SECTION 6
[CHASSIS] (C)
REF ORDER
NO. NO.
J1* 6510000370 MR-DS
P1** 5610000380 TMP-K01X-A1
P2** 5610000380 TMP-K01X-A1
P3** 5610000380 TMP-K01X-A1
P4** 5610000380 TMP-K01X-A1
P5** 5610000380 TMP-K01X-A1
P6** 5610000380 TMP-K01X-A1
P7** 5610000380 TMP-K01X-A1
P8** 5610000380 TMP-K01X-A1
MF1 2710000810 FD124010HB-1N7
MF2 2710000810 FD124010HB-1N7
W1** 8900014720 OPC-909A
W5** 8900017870 OPC-1887
W6** 8900017870 OPC-1887
W7** 8900017870 OPC-1887
W8** 8900017870 OPC-1887
W9** 8900017870 OPC-1887
W10** 9025900290 62/99/150/C31/C31
W11** 9086700300 Wire 8
W12** 9025900290 62/99/150/C31/C31
W13** 9086700300 Wire 8
W14** 9025900290 62/99/150/C31/C31
W15** 9086700300 Wire 8
W16** 9025900290 62/99/150/C31/C31
W17** 9086700300 Wire 8
MP1 8010021070 3015 CHASSIS
MP2 8110009510 3015 L-COVER
MP3 8110009500 3015 U-COVER
MP4 8930075130 3015 L-PACKING
MP5 8930075140 3015 U-PACKING
MP6 8930075590 3015 ANT PLATE
MP7 8510018690 3015 MAIN COVER
MP8 8510018700 3015 PA COVER
MP9 8930042690 RUBBER REG (L)
MP10 8930075100 3015 STAND HOLDER
MP11 8930074520 3015 STAND
MP12 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP13 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP14 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP15 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP16 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP17 8810010491 SCREW PH M3X15 ZK3
MP18 8810010491 SCREW PH M3X15 ZK3
MP19 8810004431 SCREW PH M3X6 ZK3
MP20 8810004431 SCREW PH M3X6 ZK3
MP21 8810003171 SETSCREW (A) 3X8 ZC3
MP24 8810009991 SCREW BT B0 3X8 NI-ZK3 (BT)
MP25 8930076070 3015 BUSH
MP26 8930076080 3015 A-NET
MP27 8930076090 3015 FAN HOLDER
MP28 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP29 8810004301 SCREW PH M3X10 ZK3
MP30 8810009371 SCREW BT B0 3X12NI-ZK3 (BT)
MP31 8820000530 FLANGE BOLT M4X8 NI
MP32 8850000140 FLAT WASHER M4 BS NI
MP33 8850000430 S-WASHER M4 NI
MP34 8930075810 SPONGE (KB)
MP35 8930075810 SPONGE (KB)
MP36 8930047070 SPONGE (FQ)
MP37 8930049770 SPONGE (GF)
MP38 8930049770 SPONGE (GF)
MP39 8930071840 HIMELON SHEET (CT)
MP40 8930077150 INSULATION SHEET (MJ)
MP42 8930077680 3015 PA EARTH SPRING
MP42 8930077680 3015 PA EARTH SPRING
MP42 8930077680 3015 PA EARTH SPRING
MP42 8930077680 3015 PA EARTH SPRING
MP42 8930077680 3015 PA EARTH SPRING
MP43 8930048971 SHIELD TAPE (C)-1
MP43 8930048971 SHIELD TAPE (C)-1
MP43 8930048971 SHIELD TAPE (C)-1
MP43 8930048971 SHIELD TAPE (C)-1
MP43 8930048971 SHIELD TAPE (C)-1
MP121 8930068260 THERMALLY SHEET (AV)
MP1091 8930049600 2240 IC CLIP
MP3242 8930078200 3015 IC CLIP
Screw abbreviations
MECHANICAL PARTS
DESCRIPTION
[EUR]
[FRA]
[ITR]
[ESP]
[EUR-01]
[EUR]
[FRA]
[ITR]
[ESP]
[EUR-01]
A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[FRONT UNIT] (F)
REF ORDER
QTY.
NO. NO.
SP1 2510001480 4050P0802
1
W1** 8900014720 OPC-909A
1
W2** 8900014740 OPC-885A
1
W3** 8900014740 OPC-885A
1
W4** 8900018190 OPC-1892A
1
8900018200 OPC-1941
1
1 8900018200 OPC-1941
8900018200 OPC-1941
1
8900018200 OPC-1941
1
8900018200 OPC-1941
8900018190 OPC-1892A
1
8900018190 OPC-1892A
1
8900018190 OPC-1892A
1
EP1 0880001360 EX-2500 [USA]
1
EP3 6450001230 HLJ0999-01-480 (SNAP PLATE)
1
1
1 MP1 8210024670 3015 FRONT PANEL
MP2 8310071540 3015 WINDOW PLATE
1
MP3 8830003210 3015 HEX NUT
1
1 MP4 8610013750 KNOB N-366 COVER (Incl. MP30, 31)
MP5 8610013671 KNOB N-375-1
1
MP6 8610013610 KNOB N-367 (Incl. MP29)
1
MP7 8610013621 KNOB N-368-1
1
MP8 8610013630 KNOB N-369 (Incl. MP29)
1
MP9 8610013640 KNOB N-370 (Incl. MP23)
1
MP10 8610013651 KNOB N-371-1
1
MP11 8930075120 3015 FRONT PACKING
1 MP12 8930074990 3015 17-KEY
MP13 8930075000 3015 6-KEY
1
MP14 8930074530 3015 JACK HOLDER
1
1 MP15 8930076520 3015 A-VR RUBBER
MP16 8820001490 3015 CAP SCREW
1
MP17 8930076510 3015 VR RUBBER
1
MP18 8930074540 O-RING (BU)
1
MP19 8930074350 O-RING (BW)
1
MP20 8930075160 3015 LENS
2
MP21 8010021020 3015 SUB CHASSIS
2
MP23 8610007510 KNOB SPRING NO.7800
1
5 MP24 8930069760 2914 SP NET
MP26 8930075150 3015 CONNECTOR SEAL
5
MP27 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
5
8 MP28 8810008661 SCREW BT B0 3X8 NI-ZC3 (BT)
MP29 8610007420 KNOB SPRING NO.6601
2
MP30 8610010040 KNOBN-239 FINGER REST
7
MP31 8930060190 2591 N-SPRING
7
MP32 8610010024 KNOBN-239 BASE-4
4
MP33 8930021220 SPONGE (CP)
4
MP34 8930071830 HIMELON SHEET (CS)
6
MP35 8930070300 SPONGE (JD)
2
1 MP36 8930021220 SPONGE (CP)
MP37 8930067980 SHIELD SPONGE (AS)
1
8930067980 SHIELD SPONGE (AS)
1
4 8930067980 SHIELD SPONGE (AS)
8930067980 SHIELD SPONGE (AS)
4
8930067980 SHIELD SPONGE (AS)
1
MP38 8930078390 THERMALLY SHEET (BQ)
1
MP39 8930072650 RUBBER SHEET (BX)
2
1
*: Refer to "BOARD LAYOUTS" for the location.
1
1
**: Refer to "GENERAL WIRING" for the location.
1
1
1
1
2
1
1
1
1
1
2
2
2
2
2
1
1
1
6 - 1
