B-Series DV-2 Gas Fireplace
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to this manual. For assistance or additional
information consult a qualified installer, service agency or the gas supplier.
Safety Notice:
Glass doors on gas fireplaces are extremely hot while the fireplace is on and remain
hot even after the fireplace has been turned off. Safety screens are available and
can reduce the risks of severe burns. Please keep children away from the fireplace
at all times.
For Your Safety:
Do not store or use gasoline or other flammable vapors and liquids in the
vicinity of this or any other appliance.
XG0160
Canadian Heating Products Inc. Langley, BC V4W 4A
Installation Operation & Maintenance Manual
Check local codes and read all instructions prior to installation.
B34DV2 Black Trim Shown
®
C
US
www.montigo.com
B34DV
B38DV
Warning:
mation in these instructions is not
followed exactly, a fire or explosion
may result causing property dam-
age, personal injury or death.
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical
switch; do not use any phone in
your building.
•
Immediately call your gas
supplier from a neighbor's
phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas
supplier, call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Montigo Del Ray Corp. Ferndale, WA 98248
Indoor
Indoor
If the infor-
•
Installer: Leave this manual
with the appliance.
•
Consumer: Retain this
manual for future reference.
080410
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Montigo B34DV
Summary of Contents for Montigo B34DV
-
Page 1: Safety Notice
• Installer: Leave this manual with the appliance. • Consumer: Retain this ® manual for future reference. XG0160 Canadian Heating Products Inc. Langley, BC V4W 4A Montigo Del Ray Corp. Ferndale, WA 98248 080410... -
Page 2: Table Of Contents
Installation, Your new Montigo gas fireplace will give you years of durable, Operations and Maintenance manual. Pay special attention to all reliable use. Welcome to the Montigo family of gas fireplace cautions, warnings, and Important warnings. -
Page 3: Introduction
Standard Log Set This manual covers all models and unless otherwise specified, the The B34DV-2 is rated for Natural Gas at 18,000 BTU/H (5.28 designation B-Series DV-2 refers to all models. Sections which are Kilowatts) Input or Propane at 18,000 BTU/H (5.28 Kilowatts) Input. -
Page 4: Installation
B-Series DV-2 Gas Fireplace Installation When installing a shelf over the top of the fireplace, the following Installing and Framing the Fireplace guidelines must be adhered to: For Rear Vent applications the fireplaces may be installed in any location that main- B-Series-DV-2 minimum clearance from the top of the fireplace to a shelf is 8". -
Page 5: Installing The Gasline
B-Series DV-2 Gas Fireplace Installation Installing The Gas Line Use only certified Montigo vent components. (Use of other parts will void The gas line must be installed before finishing the B-Series DV-2 the Montigo warranty, and may impede the operation of the fireplace.) Fireplace. -
Page 6: The Remote Switch
B-Series DV-2 Gas Fireplace Installation Installing Terminations with Built-In Frames Installing Heat Guards over Terminations MTO-3F (4"/7") PTO-3F (5"/8") MTKOG (4"/7") PTKOG (5"/8") Ensure that the two long mounting brackets are facing the bottom Frame the termination opening to 11" x 11". of the termination. -
Page 7: Top Vent Venting Runs
NOT be an acceptable installation. If the 'X' falls on or above the top boundary of the shaded area, the installation is acceptable. B34DV-2 B34DV-2 Example A: (Acceptable Installation) If the vertical dimension from the hearth is 108" and the horizontal run to the wall flange of the vent termination is 180", this would be an accept-... - Page 8 B-Series DV-2 Gas Fireplace Installation Example 1: For our shortest venting configuration use components A and E (see table on page 6). Figure 12. Extended Installation using a combination of solid and flex Figure 10. Typical Top Vent installation. If the 90° elbow is installed venting.
- Page 9 B-Series DV-2 Gas Fireplace Installation B. Vertical (Through-The-Roof) Installations A maximum of two offsets (each offset has two 90° bends) may be Vertical Terminations must be installed: made and shall not exceed total length of 25% of the vertical vent •...
-
Page 10: Rear Vent Venting Runs
B-Series DV-2 Gas Fireplace Installation Rear Vent Venting Runs 3. Corner Installation — 45° or less. The B-Series DV-2 Rear Vent has three possible installations which Use an MTO-4 or MTO-4F termination, an MFL-1 or MFL-2(12" or 24" do not require vertical lift. compressed length) and a frame, if appropriate. - Page 11 B-Series DV-2 Gas Fireplace Installation Installation Of Rear Vent DV B. Multi-Elbow Installations For more difficult installation situations, the B-Series DV-2 Rear Vent The following venting components are available for an B-Series DV-2 may be installed with two - 90° elbows and up to 15' of horizontal run. If in a Rear Vent installation: using this installation option, you must adhere to the following guidelines: 4"...
