  • Page 1 TM9100 mobiles Tuneup info for compliance Tuneup Issue 1 August 2004...

  • Page 2: Table Of Contents

    5.7 Test Freqs tab ..........32 Tuneup © Tait Electronics Ltd August 2004...
  • Page 3 Circuit Diagram......... 39 Tuneup © Tait Electronics Ltd August 2004...

  • Page 4: General Information

    TO BLANK CONTROL HEAD) CONTROL HEAD IN-LINE CONNECTOR RADIO BODY AUXILIARY CONNECTOR RF CONNECTOR POWER CONNECTOR BNC PLUG RJ45 PLUG ADAPTOR BANANA PROGRAMMING PLUGS CONNECTOR BLANK SOCKET CONTROL HEAD DC POWER SUPPLY RADIO BODY Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 5 AUDIO IN switch AUDIO OUT switch to “TM9100”. For For servicing TM9100 radios set the SELECTOR testing receive and transmit functions respectively, the remaining switches must be set as described below. (When programming or calibrating radios the switches have no effect, although it is good practice to set the switch to “R...
  • Page 6 Figure 1.2 Illustration of the face of the test unit Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 7 Click “Start” > “Run” . The “Run” dialogue box appears. Type d:\menu.exe , where d is the letter designating the CD-ROM drive. Click the “OK” button. The “Run” dialogue box is closed and the Contents window appears. General Information Tuneup August 2004© Tait Electronics Ltd...
  • Page 8 The Contents window remains open following installation of the above applications. Investigate the remaining features of the product support CD as described below, or click the Close button to remove the window. Remove and store the product support CD. Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 9 To run the application and become familiar with its features, proceed as follows: Click “Start” > “Programs” > “Tait Programming Applications” > “TM9100 Programming Application” . The programming application is opened.
  • Page 10 To run the application and become familiar with its features, proceed as follows: Click “Start” > “Programs” > “Tait Programming Applications” > “TM9100 Calibration Application” . The calibration application is opened.
  • Page 11 ( r1 , r2 , r3 , r4 , r5 , t1 , t2 , t3 or t7 ) AUD TAP OUT and y the tap type (C=bypass out, D=split, E=splice) (the default is D when y is omitted) General Information Tuneup August 2004© Tait Electronics Ltd...
  • Page 12 Clears the last recorded system error 204 – Read system error SysErr: x Reads the last recorded system error and the associated data where x is the error number and y represents the associated data Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 13 (any integer from 0 to 3000) 378 – Receiver output level Reads the signal power at the where x is the signal power output of the channel filter (the square of the amplitude) General Information Tuneup August 2004© Tait Electronics Ltd...
  • Page 14 (a value from 0 to 1100 mV) 326 – Transmitter power None 326 x Sets the power level of the where x specifies the level transmitter (0=off, 1=very low, 2=low, 3=medium, 4=high, 5=maximum) Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 15 Table 1.1 to Table 1.5. Depending on the command, a response might or might not be displayed. If an error occurs, an error code will be displayed. Possible error codes are listed in Table 1.6. General Information Tuneup August 2004© Tait Electronics Ltd...
  • Page 16 The information conveyed by the tones is given in Table 1.8. Not all of the tones listed are relevant to the servicing of radios but they are included for the sake of completeness. Tuneup General Information August 2004© Tait Electronics Ltd...
  • Page 17 LCD will usually be flashing OL (two-digit display) or L (one-digit display) Continuous low-pitched While powered up — System error has occurred and radio might be inoperable; tone LCD usually displays E1 or E2 (two-digit display) or E (one-digit display) General Information Tuneup August 2004© Tait Electronics Ltd...

  • Page 18: Calibration Basics

    Calibration basics Tait TM9000 radios are designed to be totally electronically tuned. No physical tuning is required, as all tuning is done by electronic trimming usually in the form of a digital-to-analog converter (DAC). The calibration process uses a PC running the calibration software, which is connected to a radio via an RS232 programming cable.

  • Page 19: Using The Calibration Application

    They are typically used to select a current state. To change data in a group of option buttons: Keyboard: select an option button using the Tab key. Select the radio Calibration basics Tuneup August 2004 © Tait Electronics Ltd...

  • Page 20: Instruction Boxes

    Radio Model toolbar. Displays the frequency band in which the radio operates, as indicated by the Band sixth and seventh characters in the product code. For example, TMAB1- H600. Tuneup Calibration basics August 2004 © Tait Electronics Ltd...

  • Page 21: Viewing Calibration Test Results

    Calibration Application recognises. b. View the data on the Specifications, Deviation/Squelch, and Raw Data forms. Note The data on these forms will belong to the file opened, not the attached radio. Calibration basics Tuneup August 2004 © Tait Electronics Ltd...

  • Page 22: Calibration Tests

    RF frequencies are derived. The TCXO requires careful alignment to ensure that the transmitter and receiver are on frequency. During this test the modulation deviation is also calibrated. Tuneup Calibration tests August 2004 © Tait Electronics Ltd...

