Summary of Contents for Nice HSCU1
- Page 1 Nice HSCU1 Home security control unit 0682 Instructions and warnings for installation and use...
-
Page 3: Table Of Contents
3.2 - Where to position the alarm system components ... . . 4 3.3 - Elements in the Nice Home Security alarm system ... . 7 3.4 - Main features of the Nice Home Security alarm system . -
Page 4: Warnings And General Precautions
3 years as of the date of manufacture. The guarantee applies to direct pur- • Do not place system components near sources of heat to avoid potential chasers from Nice. No guarantee is envisaged for the end user, who in the damage. -
Page 5: Technical Glossary
TABLE 2 DEVICES TYPE OF DISTURBANCE PROBABILITY OF DISTURBANCE Radio and television transmitters continuous high, if close Variable speed motors continuous low, during use only UPS units continuous during phase of use medium, during use only Switching power supply units continuous during phase of use medium, during use only Other devices on the same frequency, used <... -
Page 6: Designing An Alarm System
DESIGNING AN ALARM SYSTEM To obtain a perfectly operational and efficient system in terms of the intended siren alarm on the first attempt at break-in via a door or window (in zone B), or use, the system must first be designed “at the table”, before proceeding to the calls to the police forces only when the indoor detectors (in zone C) signal intru- operating phases described in this manual. - Page 7 The keypads can be wall-mounted or portable (as with a criteria for each sensor in Table 3. transmitter) if required. HSDIM11 HSDIW01 HSDIM12 HSDID11 HSDIM21 HSCU1GC HSCU1C HSDIM22 HSCU1G HSCU1 HSDIM12 HSDID11 HSDIW01 HSDIM12 HSDIM11 HSDIS01 HSSI HSDID11 HSSOC HSSO HSDID11...
- Page 8 TABLE 3 Door sensor: this is an intruder sensor designed to protect doors or windows, and signals opening of the latter when the magnet is moved away from the sensor body. The detector is normally mounted on the fixed section of the frame to be protected, on the side opposite the hinge, while the magnet is fitted on the movable section.
-
Page 9: Elements In The Nice Home Security Alarm System
3.3 - Elements in the Nice Home Security alarm system Control unit The control unit is the core of the system; it receives information from the detectors, keypads and transmitters and, according to its status, generates an audible alarm (siren) or sends signals on the fixed or mobile telephone net- work. - Page 10 Actuators The alarm system Nice Home security, as well as being an alarm for the building, is also able to interact with other devices for domotic management of the environment. By means of special actuators, other devices can be controlled, such as lights, gate opening, shutters etc.
-
Page 11: Main Features Of The Nice Home Security Alarm System
“panic” alarms. To avoid disturbance, if the system has been left acti- To exploit the Nice Home Security alarm system to the full, the user needs to vated, the siren is activated after a pre-alarm interval of approx. 10 seconds, know all the features to ensure correct configuration of the entire system during which a series of beeps are emitted. -
Page 12: Installation: The Control Panel And Accessories
• Check that the fixing surfaces are sufficiently solid and that the areas are pro- tected against the risk of impact. • The product can only be used with products part of the Nice Home Security Models HSCU1GC and HSCU1C system. -
Page 13: Installation: Control Unit
4.4 - INSTALLATION: Control unit 09. Fix the control unit to the wall using the screws supplied (fig. 17); (models HSCU1GC - HSCU1C and HSCU1G - HSCU1) 10. Electrical connections: • For models HSCU1GC and HSCU1C: 4.4.1 - Warnings make the electrical connections and insert the buffer battery as described Before proceeding with installation carefully read paragraphs 4.1 - 4.2 - 4.3. - Page 15 HSCU1G and HSCU1...
-
Page 16: Door And Window Opening Detector (Model Hsdid11)
It detects opening of a door or window and signals it via radio to the associated 2 OFF = non-differentiated alarm signal: single code for both alarms. control unit. Any other use is to be considered improper and prohibited! Nice declines 2 ON... -
Page 17: Infrared Detector With Volumetric Lens (Model Hsdim11)
2 ON = differentiated alarm signal: transmission of 2 different codes, one for the ed! Nice declines all liability for damage resulting from improper use of the product and detector alarm and one for the alarm of the NC input. -
Page 18: Infrared Detector With Vertical Curtain Lens (Model Hsdim12)
4 ON = input not in use (factory setting); the input is closed by the dip-switch. Nice declines all liability for damage resulting from improper use of the product and any 5* OFF = Anti-removal/tamper protection enabled. use other than as specified in this manual. -
Page 19: Volumetric Detector Of Glass Breakage (Model Hsdid01)
Nice declines all liability for damage resulting from improper use of the product and should only be activated when there is no risk of other sounds that may trigger the any use other than as specified in this manual. -
Page 20: Flooding Detector (Model Hsdiw01)
Any other use is to be considered improper and is strictly prohibited! Nice declines all liability for damage resulting from improper use of the product and other than as specified in this manual. -
Page 21: Control Keypad (Model Hskps)
HSTT2L) to transmit a command (pulse) each time it is pressed. Caution! – Trans- Any other use is to be considered improper and is strictly prohibited! Nice declines all liability for damage resulting from improper use of the product and other than as speci- mission occurs after the key has been pressed for 2 seconds. -
Page 22: Indoor Siren (Model Hssi)
Designed for indoor use. Any other use is to be considered improper and is strictly prohibited! Nice declines all liability for damage resulting from improper use of the product and other than as speci- fied in this manual. -
Page 23: External Siren With Wired Connections (Model Hssoc)
Also, for each control panel arming phase, the acoustic signals occur each time the Any other use is to be considered improper and is strictly prohibited! Nice declines all alarm (+N) is armed, only until the programmed count is reached; the siren is then liability for damage resulting from improper use of the product and other than as speci- fied in this manual. -
Page 24: Electrical Connections
ELECTRICAL CONNECTIONS 5.1 - Warnings • The connection to the mains must be performed by skilled and quali- fied personnel in observance of standards governing electrical installa- tions. • On the system, fit a 2-pole disconnect device with a gap between contacts of at least 3 mm, or use an electric cable equipped with a plug suited to a standard socket. - Page 25 SENSOR SIR GND +OFF +SAA TMPA BATTERY BATT ALIM TAMPER A2 TMPA GND KEY LINE NC1 COM1 COM2 RELAY 12 Vcc...
