Specifications - Icom IC-7200 Service Manual

SECTION 1
General
• Frequency coverage :
Receive
30 kHz – 60.000000 MHz*
Transmit
1.800–1.999999 MHz*
3
5.33050* , 5.34650*
3
5.37150* , 5.40350*
7.000–7.300 MHz*
14.000 –14.350 MHz,
21.000 – 21.450 MHz,
28.000 – 29.700 MHz,
1
* Some frequency bands are not guaranteed.
2
* Depending on version. *
• Mode : SSB, CW, RTTY, AM
• Number of memory CH : 201
channels
• Antenna connector : SO-239
• Antenna impedance : 50 ø (unbalanced)
• Usable temperature : –10°C to +60°C (+14°F to +140°F)
range
• Frequency stability : Less than ± 0.5 ppm
• Power supply : 13.8 V DC±15% (negative ground)
requirement
• Current drain : Transmit (at 100 W) 22 A
Receive squelched 1.3 A
(at 13.8 V DC)
• Dimensions : 241(W)
1
9
(projections not included)
• Weight (approx.) : 5.5 kg (12.1 lb)
• CI-V connector : 2-conductor 3.5 (d) mm (
• ACC connector : 13-pin
Transmitter
• Output power
SSB, CW, RTTY : 2–100 W
AM : 1–25 W* (*Carrier power)
• Modulation system
SSB : Digital PSN modulation
AM : Digital Low power modulation
• Spurious emissions
HF bands : Less than – 50 dB
50 MHz band : Less than – 63 dB
• Carrier suppression : More than 50 dB
• Unwanted sideband : More than 50 dB
: 8-pin connector (600 ø)
• Microphone
connector
• KEY connector : 3-conductor 6.3 (d) mm (

SPECIFICATIONS

1 2
*
2
, 3.500 –3.999999 MHz*
3 3
, 5.36650* ,
3
,
2
, 10.100 –10.150 MHz,
18.068–18.168 MHz,
24.890– 24.990 MHz,
50.000–54.000 MHz*
3
USA version only.
(split memory: 199; scan edges: 2)
max. audio 2.0 A
× ×
84(H) 281(D) mm,
× ×
5 1
⁄ (W) 3 ⁄ (H) 11 ⁄ (D) in
2 16 16
1
⁄ ˝)
8
1
⁄ ˝)
4
Receiver
• Receive system
• Intermediate frequencies
1st
2
2nd
3rd
• Sensitivity (10dB S/N, preamp: ON, Filter shape: sharp)
SSB, CW
2
,
AM
• Squelch sensitivity (SSB, threshold, preamp ON)
• Selectivity
SSB*
(BW=2.4 kHz)
CW*
(BW=500 Hz)
RTTY
(BW=350 Hz
AM
(BW=6 kHz)
• Spurious and image rejection ratio
• Audio output power
• RIT variable range
• PHONES connector
• EXT SP connector
1 - 1
: Triple-conversion
superheterodyne
: 64.455 MHz
: 455 kHz
: 15.625 kHz
: Less than 0.16 μV
(1.8−29.7 MHz)
Less than 0.13 μV
(50 MHz band)
: Less than 13 μV
(0.5−1.799 MHz)
Less than 2 μV
(1.8−29.7 MHz)
Less than 1 μV
(50 MHz band)
: Less than 5.6 μV
: More than 2.4 kHz/–6 dB
Less than 3.6 kHz/–60 dB
: More than 500 Hz/–6 dB
Less than 900 Hz/–60 dB
) : More than 360 Hz/–6 dB
Less than 650 Hz/–60 dB
: More than 6.0 kHz/–6 dB
Less than 15.0 kHz/–60 dB
*IF filter shape is set to SHARP.
: More than 70 dB
1
(except ⁄ IF through on 50 MHz band)
2
: More than 2.0 W at 10%
distortion with an 8 ø load
(at 13.8 V DC)
: ±9.999 kHz
: 3-conductor 6.3 (d) mm (
: 2-conductor 3.5 (d) mm (
˝)/8 ø
1
⁄
4
˝)/8 ø
1
⁄
8