  • Page 23: Receiver

    Signal Input Level box. Do not increase it past this value, then wind the signal generator power back down; if you overshoot, you will need to repeat the test from Step 1. 8) Click the 'Calibrate' button. Calibration tests Tuneup August 2004 © Tait Electronics Ltd...

  • Page 24: Mute

    Jumping to a high DAC setting (the slider will change to red) can cause overheating and component damage. You can only force a slider into this danger zone with a deliber- ate action. See Sliders for more information. Tuneup Calibration tests August 2004 © Tait Electronics Ltd...

  • Page 25: Final Gate Bias 1

    - or as close as possible, within 10mA. (Be cautious not to raise the DAC too high or damage can occur). 4) From the toolbar, click Accept button to save changes or Reject to cancel. Calibration tests Tuneup August 2004 © Tait Electronics Ltd...

  • Page 26: Tx Power Cycle

    The Power Control test requires a total of 20 adjustments, four at each test frequency. Tuneup Calibration tests August 2004 © Tait Electronics Ltd...

  • Page 27: Deviation And Squelch Thresholds

    Each value is a percentage of the equivalent voice deviation level (Tx Peak Deviation and Rx Peak Deviation), and can be changed within certain limits above or below the default value for specific system requirements. Deviation and squelch thresholds Tuneup August 2004 © Tait Electronics Ltd...

  • Page 28: Squelch And Signalling Thresholds Tab

    Each value can be changed from 2 to 20dB for specific system requirements. However, as a guideline use a higher hysteresis value for lower opening points, and a lower hystersis value for higher opening points. Tuneup Deviation and squelch thresholds August 2004 © Tait Electronics Ltd...

  • Page 29: Advanced Tab

    A-F), and by default is set to 3B28. This value can be changed for specific system requirements. However, all transmitting and receiving radios must use the same sequence. Deviation and squelch thresholds Tuneup August 2004 © Tait Electronics Ltd...

  • Page 30: Raw Data Reference

    Rx FE Tune BPF Settings Receiver test. Each row corresponds with the equivalent frequency stated in the Rx FE Tune Cal Freq Pts grid (Test Freqs tab). Note that the Rx FE Tuneup Raw data reference August 2004 © Tait Electronics Ltd...

  • Page 31: Mute Tab

    Displays results of the Final Gate Bias 2 test (see “Final Gate Bias and Tx Final Gate Bias 2 (Very Low to Max Driver Bias Limit” on page 24). Power) Raw data reference Tuneup August 2004 © Tait Electronics Ltd...

  • Page 32: Power Tab

    PC. The thresholds are: pending high temperature shutdown, shutdown to very low power, shut off, and the hysteresis value that the radio must return to before the transmitter is re-enabled. Tuneup Raw data reference August 2004 © Tait Electronics Ltd...
  • Page 33 Raw data reference Tuneup August 2004 © Tait Electronics Ltd...

  • Page 34: Topa-Sv-024 Test Unit

    TOPA-SV-024 Test Unit The TOPA-SV-024 test unit is used to test and maintain Tait Orca portables (TOP) and TM9100 radios by providing an interface between the radio, a test PC, and an RF communications test set. The diagram below shows the front panel of the test unit.
  • Page 35 TMAA21-01 cable power microphone connector connector (RJ45) TMAA20-02 cable RF connector auxiliary programming (BNC) connector connector (DB9) (DB9) TMAA20-03 cable DC POWER SUPPLY radio without user interface banana plugs TOPA-SV-024 Test Unit Tuneup August 2004 © Tait Electronics Ltd...

  • Page 36: Top / Tm9000 Switch

    This 3-way toggle switch is used to switch between Mod Audio (Tait Orca portables only), Mic Audio, and Off (no audio signal). With the Tait Orca portables, this switch can be used for setting up dual point modulation by applying modulation to different parts of the radio.

  • Page 37: Rx / Tx/Ptt Switch

    When set to Radio, only the speaker of the Tait Orca portable is active. When set to Load, no speaker is active. The audio signal is terminated in the test unit dummy load. When set to Speaker, the speakers of the test unit and the TM9100 are TM9100 radios with user interface both active.

  • Page 38: Pcb Information (Pcb Ipn 220-01418-02A)

    Res Flm 4x1.6 560e 5% 0.4w 030-54270-20 Res Flm 4x1.6 2k7 5% 0.4w 030-52560-20 Res Flm 4x1.6 56e 5% 0.4w 030-55100-20 Res Flm 4x1.6 10k 5% 0.4w PCB Layout top side bottom side Tuneup TOPA-SV-024 Test Unit August 2004 © Tait Electronics Ltd...

  • Page 39: Circuit Diagram

    Circuit Diagram TOPA-SV-024 Test Unit Tuneup August 2004 © Tait Electronics Ltd...
