  • Page 1 Digital Discussion System CCS 1000 D Operation manual...

  • Page 3: Table Of Contents

    Discussion Device 7.3.1 Configure Discussion Device 7.3.2 Initialize Discussion Device 7.3.3 Erase address Web browser interface 7.4.1 First use configuration 7.4.2 Login 7.4.3 Manage discussion 7.4.4 Prepare discussion 7.4.5 Manage recorder Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 4 10.1 Cleaning 10.2 Inspect components 10.3 Storage Technical data 11.1 Control Unit 11.2 Discussion Device 11.3 Extension Unit 11.4 Safety compliance 11.4.1 Control Units 11.4.2 Discussion Devices 11.4.3 Extension Unit 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 5: Safety

    (in accordance with the European Waste Electrical and Electronic Equipment Directive). To dispose of old electrical or electronic devices, you should use the return and collection systems put in place in the country concerned. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 6: About This Manual

    This manual is available as a digital document in the Adobe Portable Document Format (PDF). Refer to the product related information at: www.boschsecurity.com. Intended audience This manual is intended for installers, technicians and users of a CCS 1000 D Digital Discussion System. Alerts and notice signs Four types of signs can be used in this manual.

  • Page 7: Document History

    V2.0 New sections added: 3.4, 4.2.1, 4.2.2, 4.2.3, 4.5.1, 4.5.2, 4.5.3, 6.4, 7.1.2, 7.2, 7.3.2, 7.3.3, 7.4.1, 7.5, 11.3 Sections updated: 2.6, 3, 6.1, 6.2, 7.4.2, 7.4.4, 7.4.6, 8.1, 9.1 Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 8: System Overview

    | System overview Digital Discussion System System overview HD-SDI Figure 3.1: Typical system setup 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 9 Digital Discussion System System overview | en The CCS 1000 D Digital Discussion System is a hot plug‑and‑play conferencing system that is ideally suited for small to medium‑sized meeting areas, such as town halls, local business centers, and courtrooms. The main components of the discussion system are: Control Unit: there are two types of control unit: the CCSD‑CU and the CCSD‑CURD.

  • Page 10: Ccsd-Cu(Rd) Control Unit

    CCSD-CU(RD) Control Unit Figure 3.2: CCSD‑CU Figure 3.3: CCSD‑CURD The Control Unit is the central component of the CCS 1000 D Digital Discussion System. Its main purpose is to: – provide an interface for connecting Discussion Devices and peripheral equipment.

  • Page 11: Discussion Device

    CCS 1000 D Digital Discussion System. One or more Extension Units can be used to expand the CCS 1000 D Digital Discussion System up to 245 Discussion Devices. A single Extension Unit can provide power for up to 85 additional Discussion Devices (CCSD‑DS or CCSD‑DL).

  • Page 12: Planning

    Digital Discussion System Planning Before using the CCS 1000 D Digital Discussion System, read this section to make sure you have all components for connecting and operating the system. This section also includes important information on the number of Discussion Devices that can be connected to the system.

  • Page 13: Additional Components

    Digital Discussion System Planning | en Additional components The following additional components can be used with the CCS 1000 D Digital Discussion System, as required: LBB 4116 Series Extension Cables – These standard length extension cables can be connected to components in the daisy‑chain. If you want to add one or more extension cables...
  • Page 14 LBB 4116/00 roll of cable. DCN‑DISCLM Cable Clamps (25 pcs) – This cable clamp can be used to secure the connector of a Discussion Device to the next Discussion Device in the daisy chain. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 15 Control Unit. Wireless Access Point (WAP) - A commercially available wireless access point or router is required if you want to connect equipment with a WiFi connection to the system. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 16: Making Custom Extension Cables

    Figure 4.2: Plug and socket pin numbers Figure 4.3: Extension cable connections Signal Color Downlink GND Downlink data Green +24 V(DC) Brown Uplink data White Uplink GND +24 V(DC) Blue Table 4.1: Extension cable connections 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 17: Setup Options And Limits

    Digital Discussion System Planning | en Setup options and limits This section describes the setup options and limits for the CCS 1000 D Digital Discussion System. The following example system setups are described: – A small/medium sized system that has a Control Unit, and a maximum of 80 Discussion Devices.

  • Page 18: Large System (Max. 245 Discussion Devices)

    (including the first 20 m (66.0 ft) of extension cable) + the Discussion Device cables of 2 m (6.6 ft) per device. + the Extension Unit cables. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 19 Discussion Devices (245) connected to the system. Figure 4.5: Example setup for a large system (max. 245 Discussion Devices) Control Unit Extension cable 20 m (66.0 ft) long Extension Unit Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 20: Extension Cables

    56 m to 58 m 58 m to 60 m 60 m to 62 m 62 m to 64 m 64 m to 66 m 66 m to 68 m 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 21 84 m to 86 m 86 m to 88 m 88 m to 90 m Table 4.2: Max. number of components per trunk/tap-off depending on total length of extension cable(s) Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 22 Figure 4.6: Example setup for a large system with 35 m of extension cable connected to the trunk and each tap-off Control Unit Extension cable 35 m (115.0 ft) long Extension Unit 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 23: Installation

    – keep the mounting brackets and screws in case you want to install the unit(s) in a rack in the future. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 24: Connections

    Discussion Device – the Extension Unit Connect system components Figure 6.1: Connecting Discussion Devices For detailed information on the connections of the CCS 1000 D Digital Discussion System, refer to: – Control Unit connections, page 26 – Extension Unit connections, page 29 –...
  • Page 25 Digital Discussion System Connections | en If you want to use the web browser interface or system cameras with the CCS 1000 D Digital Discussion System, connect an RJ45 Ethernet cable to the ‘Network’ connector at the rear of the Control Unit.

