Wet Location Ceiling Fan Owner's Manual

42" Model Numbers

CF542ORB00

CF542SW00

Questions, problems, missing parts: Before returning to the store, Call Customer Service

BP7549-2 CF542 CF552 VERANDA EnSpFr.indb 1

VERANDA

- Oil Rubbed Bronze

- Satin White

1-888-757-7697

52" Model Numbers

CF552GES00

CF552GRT00

CF552ORB00

CF552SW00

- Satin White

CF552VS00

- Vintage Steel

- Golden Espresso

- Graphite

- Oil Rubbed Bronze

U.L. Model No.: CF542 & CF552

2/23/21 1:16 PM

Table of Contents

Need help?

Do you have a question about the VERANDA CF542ORB00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Emerson VERANDA CF542ORB00

Page 1 READ AND SAVE THESE INSTRUCTIONS VERANDA Wet Location Ceiling Fan Owner’s Manual 42” Model Numbers 52” Model Numbers CF552GES00 CF542ORB00 - Golden Espresso - Oil Rubbed Bronze CF552GRT00 CF542SW00 - Graphite - Satin White CF552ORB00 - Oil Rubbed Bronze CF552SW00 - Satin White CF552VS00 - Vintage Steel...
Page 2: Table Of Contents
Table of Contents Section Section Safety Instructions 8 . Maintenance 1 . Unpacking Instructions 9 . Energy Efficient Use of Ceiling Fans 2 . Electrical Requirements 10 . Repair Parts 3 . Ceiling Fan Assembly 11 . Troubleshooting 4 . How to Hang Your Ceiling Fan 5 .
Page 3: Unpacking Instructions
1. Unpacking Instructions PACKAGE CONTENTS WARNING Do not install or use fan if any part is damaged or Part Description Quantity missing. Call Toll-Free for replacement parts: 1-888-757-7697 Fan Motor Assembly Ceiling Cover Motor Coupler Cover Switch Housing Assembly Bracket Switch Housing Assembly Hanger Bracket Hanger Ball / 4.5”...
Page 4: Electrical Requirements
1. Unpacking Instructions (Continued) THIS FAN IS SUITABLE FOR WET LOCATIONS SUCH AS PORCHES, PATIOS, AND DECKS. USE ONLY WITH LIGHT KITS MARKED SUITABLE FOR USE IN WET LOCATIONS. This Manual Is Designed to Make it as Easy as Possible for You to Assemble, Install, Operate and Maintain Your Ceiling Fan Tools Needed for Assembly WARNING...
Page 5: Ceiling Fan Assembly
3. Ceiling Fan Assembly Unscrew and Discard the Five Screws and Five REMOVE AND DISCARD THE FIVE SHIPPING RETAINERS AND SCREWS Shipping Retainers from the Motor Hub (Figure 1) . FROM THE MOTOR HUB Figure 1 M5 x 6mm WASHER Mount Flanges to Fan Blades using Three M5 x 6mm HEAD BLADE SCREW Washer Head Blade Screws (supplied in parts bag)
Page 6 3. Ceiling Fan Assembly The Flanges have an Interlocking feature that must be BLADE/FLANGE fully engaged before tightening the M6 x 14mm Captive ASSEMBLY Pan Head Screws (Figure 4) . If one of the Flanges does not seat properly on the Motor Hub, loosen the adjacent M6 x 14mm Captive Pan Head Screw, re-engage and reseat the Flanges, then tighten the M6 x 14mm Captive Pan Head Screw...
Page 7 3. Ceiling Fan Assembly (continued) REINSTALL & TIGHTEN ONE M4 x 10mm SERRATED PAN Position the Switch Housing Assembly Bracket on the HEAD SCREW Adapter Plate so that the Two Screws mate with the Two Switch Housing Assembly Bracket Keyhole Slots ROTATE SWITCH HOUSING ASSEMBLY BRACKET CLOCKWISE TO ENGAGE with Rubber Cover .
Page 8 3. Ceiling Fan Assembly (continued) Remove and retain the Three M4 x 12mm Flat Head Screws from the Switch Housing Assembly Bracket (Figure 8) . SWITCH HOUSING ASSEMBLY BRACKET REMOVE AND RETAIN M4 x 12mm FLAT HEAD SCREWS (3) Figure 8 SWITCH Carefully tuck all Wires and Connectors under the HOUSING...
Page 9 3. Ceiling Fan Assembly (continued) 3.10 Carefully turn and place the partially assembled Ceiling Fan right side up, on the styrofoam being careful not to bend the Ceiling Fan Blades (Figure 10) . Figure 10 3.11 GREEN GROUND WIRE Remove the Hanger Ball from the 4 .5” Downrod by loosening the Set Screw in the Hanger Ball until the Ball falls freely down the Downrod (Figure 11) .
