Onkyo HT HT-S7300 Instruction Manual page 71

7.1ch Home Theater Speaker Package (HTP-780)
■
Powered Subwoofer (SKW-780)
Type Bass-reflex
Input sensitivity/Impedance
140 mV/20 kΩ
Maximum output power
290 W (Dynamic power)
Frequency response 25 Hz to 150 Hz
Cabinet capacity 37 L (1.3 cubic feet)
× ×
Dimensions (W H D)
10-13/16"
275 mm
(incl. projection)
Weight 11.6 kg (25.6 lbs.)
Drivers unit 10" (25 cm) Cone Woofer
Power supply AC 120 V, 60 Hz
Power consumption 163 W
■
Front Speaker (SKF-780)
Type 2 Way Bass-reflex
Impedance 6Ω
Maximum input power 130 W
Sensitivity 79.5 dB/W/m
Frequency response 55 Hz–50 kHz
Crossover frequency 4 kHz
Cabinet capacity 7.3 L (0.26 cubic feet)
Assembly dimensions (with supplied speaker base)
(W × H × D):
10-5/16" × 41-1/8" × 10-5/16"
262 mm × 1045 mm × 262 mm
(incl. projection)
Weight 5.2 kg (11.5 lbs.)
(incl. speaker base)
3-1/4" (8 cm) Cone (Woofer) × 2
Drivers unit
1" (2.5 cm) Balanced dome (Tweeter)
Terminal Spring type color coded
Grille Fixed
Dock for iPod UP-A1
× ×
Dimensions (W H D)
3-1/4"
83 mm
Weight 170 g (6 ounces)
Specifications and features are subject to change
without notice.
× ×
19-15/16" 16-3/16"
× ×
507 mm 411 mm
× ×
1-5/16" 2-15/16"
× ×
33 mm 74 mm
■
Center Speaker (SKC-780)
Type 2 Way Bass-reflex
Impedance 6Ω
Maximum input power 130 W
Sensitivity 79 dB/W/m
Frequency response 60 Hz–50 kHz
Crossover frequency 4 kHz
Cabinet capacity 2.8 L (0.10 cubic feet)
× ×
Dimensions (W H D)
16-9/16" × 4-1/2" × 4-3/4"
420 mm × 115 mm × 121 mm
(incl. grille and projection)
Weight 2.2 kg (4.9 lbs.)
Drivers unit
3-1/4" (8 cm) Cone (Woofer)
1" (2.5 cm) Balanced dome (Tweeter)
Terminal Spring type color coded
Keyhole slot 2
Grille Fixed
■
Surround/Surround Back Speaker
(SKR-780/SKB-780)
Type Full-Range closed box
Impedance 6Ω
Maximum input power 130 W
Sensitivity 81 dB/W/m
Frequency response 80 Hz–20 kHz
Cabinet capacity 1.0 L (0.036 cubic feet)
× ×
Dimensions (W H D)
4-1/2"
115 mm
(incl. grille and projection)
Weight 1.0 kg (2.2 lbs.)
Drivers unit 3-1/4" (8 cm) Cone
Terminal Spring type color coded
Keyhole slot 1
Grille Fixed
×
2
× ×
9-1/16" 3-3/4"
× ×
230 mm 96 mm
En
71