  • Page 26: Control Unit Connections

    See Audio under the heading System settings, page 45. RCA ‘Audio In (1)’ Audio input connector for ‘Floor’, i.e. for connecting an external audio source, such as a CD or DVD player. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 27 RJ45 Ethernet socket for connecting a network cable. The Ethernet port is intended to connect a laptop or PC, IP camera’s and other equipment which is solely used to operate the CCS 1000 D system. Power 24V 6A 4‑pole circular female connector for connecting the 24 VDC power supply.

  • Page 28: Discussion Device Connections

    Trunk connection 6‑pole circular female connector for connecting the next component in the daisy-chain. This can be: – another Discussion Device, – an Extension Unit, or – an extension cable. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 29: Extension Unit Connections

    Power 24V 6A 4‑pole circular female connector for connecting the 24 VDC power supply. Caution! Non-approved power supplies can damage the equipment. Only use the original Bosch supplied 24 VDC power supply. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 30: Configuration

    | Configuration Digital Discussion System Configuration To configure the CCS 1000 D Digital Discussion System you can use: – the touch buttons on the front of the control unit, or – the web browser interface. For more information, see Web browser interface, page 38.
  • Page 31 5 to 10 open microphones: a combination of LEDs are lit to show the number of open microphones; for example, if there are six open microphones, LED numbers 2 and 4 are lit. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 32 USB memory stick requirements, see Additional components, page Headphone socket 3.5 mm (0.14 inch) stereo headphone socket for connecting (CCSD‑CURD only) headphones (for listening to recorded discussions). When headphones are connected, the built‑in loudspeaker is muted. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 33: Discussion Modes

    The speakers list can be (viewed and) managed in the web browser interface. The waiting list is not used in this mode. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 34: Key Combinations

    Resets all system settings and values to the factory defaults. Notice! When the system is reset to the factory defaults, the latest version of the software that the system was upgraded to will be maintained. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 35: Extension Unit

    The Extension Unit is switched on and off automatically with the Control Unit. Number Item Description Power on/off LED LED indicator for showing the on/off status – Red: Power off or standby. – Green: Power on. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 36: Discussion Device

    (store the single button in a safe place). Preposition and then gently press the chairperson’s priority button (3) and microphone button (4) into place. Do not use excessive force! 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 37: Initialize Discussion Device

    The LED indicator above the microphone button is lit amber. Initialize the device as described in Initialize Discussion Device, page 37. Figure 7.4: Base view Concealed initialization button. Slide‑switch for configuring. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 38: Web Browser Interface

    Web browser interface This section describes how to configure the web browser interface. 7.4.1 First use configuration The web browser interface of the CCS 1000 D Digital Discussion System is used to: – upgrade the system software. – configure the CCS 1000 D Digital Discussion System.

  • Page 39: Login

    Figure 7.5: Homepage (CCSD‑CURD) Notice! Some web browser interface options may not be available for the CCSD‑CU, because this version of the Control Unit does not have DAFS and recording functionality. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 40 Control Unit and web browser interface application. See System info, page 51. System info Exits the discussion application and returns you to None the login page. See Logout, page 51. Logout 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 41 Manage meeting recording. Stop recording (CCSD‑CURD only) Opens the master volume control slider. Controls Configure or Manage the discussion devices loudspeaker and Control meeting Unit audio output level. Master volume Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 42: Manage Discussion

    – Recording and playing back discussion, page 53. Master volume control Click the master volume control button to adjust the audio output level of the Discussion Devices and Control Unit. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 43: Prepare Discussion

    Discussion Device priority button is used. – Stop all speakers and remove all waiting participants: When selected all speakers and requests are cancelled when the Discussion Device priority button is used. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 44: Manage Recorder

    Recycle bin button (Only visible when a file is selected): Deletes the selected file from the used memory and overview. Note: For more information on recording and playing back audio files, refer to Recording and playing back discussion, page 53. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 45: System Settings