Page 10 3. Ceiling Fan Assembly (continued) DOWNROD LOOSEN SET SCREWS (2) MOTOR COUPLER Figure 13 3.14 HAIRPIN Install the Clevis Pin and secure with the Hairpin Clip CLIP (Figure 14) . CLEVIS CLEVIS PIN The Clevis Pin must go through the Motor Coupler Holes .
Page 11 3. Ceiling Fan Assembly (continued) 3.15 While pulling up on the 4 .5” Downrod, retighten the Two Set Screws (previously loosened) in the Motor Coupler to secure the Downrod into place (Figure 15) . NOTE: The set screws must be properly installed as RETIGHTEN TWO MOTOR PHILLIPS HEAD...
Page 12 3. Ceiling Fan Assembly (continued) 3.18 Route the Three 80” Motor Wires through the Hanger Ball . DOWNROD Reinstall the Hanger Ball (Figure 18) on the Downrod HANGER BALL PIN HANGER BALL as follows: HANGER BALL CEILING GROOVE COVER Position the Hanger Ball Pin through the two Holes in the Downrod and align the Ball so the Pin is captured in the Groove in the top of the Hanger Ball .
Page 13: How To Hang Your Ceiling Fan
4. How to Hang Your Ceiling Fan CAUTION CEILING To reduce the risk of injury, install the fan so that the blades are at least 7 ft. (2.1m) above the floor (Figure 20). WARNING The outlet box and joist must be securely mounted and capable of supporting at least 50 lbs.
Page 14 4. How to Hang Your Ceiling Fan (continued) NOTE: CEILING COVER, SUPPL Y WIRES AND FAN WIRES OMITTED FOR CLARITY. Carefully lift the Fan and seat the Hanger Ball/ Downrod Assembly into the Hanger Bracket that was just attached to the Outlet Box (Figure 22) . Be sure the Groove in the Ball is lined up with OUTLET Anti-Rotation Tab on the Hanger Bracket (Figure 22) .
Page 15: How To Wire Your Ceiling Fan
5. How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. GROUND CONDUCTOR SUPPLY WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box or circuit breaker LISTED WIRE panel before wiring.
Page 16 5. How to Wire Your Ceiling Fan (Continued) Securely connect the Fan Motor Black Wire and Blue Wire to the Supply Black (hot) Wire using Wire Connector (supplied) (Figure 25) . SUPPLY BLACK (HOT) LISTED WIRE CONNECTOR FAN MOTOR BLACK WIRE FAN MOTOR BLUE WIRE Figure 25 After Connections have been made, turn Wires upward...
Page 17: Final Assembly
6. Final Assembly Screw the Two Threaded Studs (supplied) into the Tapped Holes in the Hanger Bracket (Figure 27) . THREADED STUDS (2) Figure 27 NOTE: SUPPLY WIRES AND FAN WIRES OMITTED FOR CLARITY. Lift the Ceiling Cover up to the Threaded Studs and turn until Studs protrude through the Holes in the Ceiling Cover (Figure 28) .
Page 18: Using Your Ceiling Fan
7. Using Your Ceiling Fan Restore Electrical Power to the Outlet Box by turning the Electricity on at the Main Fuse Box or Circuit Breaker Panel . During Summer Months, run the Fan Counter- Clockwise, as you look up at it, to direct airflow downward .
Page 19: Maintenance
8. Maintenance IMPORTANT CARE INSTRUCTIONS WARNING for your Ceiling Fan Do not use water when cleaning your ceiling fan. Periodic cleaning of your new ceiling fan is the only It could damage the motor or the blades and create the maintenance that is needed .
Page 20: Repair Parts
10. Repair Parts PARTS BAG BP7549-2 CF542 CF552 VERANDA EnSpFr.indb 20 BP7549-2 CF542 CF552 VERANDA EnSpFr.indb 20 2/23/21 1:16 PM 2/23/21 1:16 PM...
Page 21: Troubleshooting
11. Troubleshooting WARNING FOR YOUR OWN SAFETY TURN OFF POWER AT MAIN FUSE BOX OR CIRCUIT BREAKER PANEL BEFORE TROUBLESHOOTING YOUR FAN. TROUBLE PROBABLE CAUSE SUGGESTED REMEDY 1. Fan will not start. 1 . Fuse or circuit breaker blown . 1 .
Page 22 SERIAL NUMBER: DATE CODE: The serial number of this fan can be found on the nameplate on top of the fan housing . The date code can be found on the carton and on top of the fan housing, stamped in ink on a white label . You should record this data above and keep it in a safe place for future use .
