOX 110) or 2 zones (CALYBOX Pilot Wire Room order Setting on the heat emitter...

  • Page 3: Table Of Contents

    Warnings Contents Description ......6 • Carefully read these instructions prior to use. Automatic mode ......7 •...

  • Page 4: Description

    Description Automatic mode These instructions apply to both CALYBOX 110 and Turn the knob to AUTO CALYBOX 120. CALYBOX 110 follows the programming. Current day Time Current mode Override Modification Room buttons temperature Selector Information button knob position Display in automatic mode Selector CALYBOX 120 follows the programming in both zones.

  • Page 5: Override

    Override Timer mode In automatic mode, override is used to go from This mode is used to select a mode for a given time and for one zone only. Comfort to Economy mode (or conversely) until the Turn the knob to next program change.

  • Page 6: Continuous Mode

    Example: for a departure on 1 March and a return on 10 March, program 9 Current mode days of absence. CALYBOX 110 Automatic operation will resume Modification on 10 March at midnight. of the mode Confirm and start the calendar Room countdown.

  • Page 7: Shutdown Mode

    Shutdown mode Information button During the AUTO, modes, press the i button This mode allows you to shut down your heating sys- repeatedly to find out: tem (in this case, the water heater stays in automatic • total consumption of your installation, mode).

  • Page 8: Time Setting

    Time setting Information button • the program of the current day per zone, Turn the knob to The days flash. Press + or - to change the day, then press OK to confirm and continue on to the next setting. Minutes Days (1 : Monday…...

  • Page 9: Programming

    Example: Comfort from 6:00 to 8:00 and from 17:00 to 23:00 Programming 23:00 00:00 6:00 17:00 00:00 8:00 Turn the knob to PROG The default program is a Comfort period from 6:00 to 23:00. 1. Create your program Programming starts on day 1 at midnight. Press the buttons to create different Economy or Comfort periods...

  • Page 10: Minor 500 Option

    Programming MINOR 500 option: set point settings Check your program This mode is used to modify the Comfort and Economy set points of each probe. Turn the knob to . Press the button repeatedly to check the accuracy of the Comfort and Economy periods you created. Setting (5 to 30°C) of the Comfort point (19°C by default) for the probe 1 of zone 1.

  • Page 11: Tempo Tariff

    Tempo tariff Troubleshooting If you are on the tempo tariff, you can program specific The purpose of this section is to help you quickly solve modes for peak or off-peak days according to the confi- the most common problems that you may encounter guration made during installation.

  • Page 12: Troubleshooting

    The unit displays HEAT Troubleshooting Your underfloor heating or radiant ceiling heating system is in “gradual heating” mode. symbol and flash. If you want to know the number of days remaining, press the i You are in tariff reduction mode. button.
