iPF680
Set./Adj. Menu
Limited items are displayed during printing. The displayed items are indicated by annotations.
Test Nozzle Check
Print
Status Print
Interface Print
GL2 Set Print
Paper Details
Print Job Log
Menu Map
Color Palette
Adjust Head Auto(Standard)
Printer Posi.
Adj.
Auto(Advanced)
Manual
Head Inc. Adj.
Feed Adj. Pri-
Priority ority
Adj.
Quality
User's Guide
Setting Item
Automatic
Print Quality
Print Length
Auto(GenuinePpr)
Auto(OtherPaper)
Manual
Description, Instructions
Print a test pattern to check the nozzles.
Print information about the setting values and condition of
the printer.
Print interface settings information.
Print the settings as specified in GL2 Settings.
Print the paper settings as specified in Paper Details.
Print a record of print jobs, including the paper type and
size, amount of ink consumed, and so on. Ink consump-
tion indicates a rough estimate of the amount of ink con-
sumed per print job.( *1 )
Print the menu structure.
Print the GL2 color palette.
The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction. (See "Automatic Adjustment to Straighten
Lines and Colors.")
P.480
➔
The printer prints and reads a test pattern for automatic
adjustment of Printhead alignment relative to the printing
direction and spacing between nozzles and colors. (See
"Automatic Adjustment to Straighten Lines and Col-
ors.")
P.480
➔
Print a test pattern for adjustment of Printhead alignment
relative to the printing direction. Enter the adjustment val-
ue manually based on the resulting pattern. (See "Manual
Adjustment to Straighten Lines and Colors.")
Print a test pattern for adjustment of the Printhead orienta-
tion. (See "Adjusting Line Misalignment.")
Specify exact paper feeding, if desired. Normally, select
Automatic. Choose Print Quality for attractive printing.
Choosing Print Quality also makes banding less noticea-
ble. Choose Print Length if you prefer to feed the paper
an exact amount.
Specify this mode with paper identified in the Paper Ref-
erence Guide. (See "Displaying the Paper Reference
Guide.")
P.329
➔
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. (See "Automatic Banding
Adjustment.")
P.488
➔
Specify this mode with paper not in the Paper Reference
Guide. (See "Displaying the Paper Reference
Guide.")
P.329
➔
The printer prints and reads a test pattern for automatic
adjustment of the feed amount. Note that this function
takes more time and consumes more ink than Auto(Gen-
uinePpr). (See "Automatic Banding Adjust-
ment.")
P.488
➔
Use this mode with highly transparent media or other pa-
per for which Auto(GenuinePpr) or Auto(OtherPaper)
cannot be used.
Print a test pattern for adjustment of the feed amount
based on the type of paper. (See "Manual Banding Ad-
justment.")
P.489
➔
Menu Settings
P.481
➔
P.483
➔