-
Page 26: Control Panel Programming
CONTROL PANEL PROGRAMMING The control panel is programmed via the keypad on the control panel, accord- 6.1 - Initial start-up and configurations ing to the instructions on screen and the vocal guide provided in the main phas- When the battery is connected, the display lights up and the control panel es of programming. - Page 27 SIM expiry warning message (programmed expiry, see SET- SIM VALIDITY TINGS) DIRECT ACCESS Enables (yes) or disables (no) the option for direct access from this number; i.e. the possibility of calling the control panel from a mobile phone and enable operations without entry of the user code as the caller ID is recognised automatically by the system. Notes for recording numbers in the phone book.
- Page 28 BATT battery low DISARM. disarming IN A (or B or C) arming of specific group activation SUPERV supervision alarm SCAN scanner alarm END AL door reclosed tamper alarm TEMPERATURE hot/cold temperature alarm To program an alarm, the event must be written in the first section of the display (example: to write “low battery” enter BATT and press OK to confirm); then in the second section, write the nome assigned to the device that generates the event (see EXTRAS): for control panel write CONTROL PANEL and press OK to confirm.
- Page 29 tion, press OK to confirm. The presence of these inputs is recognised by the control panel in self-learning mode. If the inputs are then to be cancelled, simply set the control panel Test 11. Record the vocal message for detector recognition; press and hold OK function and eliminate connections.
- Page 30 “Digital service centre must be equipped with the relative HSMO telephone modem Protocols” from the Nice Service Centre. and relative software for PC Tele Service. Remote assistance must in any event be explicitly activated by the user by pressing the “spanner”...
-
Page 31: Product Maintenance
PRODUCT MAINTENANCE In general, the products in the range Nice Home Security do not require special 7.1 - Replacing the batteries (control panel and accessories) maintenance; in any event the surfaces of the products should be cleaned, and When the battery pack or backup battery of the control panel or those in the... - Page 32 HSCU1GC and HSCU1C only for models HSCU1G and HSCU1...
-
Page 33: Troubleshooting
- Vibrations: the internal anti-intruder sensor is sensitive to strong vibrations - External contact: the connection to the external contact is sensitive to high • For all products in the Nice Home Security system levels of humidity Virtually all products are fitted with protection against opening and removal; this system normally acts on the cover and base of the product. -
Page 34: Operation Instructions
OPERATION INSTRUCTIONS 9.1 - Tips when using the system 9.2.5.1 - CONTROL PANEL test • Always activate the alarm. 05. Generate a detector alarm by opening protected doors and windows or moving within the area protected by the volumetric detectors etc. •... - Page 35 EXAMPLE 1 EXAMPLE 1 - key n° Display Meaning date/time of event INSTALL access to menu with installer code 1 6 / 0 5 / 0 7 1 9 : 5 9 USER access to menu with user code NO PSTN LINE no connection to PSTN telephone line I N S T A L NO GSM NETWORK...
- Page 36 Calling the control panel on the fixed line 03. Call again immediately. the control panel answers with vocal message N° 7. 04. After listening to the message, enter the user code on the telephone key- Caution! - To answer incoming calls on the PSTN line, the guide message pad, followed by the symbol #.
-
Page 37: Technical Specifications
Caller ID recognition (for direct access). Hands-free communication Technical specifications common to all models (HSCU1G, HSCU1, HSUC1GC, HSCU1C) Alarm via radio inputs Up to 99 programmable detectors: immediate, delayed or AND, on 3 activation zones A-B-C or in 24-hour zones Panic, Robbery, Technical Alarm. -
Page 38: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY Note - The contents of this declaration correspond to declarations in the official document deposited at the registered offices of Nice S.p.a. and in particular to the last revision available before printing this manual. This declaration has been re-edited for editorial purposes. - Page 40 Ph. +351.21.922.82.10 Ph. +39.049.87.01.05.1 Nice Australia infomarseille@fr.niceforyou.com Fax +351.21.922.82.19 Fax +39.049.87.07.63.8 Wetherill Park Australia info@pt.niceforyou.com infopd@niceforyou.com Ph. +61.(0)2.96.04.25.70 Nice France Rhône Alpes Fax +61.(0)2.96.04.25.73 Nice Roma Decines Charpieu France Nice Romania info@au.niceforyou.com Roma Italia Cluj Napoca Romania Ph. +33.(0)4.78.26.56.53 Ph. +39.06.72.67.17.61 Ph./Fax +40.(0)264.453.127...
