Digital Discussion System
CCS 1000 D
en
System manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCS 1000 D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bosch CCS 1000 D

Summary of Contents for Bosch CCS 1000 D

  • Page 1 Digital Discussion System CCS 1000 D System manual...

  • Page 3: Table Of Contents

    Flush devices connections Extension Unit connections Configuration Control Unit 7.1.1 Discussion modes 7.1.2 Key combinations Discussion Device 7.2.1 Configure Discussion Device 7.2.2 Initialize Discussion Device 7.2.3 Erase address Flush devices Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 4 Troubleshooting Troubleshooting table Maintenance 10.1 Cleaning 10.2 Inspect components 10.3 Storage Technical data 11.1 Control Unit 11.2 Discussion Device 11.3 Flush devices 11.4 Extension Unit Support services and Bosch Academy 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 5: Safety

    Security advisories, that is a list of identified vulnerabilities and proposed solutions: https://www.boschsecurity.com/xc/en/support/product-security/security- advisories.html Bosch assumes no liability whatsoever for any damage caused by operating its products with outdated software components. FCC Supplier’s Declaration of Conformity The following statement is valid for: –...
  • Page 6 - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 7: About This Manual

    For information on getting permission for reprints and excerpts, contact Bosch Security Systems B.V.. The content and illustrations are subject to change without prior notice.

  • Page 8: Document History

    Sections added or updated due to the inclusion of the flush chairperson and discussion devices: – Delivered with products – Extension cables – Installation – Connections – Configuration – Technical data – Safety compliance 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 9: System Overview

    10. Wireless access point/router: used in combination with a wireless tablet device. 11. Tablet device: can be used to manage discussions, prepare discussions, and configure the system. 12. HD Conference Dome: captures the image of a speaking participant. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 10: Ccsd-Cu(Rd) Control Unit

    Built‑in loudspeaker and headphone socket with volume control for listening to the ‘floor language’ or recordings. – Additional RCA outputs for individual microphone recording, e.g. for recording individual speakers in a courtroom. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 11: Discussion Device

    A device can be configured as either a ‘participant device’ or a ‘chairperson device’, which enables a user to function as the chairperson at a meeting. See Configure Discussion Device, page 40. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 12: Flush Discussion Device

    System up to 245 Discussion Devices. A single Extension Unit can provide power for up to 85 additional Discussion Devices (CCSD‑DS or CCSD‑DL). The Extension Unit is switched on and off automatically with the Control Unit. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 13: Gui Languages

    • Security measures The owner and/or installer must take care of the security measures to prevent the improper use of the CCS 1000 D system through the Internet and the local networks. Consider the following items to increase security: –...

  • Page 14: Planning

    Unpacking This equipment should be unpacked and handled with care. If an item appears to be damaged, notify the shipper immediately. If any items are missing, notify your Bosch representative. The original packaging is the safest container in which to transport products and can be used to return products for service if necessary.

  • Page 15: Ccsd-Exu Extension Unit

    LBB 4116/02 2 m (6.6 ft) LBB 4116/05 5 m (16.0 ft) LBB 4116/10 10 m (33.0 ft) LBB 4116/15 15 m (49.2 ft) LBB 4116/20 20 m (66.0 ft) LBB 4116/25 25 m (82.0 ft) Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 16 RJ45 Ethernet cable - An RJ45 Ethernet cable is required if you want to connect a laptop or PC to the control unit for running the web browser interface and connecting system cameras. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 17 Control Unit. Wireless Access Point (WAP) - A commercially available wireless access point or router is required if you want to connect equipment with a WiFi connection to the system. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 18: Making Custom Extension Cables

    Figure 4.2: Plug and socket pin numbers Figure 4.3: Extension cable connections Signal Color Downlink GND Downlink data Green +24 V(DC) Brown Uplink data White Uplink GND +24 V(DC) Blue Table 4.1: Extension cable connections 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 19: Setup Options And Limits

    Control Unit: 40 + 40 = 80 Discussion Devices. Figure 4.4: Example setup for a small/medium sized system (max. 80 discussion devices) Control Unit Extension cable 20 m (66.0 ft) long connected to each trunk of the Control Unit Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 20: Large System (Max. 245 Discussion Devices)

    Limit 6: The maximum cable length for a trunk/tap-off is 100 m (328.0 ft). This includes all extension cables (including the first 20 m (66.0 ft) of extension cable) + the Discussion Device cables of 2 m (6.6 ft) per device. + the Extension Unit cables. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 21 Discussion Devices (245) connected to the system. Figure 4.5: Example setup for a large system (max. 245 Discussion Devices) Control Unit Extension cable 20 m (66.0 ft) long Extension Unit Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 22: Extension Cables

