Icom IC-7200 Service Manual page 111

[LOGIC UNIT]
REF PARTS
NO. NO.
C45 4030006880 S.CER C1608 JB 1H 472K-T
C47 4030006880 S.CER C1608 JB 1H 472K-T
C49 4030006880 S.CER C1608 JB 1H 472K-T
C50 4030006880 S.CER C1608 JB 1H 472K-T
C70 4030006880 S.CER C1608 JB 1H 472K-T
C71 4030006880 S.CER C1608 JB 1H 472K-T
C72 4030006880 S.CER C1608 JB 1H 472K-T
C73 4030006880 S.CER C1608 JB 1H 472K-T
C74 4030017490 S.CER C1608 JB 1A 105K-T
C101 4030011600 S.CER C1608 JB 1E 104K-T
C102 4030006880 S.CER C1608 JB 1H 472K-T
C103 4030012610 S.CER C2012 JB 1C 474K-T
C104 4030011600 S.CER C1608 JB 1E 104K-T
C105 4030011600 S.CER C1608 JB 1E 104K-T
C106 4030019490 S.CER C2012 JB 1A 106K-T
C107 4030011600 S.CER C1608 JB 1E 104K-T
C108 4030019490 S.CER C2012 JB 1A 106K-T
C109 4030019490 S.CER C2012 JB 1A 106K-T
C110 4030011600 S.CER C1608 JB 1E 104K-T
C158 4030017490 S.CER C1608 JB 1A 105K-T
C170 4030006880 S.CER C1608 JB 1H 472K-T
C171 4030006880 S.CER C1608 JB 1H 472K-T
C172 4030018910 S.CER C1608 JB 0J 475K-T
C211 4030006880 S.CER C1608 JB 1H 472K-T
C212 4030011600 S.CER C1608 JB 1E 104K-T
C1071 4030011600 S.CER C1608 JB 1E 104K-T
C1072 4510009700 S.ELE EEEFK1C101P
C1073 4510009820 S.ELE EEEFK1C470P
C1074 4510009820 S.ELE EEEFK1C470P
J1 6510018971 S.CON B4B-PH-SM4-TB(LF)(SN)
J3 6510019971 S.CON 52808-1071
J4 6510019971 S.CON 52808-1071
J5 6510019971 S.CON 52808-1071
J101 6510024151 S.CON 50FY-BMT-TB(LF)(SN)
J102 6510024151 S.CON 50FY-BMT-TB(LF)(SN)
J301 6510019971 S.CON 52808-1071
DS1 5030003090 LCD S11325 <SUC>
DS2 5040002940 S.LED TLYU1002A(T02)
DS70 5040002940 S.LED TLYU1002A(T02)
DS71 5040002940 S.LED TLYU1002A(T02)
DS73 5040002940 S.LED TLYU1002A(T02)
DS74 5040002940 S.LED TLYU1002A(T02)
DS76 5040002940 S.LED TLYU1002A(T02)
DS77 5040002940 S.LED TLYU1002A(T02)
DS79 5040002940 S.LED TLYU1002A(T02)
DS80 5040002940 S.LED TLYU1002A(T02)
DS82 5040002940 S.LED TLYU1002A(T02)
DS83 5040002940 S.LED TLYU1002A(T02)
DS85 5040002940 S.LED TLYU1002A(T02)
DS86 5040002940 S.LED TLYU1002A(T02)
DS88 5040002940 S.LED TLYU1002A(T02)
DS89 5040002940 S.LED TLYU1002A(T02)
EP2 8930076650 LCD SRCN-3015-SP-N-W (SHJ)
EP4 6910012350 S.BEA MMZ1608Y 102BT
EP5 6910012350 S.BEA MMZ1608Y 102BT
EP6 6910012350 S.BEA MMZ1608Y 102BT
EP45 6910012350 S.BEA MMZ1608Y 102BT
EP46 6910012350 S.BEA MMZ1608Y 102BT
EP47 6910018930 S.BEA MPZ2012S601A
EP48 6910018930 S.BEA MPZ2012S601A
EP49 6910018930 S.BEA MPZ2012S601A
EP50 6910018930 S.BEA MPZ2012S601A
EP51 6910018930 S.BEA MPZ2012S601A
EP52 6910018930 S.BEA MPZ2012S601A
EP53 6910018930 S.BEA MPZ2012S601A
EP54 6910018930 S.BEA MPZ2012S601A
EP55 6910018930 S.BEA MPZ2012S601A
DESCRIPTION M.
LOCATION
B 155.5/28.7
B
B 158.1/28.7
B 25.6/32.5
T 15.5/29.6
T 16.9/33.8
T 15.5/28.3
T 15.9/25.7
B
T 66.5/26.4
T 36.5/27.8
T 66.2/23.4
B
B 155.8/61.2
B 139.7/61.3
B 155.8/64.2
B 136.4/54.5
B 154.1/63.4
B
B 39.7/37.4
B 23.5/23.6
T 39.2/37.7
T 38.4/36.4
B 19.1/32.6
B 19.1/38.4
T 127.8/14.5
B 128.2/19.3
B 129.1/5.1
B 129.1/12.2
B 140.7/29.4
B 157.3/22.7
B
B
B 39.2/25.8
B
B 77.2/59.4
T 172.5/14.3
T 61.5/49.1
T
T
T 61.5/59.2
T
T
T 78.5/59.2
T 78.5/49.1
T
T
T 95.5/59.2
T 95.5/49.1
T
T
B 63.8/14.9
T 12.5/24.8
B 21.6/21.3
B 57.3/10.2
B
T 41.9/23.2
T 41.9/21.5
B
B
B
B 65.4/11.1
B
B
B
[VR-A UNIT]
H/V REF PARTS
NO. NO.
R1 7210002910 VAR
66.1/3.3 R2 7210002960 VAR
J1 6510026670 S.CON IMSA-6281S-06Y900
[VR-B UNIT]
155.1/39
REF PARTS
NO. NO.
138/60.8
J1 6510020711 S.CON 52793-1070(1090)
S1 2250000640 ENC
138/57.9
[MIC UNIT]
REF PARTS
NO. NO.
J1 6510000191 CON
J2 6510019971 S.CON 52808-1071
[PHONE UNIT]
REF PARTS
NO. NO.
61/7.7
R1 7030006070 S.RES ERJ12YJ101U (100)
9.3/29.1
R2 7030006070 S.RES ERJ12YJ101U (100)
R3 7030003440 S.RES ERJ3GEYJ 102 V (1K)
39.2/61
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
53/49.1
J1 6510023891 CON
53/59.2
J2 6510019971 S.CON 52808-1071
70/59.2
70/49.1
EP1 6910014690 S.BEA
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
87/59.2
87/49.1
104/59.2
104/49.1
57.3/8.2
41/21.1
45.5/21
65.4/7.4
8.8/25.3
66.3/4.9
43/21
5 - 15
DESCRIPTION M.
RV-310(RK0972210 10KB/10KB)
RV-313(RK0972210 10KB/10KB)
DESCRIPTION M.
T
TP96D96E20-22F-10KB-3015
DESCRIPTION M.
FM214-8SS(P)-1
B
DESCRIPTION M.
T
T
T
B
T
T
S-G4617#01F 0
B
MPZ1608S221A-T B
S.=Surface mount
H/V
LOCATION
T 21.6/5.1
H/V
LOCATION
9.2/2.4
H/V
LOCATION
18.1/6.5
H/V
LOCATION
24.6/5
24.6/10.1
23.1/12.6
27.7/9.6
23.1/2.5
23.1/13.9
26.6/4
29.2/8.1
