Vent free gas fireplace
Hide thumbs Also See for C38-VF:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operation & Installation Manual
Questions? Email us at fireplaces@montigo.com or visit our website at www.montigo.com.
Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
WARNING:
If the information in this manual is not
following exactly, a fire or explosion may
result causing property damage, personal
injury, or loss of life.
What To Do If You Smell Gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
FOR YOUR SAFETY:
Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
Installation
Operation &
Maintenance
C38-VF
Vent Free
Gas Fireplace
This is an unvented gas-fired heater.
It uses air (oxygen) from the room
in which it is installed. Provisions for
adequate combustion and
ventilation air must be provided.
Refer to page 3.
Check local codes
■
and
read
instructions prior to
installation.
Leave this manual
■
with the owner.
all

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C38-VF and is the answer not in the manual?

Questions and answers

Related Manuals for Montigo C38-VF

Summary of Contents for Montigo C38-VF

  • Page 1 Questions? Email us at fireplaces@montigo.com or visit our website at www.montigo.com. Installation Operation & Maintenance Installation and service must be performed by a qualified installer, service agency, or the gas supplier. C38-VF Vent Free Gas Fireplace This is an unvented gas-fired heater.

  • Page 2: Table Of Contents

    The C38-VF includes a 32,000 BTU dual burner and 1 piece ceramic Safety, as well as efficiency of operation, must be considered when fibre logset. The C38-VF is rated for Natural Gas at 32,000 BTU/H Input selecting the fireplace location. Try to select a location that does not or Propane at 32,000 BTU/H Input.

  • Page 3: Installation

    C38-VF Gas Fireplace Installation Clearances Framing These clearances apply to all dimensions except the framed opening, where the clearance to combustibles is 0". The C38-VF clearances to combustible materials are: 5" * When sheetrock is Back 0" not used behind the...

  • Page 4: Installing The Gasline

    Installation Installing The Gas Line WARNING: The gas line must be installed before finishing the C38-VF Fireplace. If the area in which the heater may be operated is smaller Natural Gas requires a minimum inlet gas supply pressure of 5.5"...

  • Page 5: Finishing Around The Fireplace

    C38-VF Gas Fireplace Installation Finishing Around the Fireplace Combustible mantels and mouldings may be safely installed over the top Association, when painting the fireplace surrounds, to select and apply a quality Alkyd sealer prior to the applying of latex paints. This is to and on the front of the fireplace provided that they do not project beyond shaded area shown in Figure 7a.

  • Page 6: Removing And Installing The Door

    Part A down completely. Installing the Logset Installing the Logs: The C38-VF is supplied with a single-piece,moulded design, fibre logset. The logset is very fragile and must be handled very carefully. 1. Remove the door as shown in Figures 8a-8c.

  • Page 7: Lighting Instructions

    C38-VF Gas Fireplace Operating Instructions For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lit by hand.

  • Page 8: Maintenance

    Doors and logs can get very hot. Handle only when cool. The C38-VF is equipped with an adjustable burner, allowing you to raise or lower the flames. To adjust the flames, locate the black knob General marked 'Hi-Lo', in the centre of the gas control valve (See Figure 10).

  • Page 9: Wiring For The Optional Fan Kit

    C38-VF Gas Fireplace Maintenance Wiring for the optional Fan Kit Gas Control Valve All C38-VF fireplaces may be equipped with an optional fan kit (Part no. Power Generator RFK1002 or RFK1003)for circulating heat into the living space.Kits are available with manual or heat-activated control.

  • Page 10: Warranty

    In order for any claim under this Warranty to be valid, Montigo DelRay Corp. must be notified of the claimed defect in writing or by telephone, as soon as reasonably possible after the defect is discovered. Claims against this Warranty in writing should include the date of installation, and a description of the defect.
  • Page 11 C38-VF Gas Fireplace Notes Part No. XG0317 Page 11...
  • Page 12 Installed and Serviced by: XG0317 Rev. 0 - 9/2002 Montigo Del Ray Corp. 6955 Salashan Parkway 27342 Gloucester Way, Ferndale, WA 98248 Langley, BC...
