Diagram 14-50
All the channel information is listed in the task subitem, like the device, channel, camera ID, stop duration (10-
3600s), preset (1-128) and stream. On the contrary, click to cancel the channel from tasks.
New: add a new task
Modify: modify the task configuration
Stay time: the default is 20 seconds. Double left click to modify the time between 10-3600 seconds.
Preset: double left click to add preset number
Save: save the configuration
Cancel: cancel the select item
Exit: quit this window
Introduction:
1. There are maximum 100 devices in one task
2. Select a node to add all devices in this node into the task
3. Modify one stay time and apply this time to all in context menu
14.5.2 PLAN CONFIG
"Diagram 14-51" is the [Plan Config] interface. Click "Add" and modify the plan parameter like title, task start/end
