SECTION 7
[CHASSIS UNIT]
REF PART
NO. NO.
J3001 6510028411 MR-DS-01-2
J3003 6510028411 MR-DS-01-2
MF3001 2710001060 FD128025HB-N (2N7R1)
W3001 8900011050 OPC-1109
W3002 8920003240 CAB-1390
W3003 8970024742 1.5D COAXIAL 65MM-2 C31/W17D PHL
W3006 8900009031 OPC-902A (P1N30L130)
W3007 8900015920 OPC-1142A (P1N16L110)
W3008 8970024752 1.5D COAXIAL 330MM-2 C31/W17D PHL
W3010 8900018134 OPC-1303B-4
W3011 8900009031 OPC-902A (P1N30L130)
W3012 8900009031 OPC-902A (P1N30L130)
W3020 8970024232 1.5D COAXIAL 390MM-2 (F/I) C31/C31
W3022 8920003300 CAB-1395
W3023 8970024083 1.5D COAXIAL 180MM-3 C31/C31
W3025 8970024442 1.5D COAXIAL 510MM-2 (B) C31/C31
EP3001 6950000710 USBC-3
MP3001 8010018824 2429 CHASSIS-4
MP3002 8110007703 2429 T-COVER-3
MP3003 8110011720 4100 B-COVER ZAM
MP3004 8110011730 4100 PA COVER ZAM
MP3005 8930057191 2429 EARTH PLATE-1
MP3006 8930057980 RUBBER REG (N) SJ-5023K
MP3007 8930102230 4100 D-SUB PLATE
MP3009 8820000530 FLANGE BOLT M4 × 8 NI
MP3011 8810010670 SET SCREW H M4 × 30 ZC3
MP3012 8810008661 PH BT M3 × 8 NI-ZC3
MP3013 8810005771 BIND M3 × 8 ZK3 BLACK
MP3014 8810009991 PH BT M3 × 8 NI-ZK3
MP3016 8930058100 2429 DC PLATE
MP3025 8810007231 SET SCREW H M3 × 8 ZC3
MP3026 8810007231 SET SCREW H M3 × 8 ZC3
MP3027 8810007231 SET SCREW H M3 × 8 ZC3
MP3028 8810007231 SET SCREW H M3 × 8 ZC3
MP3029 8930102460 4100 IC CLIP
MP3030 8930070510 THERMAL SHEET (BF) TC-600HS-1.4
[MAIN UNIT]
REF PART
NO. NO.
J4141* 6510023671 TCS4480-0141577
J4161* 6450002470 JY-3510A
J4401* 6510028210 SJ050010 (TMP-J01X-V6)
J4421* 6510028210 SJ050010 (TMP-J01X-V6)
J4701* 6510028210 SJ050010 (TMP-J01X-V6)
J5071* 6510026540 UBB-4R-D14T-4D (LF) (SN)
J5081* 6510021861 BH-800.4GG
BT5081 3020000110 CR-2032L/BK
MP4201* 8510019710 3182 PLL CASE
MP4381* 8510019800 3183 FILTER CASE
MP5181* 8510021830 3765 S-CASE
MP5241* 8510021830 3765 S-CASE
MP5282* 8510021830 3765 S-CASE
MP5421* 8510019800 3183 FILTER CASE
[CONNECT UNIT]
REF PART
NO. NO.
J7711* 6510023120 CD6109SA1J0
J7721* 6510023120 CD6109SA1J0
J7751* 6450002650 BNC-6252H7
MP7701 8930077910 2590 M2-SPRING
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless

MECHANICAL PARTS

DESCRIPTION
DESCRIPTION
DESCRIPTION
[PA UNIT]
REF PART
QTY.
NO. NO.
1 J6101* 6510028210 SJ050010 (TMP-J01X-V6)
1 J6401* 6510028210 SJ050010 (TMP-J01X-V6)
1 F6701* 5220000440 FHA040-01
F6702 5210001430 11930011 (BFLP 5A 58V)
1
1 EP6327* 6910018760 GLASS D=1.0 L=15MM
1 EP6602* 6510018330 F4053A
1 EP6603* 6510018330 F4053A
1
1
1 MP6401 8860001640 4100 RUG
1 MP6402 8860001640 4100 RUG
1 MP6403 8860001640 4100 RUG
1 MP6404 8860001640 4100 RUG
1
1
1
1
[FILTER UNIT]
REF PART
1
NO. NO.
1
1
J7001* 6510028210 SJ050010 (TMP-J01X-V6)
1
J7311* 6510028210 SJ050010 (TMP-J01X-V6)
2
J7321* 6510028210 SJ050010 (TMP-J01X-V6)
4
1
1
2
38
14
[FRONT UNIT]
4
1
REF PART
8
NO. NO.
2
1
SP8001 2510002060 057D0401
2
1
2
W8002 8910000070 FFC-1008 (P0.5N6L50)
W8003 8910000070 FFC-1008 (P0.5N6L50)
W8004 8900018000 OPC-1344A (P1N10L70)
W8005 8900015120 OPC-942B (P1N10L170)
W8006 8920003260 CAB-1380
W8007 8920001660 CAB-1174
MP8001 8210034770 3715 FRONT PANEL (D) ASSEMBLY-1
QTY. MP8003 8930092130 3715 LCD HOLDER
MP8004 8610015670 KNOB N-430 ASSEMBLY
MP8007 8610015630 KNOB N-429
1
MP8008 8930091880 3715 B-KEY (SC)
1
MP8009 8930091890 3715 F-PACKING (ORION)
1
MP8010 8930092250 3715 LCD SPONGE
1
MP8012 8510021570 3715 SHIELD CASE
1
MP8013 8930092350 3715 SP HOLDER
1
MP8014 8310084000 3570 D-COVER
1
MP8015 8930088990 3570 SHAFT
MP8016 8930089100 3570 SPRING
MP8017 8930069020 O-RING (BG)
MP8018 8810008661 PH BT M3×8 NI-ZC3
1
MP8019 8810008661 PH BT M3×8 NI-ZC3
MP8022 8930058780 2577 SHEET
MP8024 8820001180 2417 SCREW 2.6×16
1
MP8025 8930053730 O-RING (AI) (KSK)
1
MP8026 8930082360 3340 JACK CAP
1
MP8027 8930082490 O-RING (CH) (TOP)
1
MP8028 8510021640 3726 CASE ASSEMBLY
1
MP8029 8930092550 3715 A-KEY (A) (SC)
1
MP8030 8930057950 DOUBLE SIDE TAPE (AH)
MP8031 8810008661 PH BT M3×8 NI-ZC3
[LOGIC UNIT]
QTY.
REF PART
NO. NO.
1
1
DS9001 5030004580 RFE430V-AZH-DNN-000
1
1
7-1
DESCRIPTION
DESCRIPTION
DESCRIPTION
DESCRIPTION
QTY.
1
1
1
1
2
1
1
1
1
1
1
QTY.
1
1
1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
11
4
1
8
8
1
1
1
1
1
2
QTY.
1
