INSTRUCTIONS
BASIC
COLOR VIDEO PRINTER
OEP-4
USA: CAUTION: Federal law restricts this device to sale by or on the order of a physician.
Table of Contents
Labels and Symbols
Important Information –
Please Read Before Use
Package Contents
Installation and
Connection
Inspection Before Use
Operation
Appendix
1
2
3
4
Advertisement
Table of Contents
Related Manuals for Olympus oep-4
Summary of Contents for Olympus oep-4
- Page 1 Important Information – Please Read Before Use Package Contents Installation and Connection Inspection Before Use INSTRUCTIONS Operation Appendix BASIC COLOR VIDEO PRINTER OEP-4 USA: CAUTION: Federal law restricts this device to sale by or on the order of a physician.
-
Page 3: Table Of Contents
1.1 Checking the Package Contents ....8 Chapter 2 Installation and Connection 2.1 Installation of the Color Video Printer (OEP-4) ............9 2.2 Connection of the EVIS EXERA Video System Center (CV-160) ......11 2.3 Connection of the VISERA Video System Center (OTV-S7V) ........ -
Page 4: Labels And Symbols
Labels and Symbols Safety-related labels and symbols are attached to this If labels or symbols are missing or illegible, contact instrument (OEP-4 color video printer) at the locations Olympus. shown below. Color video printer (OEP-4) Equipotential terminal Electrical rating The product name, rated voltage and frequency are shown. -
Page 5: Important Information - Please Read Before Use
Standard Definition Television. It is the format used by Intended Use ordinary television systems. This instrument, that is, OEP-4 color video printer, has HDTV been designed to be used with Olympus endoscopes, High Definition Television. It is a format featuring video system centers, camera control units and higher image definition than the SDTV format. -
Page 6: Repair And Modification
– Keep fluids away from all electrical equipment. If The following signal words are used throughout this fluids are spilled on or into this instrument, manual: immediately stop operating it and contact Olympus. – Do not prepare, inspect or use this instrument with wet hands. DANGER •... - Page 7 – Do not apply excessive force to the terminals of this instrument. • When using spray-type medical agents such as lubricate, anesthetic, or alcohol, use them away from this instrument so that the medical agents will not fall on this instrument. The medical agents possibly may come into this instrument from its ventilation grills and cause the failure.
-
Page 8: Chapter 1 Package Contents
Match all items in the package with the components shown below. Inspect each item for damage. If this instrument is damaged, a component is missing or you have any questions, do not use this instrument; immediately contact Olympus. Color video printer Trial pack (100 sheets) Ink ribbon holder... -
Page 9: Chapter 2 Installation And Connection
2.1 Installation of the Color Video Printer (OEP-4) - Page 10 Place the color video printer (OEP-4) on the mobile shelf of the mobile workstation. Be sure the portion of the color video printer (OEP- 4) does not contact with the mobile workstation, etc., when you attach or remove the paper tray, or...
-
Page 11: Connection Of The Evis Exera Video System Center (Cv-160)
To RGB, Y/C, or VIDEO input terminal of a monitor Attach the two black screws, provided with the To Remote terminal of a monitor remote cable (MH-995). VIDEO OUT Color video printer (OEP-4) RS-232C terminal terminal INPUT terminals RGB cable (MH-984) BNC cable (MB-677) -
Page 12: Connection Of The Visera Video System Center (Otv-S7V)
2.3 Connection of the VISERA Video System Center (OTV-S7V) To a monitor To Y/C input terminal of a monitor Color video printer (OEP-4) INPUT terminal S VIDEO S VIDEO VIDEO IN REMOTE 2 terminal terminal terminal terminal OEP cable (MH-987) -
Page 13: Connection To The Ac Mains Power Supply
To connect to the AC mains power supply Moreover, if power cord is damaged, turn OFF the power and stop using this instrument immediately and Confirm that the color video printer (OEP-4) is contact Olympus. turned OFF. – When placing the power cord, take care that it is not... -
Page 14: Chapter 3 Inspection Before Use
Should the slightest irregularity be suspected, Press the power switch to turn ON the color video do not use this instrument and see “Chapter 7 printer (OEP-4) (see Figure 3.1). Troubleshooting” in “INSTRUCTIONS (ADVANCED).” If the irregularity is still suspected Confirm that the PRINT lamp is lit and then turns after consulting Chapter 7 in “INSTRUCTIONS... -
Page 15: Installation Of The Color Printing Pack (Upc-55)
Take out the ink ribbon holder (see Figure 3.3). 3.2 Installation of the Color Printing Pack (UPC-55) Install the separately available color printing pack (UPC-55) on this instrument. In addition, never use the other printing packs except UPC-55. For the first time using this instrument, supplied trial pack can be used for an operation check. - Page 16 (see Figure 3.6). Also refer to the caution label on the ink ribbon holder. Gear (White) Push the ink ribbon holder all the way into the color video printer (OEP-4) (see Figure 3.8). Caution label Figure 3.8 Gear (Gray) WARNING Do not insert or put something except ink ribbon holder into the paper exit.
