TM9100 P25 Mobile Radios
Installation Guide
MMA-000018-06 · Issue 6 · November 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the tm9100 p25 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tait tm9100 p25

  • Page 1 TM9100 P25 Mobile Radios Installation Guide MMA-000018-06 · Issue 6 · November 2012...
  • Page 2: Contact Information

    Tait Limited. Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this The word TAIT and the TAIT logo are trademarks of Communications Equipment. The user of this Tait Limited.
  • Page 3: Table Of Contents

    4.5 Desktop Power Supply ........35 Tait Software License Agreement ......36...
  • Page 4: Preface

    This publication is also available in French (MMA-00046-xx), Portuguese (MMA-00060-xx) and Spanish (MMA-00083-xx). Technical notes are published from time to time to describe applications for Tait products, to provide technical details not included in manuals, and to offer solutions for any problems that arise. Preface TM8100/TM8200 Installation Guide ©...
  • Page 5: Publication Record

    Installation Options section added. Minor corrections and additions. November 2012 New Tait logo 1. Technical notes are only available in PDF format from the Tait support website. Consult your nearest Tait Dealer. TM8100/TM8200 Installation Guide Preface © Tait Limited October 2012...
  • Page 6: Document Conventions

    25W: This symbol highlights information that is relevant to radios with a transmit >25W power >25W. This symbol highlights information that is relevant to radios with a transmit power of 25W. Preface TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 7: Safety And Regulatory Warnings

    MPT 1362 Code of Practice Mobile radios should be installed in accordance with the MPT 1362 Code of Practice. TM8100/TM8200 Installation Guide Safety and Regulatory Warnings © Tait Limited October 2012...
  • Page 8: Safe Radio Mounting

    Radio Installation in Gas or Fuel Tankers Special conditions must be observed when installing a radio on gas and fuel tankers. Consult your radio provider or Tait-accredited service center for more details. Safety and Regulatory Warnings TM8100/TM8200 Installation Guide ©...
  • Page 9: Vehicles Powered By Liquefied Petroleum Gas

    This is illustrated in the following diagram: 3/8 inch (10 mm) mounting surface 1.10 Negative Earth Supply The radios are designed to operate only in a negative earth system. TM8100/TM8200 Installation Guide Safety and Regulatory Warnings © Tait Limited October 2012...
  • Page 10: Preparing The U-Bracket Installation

    A TMAA03-17 installation kit (>25W radio) or TMAA03-01 >25W installation kit (25W radio), consisting of the following items: U-bracket ■ thumbscrews ■ self-drilling screws and washers ■ power cable with DC connector ■ fuses ■ Preparing the U-Bracket Installation TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 11 ■ Installation kits are also available without the U-bracket included and with Installation Kit Options other antenna connector options. Consult your nearest Tait Dealer or Customer Service Organization for more information. TM8100/TM8200 Installation Guide Preparing the U-Bracket Installation © Tait Limited October 2012...
  • Page 12: Power Source And Ignition Control

    The TMAA04-05 ignition sense kit provides a suitable mating plug for the radio’s auxiliary connector. The plug includes wiring for the the igni- tion signal and analog ground. Preparing the U-Bracket Installation TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 13: Installing The Radio

    Notice It may be necessary to mount the radio upside down to main- tain a gap of more than 3/8 inch (10 mm) for air circulation between the underside of the radio body and the mounting surface. TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 14 Use the screwdriver to lift the control head off the snap feature, then repeat in the other position. The control head can now be removed from the radio body. Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 15: Selecting The Mounting Position

    ■ installed an accessory is added which is not rated to IP54 (e.g. control-head ■ interface box or hand-held control head remote interface box) TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 16: Mounting The U-Bracket

    (not included). Caution Although an industrial-strength recloseable fastening system can be used to support the installation, for safety reasons Tait does not recommend this as a mounting option. Notice When mounting the radio on a surface, check whether the mounting screws will screw into material providing sufficient strength.
  • Page 17: Installing The Antenna

    Terminate the free end of the antenna cable with the mini-UHF plug or BNC plug (supplied) as shown in Figure 3.4. Figure 3.4 Terminating the antenna cable 5/16" 5/32" (8 mm) (4 mm) 9/16" (14 mm) TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 18: Connecting The Power Cable To The Power Source

    DC operating conditions. Note that most 24V-to-12V converters already fitted are not rated sufficiently. 1. For the 110W radio, refer to the TM9100 110W Mobile Radio Installation Guide (MMA-00039-xx). Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 19 Failure to fit the correct fuses may result in fire or damage to the radio. The correct fuse types are: >25W radios: 20A fuses (Tait IPN 265-00010-81) ■ >25W 25W radios: 10A fuses (Tait IPN 265-00010-80) ■...
  • Page 20: Connecting A Remote Speaker

    Connect the speaker to pins 2 (SPK–) and 3 (SPK+) of the power ■ connector described on page For more information, refer to the installation instructions provided with the speaker, or to the relevant section of the service manual. Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 21: Connecting To The Auxiliary Connector (Ignition Signal, Emergency Switch, External Alert Devices)21

