- Page 1 Kempact Pulse 3000 KempactCool Operating manual Bruksanvisning Gebrauchsanweisung Manual de instrucciones Käyttöohje Manuel d’utilisation Manuale d’uso Gebruiksaanwijzing Brugsanvisning Instrukcja obsługi Инструкции по эксплуатации Bruksanvisning 操作手册...
- Page 3 Operating manual english...
-
Page 4: Table Of Contents
........................Kempact Pulse 3000, KempactCool 10... -
Page 5: Preface
Do not copy, record, reproduce or transmit the contents of this guide without prior permission from Kemppi. product introduction The Kempact Pulse 3000 is a compact MIG inverter suitable for repair and installation use, and for light and medium industrial use. © Kemppi Oy / 1336... -
Page 6: Before You Start Using The Unit
Connection to the mains supply The Kempact Pulse 3000 is delivered with a five metre mains cable without a plug. Installation of the plug should be carried out only by a competent electrician. For fuse and cable sizes, see the technical data in the end of this document. -
Page 7: Duratorque™ 400, 4 Wheel Wire Feed Mechanism
W000961 brown W001049 W001050 yellow W001051 W001052 grey W001053 W001054 black W001055 W001056 Fc, Mc, (Fe) W001057 W001058 V-groove, knurled orange W001059 W001060 1.4 – 1.6 yellow W001061 W001062 grey W001063 W001064 black W001065 W001066 © Kemppi Oy / 1336... -
Page 8: Installation Of Welding Gun
• Release locking nails of wire reel hub by turning locking knob a quarter round. • Mount the reel at its place. Note rotating direction of reel! • Lock the reel with locking knob, locking nails of hub remain to outside position and will lock the reel. Kempact Pulse 3000, KempactCool 10... -
Page 9: Automatic Wire Feed To Gun
The greater the wire feed speed, the greater the braking force required. Do not keep the brake unnecessarily tight, since this will impose a strain on the motor. © Kemppi Oy / 1336... -
Page 10: Shielding Gas
Always fasten the gas cylinder securely in an upright position on a wall rack intended for the NOTE! purpose or on a cylinder cart. Always close the cylinder valve after you have finished welding. Kempact Pulse 3000, KempactCool 10... -
Page 11: Cooling Unit (Kempactcool 10)
Cooling liquid is injurious! Avoid also contact with skin or eyes. In case of injury, seek for NOTE! medical advice. Cooling unit KempactCool 10 together with MIG-gun of Kemppi's PMT-W and MMT-W range enables MIG welding with water-cooled gun. The cooling unit is installed beneath the power source with screws and mounting plate. -
Page 12: Operation
The welding of very thin steelplates (0.5 to 0.7 mm) a - polarity might also work best for solid wire. 3.2.1 Changing the polarity - pole + pole Only a service shop authorised by Kemppi may change the polarity. NOTE! Kempact Pulse 3000, KempactCool 10... -
Page 13: Panel
Choose the appropriate synergy curve for the filler wire and shielding gas to determine how the wire feed speed affects the pulse parametres. © Kemppi Oy / 1336... -
Page 14: Selecting 1-Mig/Pulse Mig Synergy Curves
One press will revert to the material group and diameter display, a second will display the type number of the material and a third run through the gas consistency components one by one. KEMPACT PULSE 3000 Synergic programs 1-MIG Pulse Double Wire, ø... - Page 15 1,0 mm CuSi3-A 5,0 – 5,5 1,0 mm CuSi3-A 5,5 – 6,0 1,0 mm CuSi3-A 6,0 – 6,5 1,0 mm CuSi3-A 6,4 – 7,0 1,0 mm CuSi3-A 6,9 – 7,6 1,0 mm CuSi3-A 7,4 – 8,1 © Kemppi Oy / 1336...
-
Page 16: Adjustments, Display And Weld Data
0-position is the recommended reference range. Values -9...-1 give a smoother arc and less spatter, while values 1...9 give a rougher arc and increased stability, when using a 100% CO ₂ shielding gas when welding steel. Kempact Pulse 3000, KempactCool 10... -
Page 17: Remote Control
First, press the SETUP button and then , while still pressing the SETUP button, press the extra function button. Adjust the Hot Start level. Repeat step 2, upon which the display will show the next adjustable parameter, depending on the switch mode. Exit by pressing any button (except SETUP) © Kemppi Oy / 1336... -
Page 18: Use Of Gas Test
Select memory channels by pressing the CH REMOTE button simultaneously and the gun control light will start to blink. Use the saved values through the gun’s remote control. You can use five channels. Kempact Pulse 3000, KempactCool 10... -
Page 19: Setup
Display reset time 1 – 20 s PRG INFO - feeld 1, 2, 3 selection Restore Restoring factory settings (OFF=no reset, Pan=panel and setup ALL= also memory channels) © Kemppi Oy / 1336... -
Page 20: Error Codes
• If you use a water-cooled gun you can fill it with cooling liquid by pressing TEST-button (on cooling unit). The pump operates for 5 another minutes after welding has been finished to cool the liquid to the same temperature as in the machine surrounds. This reduces the need of service. Kempact Pulse 3000, KempactCool 10... -
Page 21: Maintenance
The owner of the equipment is obliged to deliver a decommissioned unit to a regional collection centre, per the instructions of local authorities or a Kemppi representative. By applying this European Directive you will improve the environment and human health. -
Page 22: Ordering Numbers
Wire spool pole 4289880 5 kg spool adapter 4251270 teChniCal Data Kempact Pulse 3000 Connection voltage 3~, 50/60Hz 400V ±15% Rated power 40% ED 12 kVA 250A 60% ED 10 kVA 207A 100% ED 7.5 kVA 160A Kempact Pulse 3000, KempactCool 10... - Page 23 Tank volume External dimensions ( 580x280x300 mm LxWxH) Weight 13 kg Operating temperature range - 20 °C ...+ 40 °C Storage temperature range - 40 °C ...+ 60 °C EMC class Degree of protection IP23S © Kemppi Oy / 1336...
