Declaration of Conformity

COLORTRAC IMAGING SYSTEM (SUZHOU) CO LTD
#39 DONGJING INDUSTRIAL ZONE, #9 DONGFU RD,
SUZHOU INDUSTRIAL PARK, SUZHOU,
JIANGSU, 215123 CHINA
Model name:
Function:
Rating voltage:
Rating current:

Power supply:

Approvals applied for:
Warning:
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
In-the-box
Scan System
Scan software
Optical Resolution
DocLogic
Max Scan Width
Max Image Length
Min Media Width / Thickness
Max Media Width / Thickness
Paper sizing (image sizes)
Internal memory
Scan Accuracy
SingleSensor
digital imaging technology
Operation modes
Color space
Scan speeds (maximum at 200 dpi)
Paper Path
Data interfaces
Power Requirements
Environment
Weight & Dimensions (WxHxD)
Host Platform
Certifications
Warranty
.
DOCUMENT NO 88N001D
SmartLF Scan! 24, SmartLF Scan! 36
Large Format Scanner
19V
3.42A
FSP065-REBXX
(X=0-9, A-Z or Blank)
Energy Star, CB, CE, FCC, UL, CuL, VCCI, C-Tick, CCC,
BIS, KCC, EAC, BSMI, RoHS, LVD
SmartLF Scan! 24
TIFF and PDF files are generated inside the scanner. They can be
3 - transferred via wired Ethernet, direct to a network or PC.
When connected to a PC, additional black and white binary files are available.
SmartLF Scan! is self-contained and only requires a power supply to operate.
Scan formats are viewable using native Windows Apps. A small Windows program is supplied to receive live or stored scan files
from the scanner. This is not required for scan to USB stick operation.
automatically sets dpi of document or photos according to physical size to maximise image quality and reduce file size
24" (609.6 mm)
6.2" (160mm) / 0.003" (0.07 mm)
26" (660mm) / 0.02" (0.5 mm)
ISO DIN / ARCH / ANSI / automatic width and length
SingleSensor is a full width straight-line contact image sensor (US patent #8,922,849)
Bi-directional long-life LED light system for optimum object illumination and instant-on scanning capability
scan to internal memory / scan to USB stick (not supplied) / scan to networked computer
24-bit sRGB and grayscale (plus bitonal using the pc connection)
4.5 inch/sec (114.3mm/sec) grayscale and 3 in/sec (76.2mm/sec) for color.
Front: USB2 socket for scan to USB memory stick.
Rear: Ethernet RJ45 GBit for scan to computer over network
External power supply Input: 100~240VAC, 50-60Hz, auto-sensing +/-10%, Output: 3.42A at 19V,
Scanner power consumption: 19.4 W (scanning), 10.2W (standby), 0.05W (sleep). Energy Star qualified
Operating temperature 10
Scanner only 11.5 lbs (5.2 kg) / 34.3 x 6.3 x 5 inches
(870 x 160 x 126 mm)
Scanner incl. case: 22.3 lbs (10.1 kg) / 38.6 x 10.4 x 8.2
inches (980 x 265 x 208 mm)
Windows 10, Windows 8, Windows 7, 32-bit and 64-bit architectures
ENERGY STAR qualified, CB, CE, CCC, FCC, UL, RoHS compliant
Scan! large format scanner
Tough wheeled carry case
Mains external power supply
Calibration target
RJ45 Ethernet cable
Three modes of operation.
1 - stored in the scanner for transfer to a PC later
2 - stored directly on a USB stick
600 dpi
intelligent image optimisation system
50" (1270mm)
approx. 6 GB or 8 scans
0.2 % +/-1 pixel
Centered, face-up, front entry
o o
C – 35 C, Relative Humidity 10% – 90% (non-condensing)
Scanner only 15.4 lbs (7 kg) / 46.3 x 6.3 x 5 inches (1175 x
Scanner incl. case: 30.9 lbs (14 kg) / 50.4 x 10.4 x 8.2 inches
12 months or 30,000 linear scan metres
SmartLF Scan! 36
36" (914.4 mm)
6" (150 mm) / 0.003" (0.07 mm)
38" (965 mm) / 0.02" (0.5 mm)
160 x 126 mm)
(1280 x 265 x 208 mm)
Colortrac Ltd © 2015