-
Page 17: Installation Of The Print Sheets
Close the front door of the color video printer Press the PUSH EJECT area of the paper tray and (OEP-4) (see Figure 3.9). take out the paper tray from the color video printer (OEP-4) (see Figure 3.11). Front door Figure 3.11 Figure 3.9... - Page 18 Open the cover of the paper tray. Insert the paper tray into the color video printer If print sheets remain in the paper tray, remove (OEP-4) until it clicks (see Figure 3.15). them. Align the direction of the arrow of the positioning...
-
Page 19: 3.3 Setup Of The Connected Equipment
3.3 Setup of the Connected Equipment This document, “INSTRUCTIONS (BASIC),” explains the EVIS EXERA video system center (CV-160) and the VISERA video system center (OTV-S7V). Refer to the instruction manuals of the connected equipment and set them up as required for use with this instrument. -
Page 20: Setting Of The Rear Panel
“Countermeasures Against Messages” in “7.1 Troubleshooting Guide” in “INSTRUCTIONS (ADVANCED).” Turn the color video printer (OEP-4) ON as described in “3.1 Inspection of the Power Supply” on page 14. Confirm that the LCD panel displays the startup message and that the display then changes as shown in Figure 3.18. -
Page 21: Setup Of This Instrument
Cursor keys “v” “V” “b” “B” MENU button LCD panel Figure 3.19 Press the MENU button. Perform setup of the color video printer (OEP-4) and confirm in the following procedures according to the connected equipment. Table 3.3 Connecting Procedure CV-160 1 Press “B”... -
Page 22: 3.7 Inspection Of The Monitor Display
3.7 Inspection of the Monitor Display The monitor displays information and messages When the color video printer (OEP-4) is connected according to the conditions of this instrument. to a video system center, display the image from the color video printer (OEP-4) on the monitor by... -
Page 23: Check Of The Printed Picture
Inspection of the CVP counter 3.8 Check of the Printed When this instrument is connected to the following equipment, perform the inspection of the CVP counter. Picture – EVIS EXERA video system center (CV-160) – EVIS video system center (CV-240, CV-140) Check whether the printed picture is desired. -
Page 24: Chapter 4 Operation
MRI or radio equipment). Electromagnetic Press the power switch (see Figure 4.1). radiation can interfere with the monitor display. • It is recommended to use only Olympus high- frequency electrosurgical equipment with this instrument. Non-Olympus equipment can cause interference on the monitor display or a loss of the endoscopic image. -
Page 25: Control From The Connected Equipment
Cause the difference between settings of the EVIS EXERA video system center (CV-160) and settings of Set up the color video printer (OEP-4) according to this instrument, desired operation may not be carried the connected equipment as described in “3.6 Setup out or image data may disappear. -
Page 26: In The Case Of A Paper Jam
Figure 4.2 Remove the ink ribbon cartridge and the paper tray from the color video printer (OEP-4) and then turn the color video printer (OEP-4) upside down. 4.3 In the Case of a Paper Jam... -
Page 27: Restart Printing
Figure 4.9 Remove the jammed paper slowly (see Figure 4.7). Reset the paper tray and ink ribbon holder into the color video printer (OEP-4). Reconnect the power cord and other connecting cables as they were. Confirm that any connecting cables and the power cord are securely connected. -
