Excel 100 Technical Manual page 20

Excel 100 basic Technical
2. Brake Adjustment
Adjustment is made to the brake assembly by loosening the Allen key bolt heads that clamp they braking
mechanism. DO NOT alter any other fixings on the brake system. The adjustment is made by sliding the brake
unit along the frame to the suitable position. The brakes will have to be adjusted when the rear wheels have
been re positioned. Check that the contact point sufficiently brakes the wheel movement, allow for give in the
.
type of tyre that is used on the wheel
