Onkyo HT-R340 Specification Sheet

Onkyo HT-R340 Specification Sheet

Onkyo 5.1-channel a/v surround home theatre receiver/speaker package specification sheet
Hide thumbs Also See for HT-R340:

Advertisement

HT-S590
5.1-Channel A/V Surround Home Theatre Receiver/Speaker Package
HT-R340
5.1-Channel A/V Surround Home Theatre Receiver
•105 W/Ch, continuous 6
, 1 kHz, FTC •120 W/Ch, continuous 6
JEITA •DTS
®
, DTS
®
Neo:6 5.1, Dolby
®
Digital, Dolby
(High Current Power Supply) massive high power transformer •192 kHz/24-
bit DACs for all channels •HDTV-capable (50 MHz) component video
switching (3 inputs/1 output) •32-bit processing DSP chip •OR-EQ
equalizer function •3 digital inputs (2 optical/1 coaxial) •CinemaFILTER
•Optimum gain volume circuitry •Non-scaling configuration •A-Form
listening mode memory •Color-coded speaker terminals •Crossover
adjustment (40/50/60/80/100/120/150/200 Hz) •A/V sync control function
(fixed at 0/20/40 ms) •Speaker A/B drive •RI (Remote Interactive) remote
control •WHD: 435 x 150 x 369 mm •9.6 kg
Providing Perfect Delivery and a Graceful Presence to Home Theatre
L-MS5500
SILVER
TX-L55
SILVER
6.1-Channel Digital A/V Receiver
•80 W/Ch, continuous 6
, 1 kHz, JEITA •Exclusive Onkyo digital amplifier technology •DTS
ES
Discrete/Matrix, DTS
®
Neo:6, DTS
®
96/24, Dolby
current, low-impedance drive •Discrete output stage circuitry •Non-scaling configuration •5
DSP modes •2 component video inputs and 1 output •3 digital inputs •Speaker auto detect
system •CinemaFILTER
•Subwoofer pre out •Color-coded 5.1 multichannel inputs
•Preprogrammed RI (Remote Interactive) remote control
DV-L55
SILVER
DVD/CD/MP3 CD Player
•Plays DVDs, DVD-R/RWs, MP3-encoded CDs, WMA-encoded CDs, CD-R/RWs, video CDs,
audio CDs and JPEG-encoded CDs* •54 MHz/10-bit video DAC •PAL/NTSC progressive scan
•192 kHz/24-bit audio DAC •96 kHz or 48 kHz selectable digital output •Optical & coaxial
digital outputs •Full set of A/V outputs (composite, S-Video & component video) •DVD quick-
start play •High resolution on-screen display (English/French/Spanish) •Full-function RI (Remote
Interactive) remote control
* Discs that have not been properly finalized may only be partially playable or not playable at all.
HTP-340
5.1-Channel Home Theatre Speaker System
SKF-340F
2-Way Bass Reflex Front Speakers
, 1 kHz,
•8 cm cone woofer •2 cm ceramic tweeter
®
Pro Logic
®
II •H.C.P.S.
•Magnetically shielded •Impedance: 6
power: 120 W •Frequency response: 80 Hz–22 kHz
•WHD: 116 x 218 x 127 mm •0.9 kg
SKC-340C
2-Way Bass Reflex Center Speaker
•8 cm cone woofer x 2 •2 cm ceramic tweeter
•Magnetically shielded •Impedance: 6
power: 120 W •Frequency response: 80 Hz–22 kHz
•WHD: 300 x 128 x 118 mm •1.5 kg
®
-
®
Digital EX
, Dolby
®
Pro Logic
®
IIx •High-
SILVER
SKM-340S
2-Way Bass Reflex Surround Speakers
•8 cm cone woofer •2 cm ceramic tweeter
•Max. input
•Impedance: 6
•Frequency response: 80 Hz–22 kHz •WHD: 116 x
218 x 127 mm •0.7 kg
SKW-340
Bass Reflex Subwoofer
•20 cm cone woofer •Max. input power: 125 W
•Max. input
•Frequency response: 30 Hz–150 Hz •WHD: 235 x
461 x 410 mm •8.1 kg
TX-L55, DV-L55, SKF-L500, SKS-L500, SKR-L500, SL-107(S)
SKF-L500
2-Way Bass Reflex Speakers
(See page 13 for product information)
SKS-L500
Center/Surround Speaker Package
(See page 13 for product information)
SKR-L500
Surround
Back Speaker
(See page 13 for product information)
SL-107
( S )
Bass Reflex
Powered Subwoofer
(See page 14 for product information)
Home Theatre System/Home Style Component
•Max. input power: 120 W
TX-L55, DV-L55, SKF-L500,
SKS-L500, SKR-L500, SL-107(S)
19
