MAKING ADJUSTMENTS TO YOUR WHEELCHAIR CAN CAUSE BIG RISKS FOR YOUR SAFETY AND THE FUNCTION OF
ADJUSTMENTS MADE BY YOURSELF ARE STRONG ADVISED AGAINST AND CARRIED OUT AT YOUR OWN RISK
ALWAYS SEEK ADVICE FROM AN APPROVED DEALER BEFORE MAKING ADJUSTMENTS

5. INSTRUCTIONS FOR USE AND OPPORTUNITIES IN YOUR WHEELCHAIR

In this chapter we will explore all the possibilities that you have with your wheelchair. All options will be discussed,
but all use instructions such as the removal of the footrest.
Your wheelchair is an Excel 100 Basic Compact ®.
All these detailed models are available in self propel and transit wheel versions, see Section 2.2 for further
explanation on this. You can find details about your wheelchair on the label on the cross brace where you can see
the exact specifications. Further on in this chapter are details about specific options referring to the different
versions.
Warning:
We advise you, if you want to make changes where tools are needed, to consult with your dealer.
5.1

Tools and technical information

For the maintenance of your wheelchair, in some cases, you need tools. For your wheelchair the following tools are
required: -
Phillips screwdriver
Allen keys
Cross-ring or keys
Spanners
Socket wrench
Excel ® 100 Basic Compact
Seat widths
Seat depths
Seat heights
Backrest height
Total width
Total length
Total height
Folded width
Weight (complete)
Transport Weight
Maximum User Weight
YOUR WHEELCHAIR
PH2
4, 5 and 6 mm
8, 10, 13 and 26 mm
19 and 22 mm
19 mm
40, 42½, 45, 50 and 55 cm
43 cm
50 cm
45 cm
17 cm + seat width
> 103 cm
> 95 cm
31 cm
17.9 kg (transit rear wheel: 17.2 kg)
9.2 kg
130 kg (150 kg in seat width 55cm)
