Brickcom NR-2008 User Manual page 8

Name
1.Display the IP address and current
1 LCD
time;
2.Display the external alarm channel
and show error code of the NVR
"E××"
3.display the remote address;
4.display internal temperature of the
chassis
2 IR It is to receive the signal from the remote control.
3 Esc Go to previous menu, or cancel current operation
1. Shift current activated control.
Up/Down
4 Direction
Left/Right
1. Confirm current operation.
5 Enter 2. Go to default button.
3. Go to menu.
One-window monitor mode, click this button to display assistant function: PTZ control and image
color.
Simultaneously press the Fn key and the direction key to complete the settings with the dynamic
monitoring area.
6 Fn Backspace function: in numeral control or text control, press it for 1.5seconds to delete the previous
character before the cursor. In text mode, click it to switch between numeral, English
character(small/capitalized) and etc.
Playback mode, click this button to switch full-screen window.
Realize other special functions.
7 USB To connect USB storage device, USB mouse and etc.
8 Power Power button, press this button for three seconds to boot up or shut down NVR.
Function
1 2
Network
Connecti
on status
1. Increase/decrease numeral.
2. Assistant function such as PTZ menu.
1. Assistant function such as PTZ menu.
2. When playback, click these buttons to control playback bar
7
www.brickcom.com.tw
1
2
3
4
3
1. Display HDD
1. Cycling display the
status and numbers.
recording status
2. "E" and flash
(Distinguish
label refer HDD
"REC" and "MOVE").
error.
4