-
Page 12: Finishing Around The Fireplace
Alkyd sealer prior to the applying of latex paints. This is to prevent leaching of water from evaporation and causing a brownish staining effect to paint over coats. Figure 23a. Combustible mantles and facings for B34DV-2. B34DV-2 Figure 24. Combustible surrounds. -
Page 13: Wiring
B-Series DV-2 Gas Fireplace Installation Wiring Wiring for the optional Fan Kit All B-Series DV-2 fireplaces may be equipped with optional fan kits for circulating heat into the living space. Gas Control and Pilot Wiring B-Series DV-2-I Installations in Canada which employ the fans must be electrically grounded in accordance with CSA C22.1 Canadian Electrical Code Honeywell (Q3450) Pilot Assembly... - Page 14 B-Series DV-2 Gas Fireplace Installation Figure 26. Wiring for the SIT IPI Wiring Schematic Part No. XG0160 - 080410 Page 14...
-
Page 15: Removing And Installing The Door
(See figure 29) Install the upper trim pieces so that the baffle is resting between the top and middle piece, as shown below. The trim piece with the Montigo Emblem should be installed on the lower middle clips with the emblem on the right side. -
Page 16: Positioning The Logset
B-Series DV-2 Gas Fireplace Installation Installing the Log Set Installing the Logs: The B-Series DV2 is supplied with five ceramic fibre logs. Unpack the logs and handle them very carefully. Remove the door cover and the glass door. Place the Back log onto the back log rest as shown below in figure 29. -
Page 17: Operation
B-Series DV-2 Gas Fireplace Operation - Model B-Series DV-2 B-Series DV-2 with Continuous Pilot For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. If you cannot reach your gas supplier, call the Fire A. -
Page 18: Lighting Instructions
B-Series DV-2 Gas Fireplace Operation - Model B-Series DV-2-I B-Series DV-2-I with Honeywell Electronic Ignition For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. If you cannot reach your gas supplier, call the Fire A. - Page 19 B-Series DV-2 Gas Fireplace Operation - Model B-Series DV-2-F B-Series DV-2-F with IPI Electronic Ignition For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A.
-
Page 20: Operation
B-Series DV-2 Gas Fireplace Operation Maintenance Lighting Instructions General Have the fireplace and installation inspected yearly. The inspection See pages 14 to 17. must include, but is not limited to, the following: Burner Adjustment B-Series DV-2 • A visual check of the entire vent system and termination. The B-Series DV-2 is equipped with an adjustable burner, allowing you •... -
Page 21: Gas Control Valve
B-Series DV-2 Gas Fireplace Maintenance Gas Control Valve Troubleshooting B-Series DV-2 The following is a troubleshooting chart of possible problems: PROBLEM CORRECTIVE ACTION Noisy Pilot Flame Locate pilot adjustment screw on gas control valve. Flame is decreased by turning adjustment screw clockwise. Pilot won’t ignite Disconnect remote wires and try to light pilot. -
Page 22: Spare Parts
B-Series DV-2 Gas Fireplace Maintenance Notes Spare Parts - B-Series DV-2 B34DV-2 B38DV-2 NG Gas Valve RGC1006 RGC1006 LP Gas Valve RGC1005 RGC1005 RPA020 RPA020 NG Pilot LP Pilot RPA021 RPA021 Burner NG Front RBT1121 RBT1009 Burner NG Rear RBT1122... -
Page 23: Warranty
The duration of any implied warranty with respect to this Montigo Gas Appliance is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you. -
Page 24: Termination Locations
B-Series DV-2 Gas Fireplace Appendix A - Termination Locations A = clearance to the termination frame above grade, veranda, porch, deck, clearance above paved sidewalk or a paved driveway located on public † or balcony [16 inches (41 cm) minimum] property [*7 feet (2.1 m) minimum] B = clearance to door, or sides and top of window, that may be opened [16 P = c l e a r a n c e u n d e r v e r a n d a , p o r c h , d e c k , o r b a l c o n y... -
Page 25: B State Of Massachusetts / Amendment
B-Series DV-2 Gas Fireplace Appendix B - State of Massachusetts Amendment (Gas Fireplace / Equipment sold in the State of Massachusetts) 5.08: Modifications to NFPA-54, Chapter 10 (1) Revise NFPA-54 section 10.5.4.2 by adding a second exception as follows: Existing chimneys shall be permitted to have their use continued when a gas conversion burner is installed, and shall be equipped with a manually reset device that will automatically shut off the gas to the burner in the event of a sustained back-draft (2) Revise 10.8.3 by adding the following additional requirements:... -
Page 26: Notes
B-Series DV-2 Gas Fireplace Notes Notes Part No. XG0160 - 080410 Page 26... - Page 27 B-Series DV-2 Gas Fireplace Notes Notes Part No. XG0160 - 080410 Page 27...
- Page 28 XG0160 - 080410 Montigo Del Ray Corp. Canadian Heating Products Inc. Ferndale, WA 98248 Langley, BC V4W 4A1...
