iPF680
2
When using 24-inch or A1 (portrait) rolls, pull out the
Adjustable Stopper (a). This completes the procedure
for switching to Extended position A.
Once the printing has finished, use the following procedure to return to the regular position.
1
Lower the Support Rod to the position shown (a) to
return to the regular position. If the Adjustable Stop-
per (b) is extended, retract it.
2
Return to the regular position.
• Switching to Extended position B (ST-27 only)
Switch the stacker to Extended position B as follows.
User's Guide
Using the Output Stacker
