Brickcom NR-2008 User Manual page 11

Confirm/Menu Key
ESC
Direction Key
Previous record/Iris-
Next record/Iris+
Forward 5sec
Reverse 5sec
Slow Play
Forward
Stop
Play/Pause
The procedures of controlling multiple NVR by remote control:
The NVR ID default is 8. It's no need to reset it when control one single NVR by the remote control. If you need to
control multiple NVR, do as below:
First activate the remote control: choose controlled NVR, starts successfully, aim the remote control to control the
hard disk video recorder, press the "Add" button, input device ID) between (1-999), then press ENTER to determine
can control the corresponding number of hard disk video recorder.
and direction keys to realize setup;
3. In text mode, click it to delete the character before the caret(if there is
no shift on the front panel, it can switch input methods), press this button
for 1.5sec to clear all of the characters;
4. In playback mode, switch the full screen;
5. Realize other special functions.
1. Confirm current operation;
Menu/Menu 2. Go to OK button;
3. Go to menu.
ESC Go to previous menu, or cancel current operation.
1.Assistant function such as PTZ menu;
2.In monitor mode, switch between multiple-window and one-window;
3. Activate the digital input box increase or decrease the number;
4.Active pull-down menu to switch the drop-down box options;
/
5. Activate checkbox to change status;
6. Activate the text input box and step down carry and abdication;
7. Activate the control box to move the slider;
8. Activate display window to select the previous channel, next channel.
1. Shift current activated control, and then move left and right;
2. In monitor mode, switch channel;
/
3. Assistant function such as PTZ menu.
1.In playback mode, playback the previous video;
2. In PTZ mode, Iris-.
1.In playback mode, playback the next video;
2. In PTZ mode, Iris+.
In playback mode, forward 5sec.
In playback mode, reverse 5sec.
Multiple slow play speeds or normal playback.
Various forward speeds and normal speed playback.
■
In normal playback click this button to stop playback.
1. Go to SEARCH interface;
2. In PTZ channel: ZOOM+;
3. In normal playback click this button to pause playback;
4. In pause mode, click this button to resume playback.