Page 28: Exiting From Examination
If there is any, print them. manually. After printing is completed, turn the color video Message “READING IMAGES” is displayed on printer (OEP-4) OFF. the monitor and the LCD panel. And then the display returns to the normal display. When image readout completes, message “RESTORE FINISHED”... -
Page 29: Appendix
For further details, contact Olympus. WARNING If combinations of equipment other than those shown in the following chart are used, the full responsibility is assumed by the medical treatment facility. - Page 30 Mobile workstation (WM-N60) VISERA Video System Center (OTV-S7V) 3CCD Camera Control Unit (OTV-SP1C, OTV-SP1C-G) Camera Control Unit (OTV-SX2) Color video printer (OEP-4) Video System (OTV-SI) Remote control unit (MAJ-898) EUS EXERA Compact Enoscopic Ultrasound Center (EU-C60) High Definition LCD Monitor (OEV191H)
-
Page 31: Operating And Storage Environment
Operating and Storage Specifications Environment Item Specifications Power supply Supply voltage 100 – 120 V AC Color video printer (OEP-4) Voltage fluctuation ±10% Supply frequency 50/60 Hz Operating Ambient temperature 10 – 35°C (50 to environment 95°F) Frequency ±1 Hz... - Page 32 Item Specifications Input signal HDTV signal (1080/ 59.94i): RGB/YPbPr video signal. Y/C video signals Composite video signal Tolerance (75 Ω termination) RGB (HDTV) video signals: 0 to 0.7 Vp-p (Video) ±0.3 Vp-p (Sync). RGB video signals: 0 to 0.785 Vp-p. Composite sync: 1.0 to 4.0 Vp-p.
-
Page 33: Emc Information
EMC Information This model is intended for use in the electromagnetic environments specified below. The user and the medical staff should ensure that it is used only in these environments. Magnetic emission compliance information and recommended electromagnetic environments Emission standard Compliance Guidance RF emissions... - Page 34 Cautions and recommended electromagnetic environment regarding portable and mobile RF communications equipment such as a cellular phones Immunity test IEC 60601-1-2 Compliance level Guidance test level Formula for recommended separation distance =3 according to the compliance level) Conducted RF 3 Vrms 3 V (V IEC 61000-4-6 (150 kHz to 80 MHz)
-
Page 35: Fcc
Subpart B of Part 15 of FCC Rules. Declaration of Conformity Trade Name : OLYMPUS MEDICAL SYSTEMS Model : OEP-4 Responsible Party : OLYMPUS AMERICA INC. Address :Two Corporate Center Drive, Melville, N.Y. -
Page 36: Index
Rear panel 20 Index This instrument (OEP-4) 21 Labels and symbols related to safety Signal words 6 Source image 5 Specifications 31 Startup message 20 “AA”-size battery 8 System chart 29 Memory image 5 Camera control unit 5 Terms used in this manual 5... - Page 37 Index...
- Page 38 Index...
- Page 39 ©2005 OLYMPUS MEDICAL SYSTEMS CORP. All rights reserved. No part of this publication may be reproduced or distributed without the express written permission of OLYMPUS MEDICAL SYSTEMS CORP. OLYMPUS is a registered trademark of OLYMPUS CORPORATION.
- Page 40 Manufactured for 2951 Ishikawa-cho, Hachioji-shi, Tokyo 192-8507, Japan Fax: (0426)46-2429 Telephone: (0426)42-2111 Distributed by Two Corporate Center Drive, PO Box 9058 Melville, N.Y. 11747-9058, U.S.A. Fax: (631)844-5442 Telephone: (631)844-5000 One Corporate Drive, Orangeburg, N.Y. 10962, U.S.A. Fax: (845)398-9444 Telephone: (845)398-9400 GT2250 01 Printed in Japan 2-667-560-11 (1)
