Rf Unit View; Filter Unit View - Icom IC-7200 Service Manual

• RF UNIT
YGR AMP
(IC181)
SEND SW
(Q501)
RF AMP
(Q380)
PRE-AMP
(Q441)
PRE-AMP SW
(Q442, Q443)
• FILTER UNIT
ALC AMP
(IC463)
2 - 3
ATT SW
(Q155)
BUFF
S/P CONV
(IC142)
S/P CONV
(IC141)
ALC AMP
(IC462)