    44. – Prepare meeting: This right gives access to the prepare discussion pages. Refer to Prepare discussion, page 43. – Modify users: This right gives access to the users page. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 46 Overview camera: Sets the camera used as the overview camera. SDI Switcher: Enter the IP address of the HD‑SDI video switcher. Do not use leading zeros. If leading zeros are entered, the CCS 1000 D Digital Discussion System will not be able to control the switcher.
  • Page 47 – Input: The video switcher input that the camera is connected to. A total of 6 cameras can be connected to the CCS 1000 D Digital Discussion System. Notice! Ensure that the Bosch Onvif Camera has firmware 5.80 or higher.
  • Page 48 Selection mode (select on Discussion Devices): When selected, a Discussion Device can be located by selecting the seat in the list or by pushing the Discussion Device microphone request button. The Discussion Device LEDs are illuminated. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 49 Click the Date and time button to open the date and time settings page. Click the Change date and time settings button to select: – Time: Select the local time. – Date: Select the current date. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 50 Exit the upgrade page after completion of the upload process (‘done’state). Clear the browser cache (history), so that the new functionality is displayed in the web browser. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 51: Power

    Software version (build) System info is used by a technician. 7.4.10 Logout Click the Logout button on the homepage to log out from the discussion application. The login page is displayed. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 52: Restful Application Program Interface (Api)

    Digital Discussion System RESTful Application Program Interface (API) The CCS 1000 D Digital Discussion System has a RESTful API that has the following functions: Note: A RESTful API is an Application Program Interface that uses HTTP requests to GET, PUT, POST and DELETE data.

  • Page 53: Operation

    Digital Discussion System Operation | en Operation This section describes how to operate the CCS 1000 D Digital Discussion System. Recording and playing back discussion 13 14 Figure 8.1: CCSD‑CURD The built‑in recorder is used to record discussions in the MP3 format. Recordings are saved to the internal memory or an appropriate USB memory stick, when connected.
  • Page 54 USB connector at the rear of the Control Unit. Notice! Recordings cannot take place when the Control Unit is connected to a PC with the micro USB connector. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 55: Using The Microphone Button

    As soon as the active speaker disables their microphone button you will be allowed to speak. – Your microphone is active; you are allowed to speak. All LEDS off – The device is off. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 56: Using The Priority Button

    Adjusting headphones volume Figure 8.4: Device with chairperson‘s button fitted Use the rotary thumbwheel (3) on the side of the device to adjust the volume of the headphones, when connected. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 57: Troubleshooting

    Digital Discussion System Troubleshooting | en Troubleshooting Use the following Troubleshooting table to troubleshoot the CCS 1000 D Digital Discussion System. Troubleshooting table Problem Possible cause Possible solution No sound from loudspeakers Loudspeaker volume too low. Use the volume control of all Discussion Devices.
  • Page 58 Discussion Device to either participant’s device incorrectly set. or chairperson’s device. See Discussion Device, page 36. The configuration mode can be set in the Seats page of the web browser interface. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 59 LED indicator: Red/green flashing indicates that the internal memory is full. – Connect the USB memory stick to a PC, and transfer the files to a hard disk if necessary. Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 60 – For the Kramer MV‑6 switcher, set the TCP connection port number to 5000. – For the tvOne CORIOmatrix switcher, set the TCP connection port number to 10001. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 61: Maintenance

    10.3 Storage If you do not intend to use the CCS 1000 D Digital Discussion System for a while: Disconnect the 24 VDC power supply from the mains and from the rear of the Control Unit.

  • Page 62: Technical Data

    | Technical data Digital Discussion System Technical data This section contains the technical specifications of the CCS 1000 D Digital Discussion System. 11.1 Control Unit Electrical Supply voltage Adaptor 100 to 240 VAC, 50/60 Hz Current Consumption voltage Adaptor 1.9 A (100 VAC) to 1 A 240 (VAC)
  • Page 63 45 x 440 x 200 mm (1.8 x 17.3 x 7.9 in) 19” wide, 1 RU high Height of feet 5.5 mm (0.2 in) Mounting Tabletop or 19 “ rack Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 64: Discussion Device

    Height with microphone in horizontal position 130 mm (5.1 in) Length of microphone from mounting surface CCSD‑DS: 310 mm (12.2 in) CCSD‑DL: 480 mm (18.9 in) Weight Approx. 1 kg (2.2 lb) 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
  • Page 65 (+32 ºF to +95 ºF) Storage and transport temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF) Relative humidity 5% to 98% non-condensing Air pressure 600 to 1100 hPa Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...

  • Page 66: Extension Unit

    5 ºC to +45 ºC (+41 ºF to +113 ºF) Storage and transport temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF) Relative humidity 5% to 98% non-condensing 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.

  • Page 67: Safety Compliance

    Only applicable for the power adaptor. 11.4.2 Discussion Devices CE, WEEE ICES-003 AU/NZ RU/KZ/BY China RoHS SASO 11.4.3 Extension Unit CE, WEEE UL, FCC CSA, ICES-003, EPS KCC, KC , K-MEPS Bosch Security Systems B.V. Operation manual 2016.05 | V2.0 |...
  • Page 68 | Technical data Digital Discussion System AU/NZ RCM, MEPS RU/KZ/BY China RoHS, CCC BSMI SASO Note: Only applicable for the power adaptor. 2016.05 | V2.0 | Operation manual Bosch Security Systems B.V.
