Sports Camcorder
VP-X205L/X210L/X220L
AF
Auto-Focus
CCD
Charge Coupled
Device
LCD
Liquid Crystal
Display
Owner's Instruction Book
Before operating the unit, please read this
Instruction Book thoroughly, and retain it for
future reference.
This product meets the intent of
Directive 89/336 CEE, 73/23 CEE, 93/68 CEE.
Use only approved battery packs.
Otherwise, there is a danger of overheating, fire or explosion.
Samsung is not responsible for problems occurring due to using
unapproved batteries.
运动型摄录一体机
VP-X205L/X210L/X220L
U
M E N
E
M O D
使用说明书
在操作使用本机前,请彻底阅读本说明书,并保
存好供将来参考
本产品符合下列标准
89/336 CEE, 73/23 CEE, 93/68 CEE.
请使用提供的电池组,否则有过热,着火或者爆炸的危险
三星对由于不使用提供的电池发生的这些问题不承担责任
AF
自动调焦
CCD
电荷耦合器件
LCD
液晶显示器
AD68-00994W
