LANCOM 1811n Wireless – LANCOM 1821n Wireless
Chapter 2: Installation
»
WAN Status Connection status of the WAN connection:
(only LANCOM
1811n
off
Wireless)
green
green
green
red
¿
WAN Data Data traffic via the WAN connection:
(only LANCOM
1811n
off
Wireless)
green
green
´
ADSL status Information on connection status at the ADSL connector:
Off
Green
Green
Red
Red
Red/
orange
²
Information on data traffic at the ADSL connector:
ADSL data
Off
Green
Green
Green
Green
30
not connected
blinking Establishing first connection
invers flashing Establishing further connection
constantly on At least one connection established
constantly on Error while establishing connection
No network device connected
constantly on Connection to network device operational, no data traffic
flickering Data traffic (send or receive)
Interface deactivated
Blinking/flashing Handshake/training
Permanently Synchronization successful
Flickering Error (CRC error, framing error, etc.)
On (permanently) No synchronization, searching for remote station
Blinking Hardware error
No logical connection
Blinking Opening the first connection
Inverse flashing Opening an additional connection
Permanently At least one logical connection is established
Inverse flickering Data traffic (send or receive)
