11.2

Connector wiring

11.2.1

Ethernet interface 10/100Base-TX

8-pin RJ45 sockets (ISO 8877, EN 60603-7)
11.2.2

ADSL interface

6-pin RJ11 socket
Only LANCOM
1821n Wireless
LANCOM 1811n Wireless – LANCOM 1821n Wireless
Connector
Connector
Chapter 11: Appendix
Pin Line
1 T+
2
3 R+
4 PoE/G
5 PoE/G
6
7 PoE/ -48 V
8 PoE/ -48 V
Pin
1
2
3
4
5
6
T-
R-
IAE
–
–
a
b
–
–
95
