Onkyo HT-S7200 Quick Setup

QUICK SETUP

Model : HT-S7200
Thank you for purchasing this product.
This quick setup sheet shows the typical hookup method for connecting
speakers and AV components (DVD/BD player, TV, cable/satellite receiver).
For more detailed hookup information and operating instructions,
please see the Instruction Manual.
Speaker Layout (Main Room)
Front High
Left
(Optional)
TV TV
Front
Front
Left
Left
Center
Center
Surround
Surround
Left Listener Listener
Left
Surround
Surround
Back
Back
Left
Left
Front High
Right
(Optional)
Front
Front
Right
Right
Surround
Surround
Right
Right
Powered
subwoofer
Surround
Surround
Back
Back
Right
Right
· HTP-770 speaker package is shown.
· When you connect the front high left and right speakers, preparate it
separately, or use the surround back left and right speakers.
Speaker Hookup
Front
right
speaker
Front
high right
speaker
(Optional)
Center speaker
*1
3/8''-1/2'' (10-12mm)
Surround back Surround right
right speaker speaker
*1 The same signal is output from each jack.
See the other side of this sheet for the AV component hookup.
(C) Copyright 2009 ONKYO CORPORATION Japan. All rights reserved.
Front
left
Front speaker
high left
speaker
(Optional)
Surround left Surround back
speaker left speaker
SN 29400120
* 2 9 4 0 0 1 2 0 *