    Some input levels of the auxiliary connector depend on how the internal hardware links are fitted (refer to Table 3.3). For more information on hardware links refer to "Hardware Links and Power-Sense Options" on page TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 22 2. For more information on hardware links refer to Table 3.4 on page 23 and to the service manual. 3. This output is protected against accidental input to the limits specified. Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 23 3. If LK 4 is in and R723 is placed, IOP GPIO7 should be driven low as well. (R723 is placed by factory default.) For more information on hardware links and power-sense options refer to the service manual. TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 24 Notice The logic thresholds for AUX GPI3 are based on 3V3 levels. However, AUX GPI3 can be connected directly to a +13.8V ignition signal (for input levels, refer to Table 3.3 on page 22). Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 25 This means that the negative side of the alert device must be connected to AUX GPIO4 and the positive side to pin 8 (+13V8 SW). The external alert device must be capable of accepting a voltage of between 10V and 18V. TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 26: Installing The Radio

    Adjust the position of the radio in the U-bracket for the best viewing angle, then tighten the thumb screws. Figure 3.6 Installing the radio in the U-bracket Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 27: Installing The Microphone

    Install the microphone clip in the most convenient location using the screws provided. The microphone must be within reach of the user but in such a position that the PTT (press-to-talk) key cannot be inadvertently activated or jammed. TM8100/TM8200 Installation Guide Installing the Radio © Tait Limited October 2012...
  • Page 28: Checking The Installation

    Notice Some antennas are pre-tuned and must not be cut. Check with the manufacturers’ instructions. Once the reflected power levels are within tolerance, make a call to another party on the radio. Installing the Radio TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 29: Installation Options

    ■ desktop power supply. ■ Some installation options may not be suitable for some models of radio. Consult your nearest Tait Dealer or Customer Service Organization for more information. TM8100/TM8200 Installation Guide Installation Options © Tait Limited October 2012...
  • Page 30: Radio Body

    The cradle is not suitable for >25W >25W radios or radios with a local graphical-display control head. Refer to the TMAA03-18/TMAA03-39 Cradle Installation Instructions (MMA-00019-xx) for full details. Installation Options TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 31: Remote Control Head

    The diagram below shows the additional parts used for this installation. Refer to the Instructions for Installing a Remote Control Head (402-00020-xx) for full details. control-head interface remote cable body interface remote U-bracket TM8100/TM8200 Installation Guide Installation Options © Tait Limited October 2012...
  • Page 32: Dual Control Heads

    ■ 6m remote cables body remote (TMAA11-17/19) ■ 12m remote cables interface (TMAA11-18/20) second control head (TMAC34) and remote interface (TMAC47) remote interface for primary control-head existing (TMAA03-03C) control head Installation Options TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 33: Hand-Held Control Head

    TMAC70 control head TMAA03-29 antenna power auxiliary connector connector remote combining interface box cable radio body ignition sense cable remote PTT remote control head remote microphone remote speaker TM8100/TM8200 Installation Guide Installation Options © Tait Limited October 2012...
  • Page 34 (No. 6 x 0.31in. (19mm)) some protection from water and dust ingress. Refer to the TMAA04-14/15/16/17 Hand-Held Control Head Extension Kits Installation Instructions (402-00067-xx) for full details. Installation Options TM8100/TM8200 Installation Guide © Tait Limited October 2012...
  • Page 35: Desktop Power Supply

    3 x screws 4 thumb screws plinth 3 x washers microphone clip U-bracket Kit 4 thumb screws TMAA03-13: >25W radios TMAA03-06: 25W radios U-bracket 2 x screws power cable microphone clip (300mm) TM8100/TM8200 Installation Guide Installation Options © Tait Limited October 2012...
  • Page 36: Tait Software License Agreement

    Software Documentation, ment") is between you (“Licensee”) and Tait whether made by Tait or another party, or any Limited (“Tait"). improvements that result from Tait processes or, By using any of the Software items embedded provision of information services.
  • Page 37: Tait Limited October

    Software is strictly prohibited. tion, provided that Licensee shall indemnify Without limiting the general nature of these Tait for all costs (including audit costs and legal restrictions, Licensee will not make the Soft- costs on a solicitor client basis) if Licensee has ware available for use by third parties on a "time...
  • Page 38 Agreement, Licensee must certify in writ- disclaims any warranty to any person other than ing to Tait that all copies of the Software have Licensee with respect to the Software or Doc- been removed or deleted from the Designated umentation.
  • Page 39 Documenta- at the option of Tait to the repair or replace- tion or Software to any country for which New ment of the Software or the refund of the pur- Zealand or any other applicable country chase price of the Software.
  • Page 40: Cable Connections

    Draft Cable Connections Terminating the Antenna Cable 5/16" 5/32" (8 mm) (4 mm) 9/16" (14 mm) For more information, refer to "Installing the Antenna" on page Power and Remote Speaker Connections >25W radio Signal Function AGND Earth return rear view SPK–...
