as the self-adhesive strip on the microphone holder. The location selected must allow the microphone cable to reach the

electronics box! Position the microphone with the head facing towards the direction of speech.

Cleaning and degreasing the mounting location

The mounting location must be clean and free from grease and dirt/dust. Prior to installation, clean the area with a

cleansing product containing ethyl alcohol. Only use products that do not damage plastics or varnished wood ﬁ nishes

and are themselves free of oils or grease. Unsuitable cleansers are, for example, lighter ﬂ uid, acetone, turpentine,

trichloroethylene and similar products.

Attaching the microphone holder

Peel off the protective backing from the self-adhesive strip. Hold the microphone holder at a distance of several

millimetres (about a quarter of an inch) above the desired mounting location. Re-check the positioning. Re-positioning

after mounting is no longer possible. Place the microphone holder on the mounting location and ﬁ x by applying short and

light pressure.

Attaching the microphone

Attach the microphone by sliding it into the holder and position the microphone head towards the direction of speech.

6.3.3 Inserting the battery in the radio controller

Rotate the lower portion of the controller clockwise and the upper portion counterclockwise to open the controller. Lift

the upper portion. Insert the supplied battery with the positive terminal downward into the lower portion until it latches.

Now place the upper portion on the bottom so that the contacts from the bottom of the controller touch the contact

surface in the upper portion. Position the latching tabs in the notches and rotate opposite the opening direction.

Deﬁ ne the mounting location

The control console is mounted on a smooth service by means of the self-adhesive pad provided. Make sure that the user

can easily reach the controller.