    56 m to 58 m 58 m to 60 m 60 m to 62 m 62 m to 64 m 64 m to 66 m 66 m to 68 m 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 23 32 m to 34 m 34 m to 36 m 36 m to 38 m 38 m to 40 m 40 m to 42 m 42 m to 44 m 44 m to 46 m 46 m to 48 m 48 m to 50 m 50 m to 52 m Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 24 60 m to 62 m 62 m to 64 m 64 m to 66 m 66 m to 68 m 68 m to 70 m 70 m to 72 m 72 m to 74 m 74 m to 76 m 76 m to 78 m 78 m to 80 m 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 25 Extension Units + 29 Discussion Devices = 32 components. Figure 4.6: Example setup for a large system with 35 m of extension cable connected to the trunk and each tap-off Control Unit Extension cable 35 m (115.0 ft) long Extension Unit Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 26: Installation

    Following the template, drill the four pilot holes for the screws with a Torx T10 screwdriver. Note: The maximum thickness of the table is 40 mm. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 27 Installation | en [mm] Cut the table according to the marks. For better results, use the Bosch jigsaw GST 650 equipped with the blades T 119 BO or T 144 D. Insert the device into the table. Make sure the cable remains within the cut space and below the table.
  • Page 28 The use of a cable clamp is optional. If you chose to install a cable clamp, secure the DCN‑DISCLM around the connector. For details, refer to Flush devices connections, page 33. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 29: Connections

    Digital Discussion System, connect an RJ45 Ethernet cable to the ‘Network’ connector at the rear of the Control Unit. Connect the other end of the Ethernet cable to an Ethernet switch, laptop, or PC. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 30: Control Unit Connections

    This allows the system to recover from a power failure. Caution! Non-approved power supplies can damage the equipment. Only use the original Bosch supplied 24 VDC power supply. Control Unit connections 6 7 8 Figure 6.2: CCSD‑CURDrear view...
  • Page 31 PC, IP camera’s and other equipment which is solely used to operate the CCS 1000 D system. Power 24V 6A 4‑pole circular female connector for connecting the 24 VDC power supply. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 32: Discussion Device Connections

    | Connections Digital Discussion System Caution! Non-approved power supplies can damage the equipment. Only use the original Bosch supplied 24 VDC power supply. Notice! The audio inputs/outputs are mono but the audio connectors allow for the connection of stereo RCA cables.

  • Page 33: Flush Devices Connections

    Trunk connection 6‑pole circular female connector to connect the next component in the daisy-chain. This can be: – Another Flush device, – An Extension unit, or – An extension cable. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 34: Extension Unit Connections

    Power 24V 6A 4‑pole circular female connector for connecting the 24 VDC power supply. Caution! Non-approved power supplies can damage the equipment. Only use the original Bosch supplied 24 VDC power supply. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 35: Configuration

    LED indicator for showing the on/off status. – Red: Power off. – Green: Power on or standby. Note: When the Control Unit is in standby, the Discussion Devices volume control LED (3) flashes slowly. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 36 Red flashing once a second: Recording paused. – Red flashing twice a second: 5 minutes of recording left. Three short beeps, from the monitor loudspeaker, will also be sounded to alert the user. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 37 USB memory stick requirements, see Additional components, page 15. Headphone socket 3.5 mm (0.14 inch) stereo headphone socket for connecting (CCSD‑CURD only) headphones (for listening to recorded discussions). When headphones are connected, the built‑in loudspeaker is muted. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 38: Discussion Modes

    The speakers list can be (viewed and) managed in the web browser interface. The waiting list is not used in this mode. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 39: Key Combinations

    When the system is reset to the factory defaults, the latest version of the software that the system was upgraded to will be maintained. Discussion Device This section describes how to configure the device. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 40: Configure Discussion Device

    Push the microphone button again. 7.2.3 Erase address Push and release the concealed initialization button (1) at the base of the discussion device: – The microphone LED indicator is red. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 41: Flush Devices

    Make sure the units that need to be de-initialized are powered through the controller. Gently push and release the button on the side of the device with a paper clip. The LED of the microphone is red. The button LED is multicolor. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 42: Extension Unit

    The web browser interface of the CCS 1000 D Digital Discussion System is used to: – upgrade the system software. – configure the CCS 1000 D Digital Discussion System. – prepare and manage discussions. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 43 – On a Windows PC/laptop, make sure: – Bosch DNS‑SD is installed. Bosch DNS‑SD is on the DVD supplied with the Control Unit and can be downloaded from the relevant product page on: www.boschsecurity.com – a dynamic IP address has been assigned to the laptop/PC. If the laptop/PC has a static IP address, the web browser interface will not work correctly.

  • Page 44: Login

    Digital Discussion System 7.5.2 Login Multiple users can log in to the CCS 1000 D system at the same time, providing they log in on separate web browsers or separate devices (tablet, laptop or PC). First time login Since version 1.7, when logging in for the first time, the user must follow a wizard to configure the system.
  • Page 45 Configuration | en Notice! Some web browser interface options may not be available for the CCSD‑CU, because this version of the Control Unit does not have DAFS and recording functionality. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 46 Control Unit and web browser interface application. See System info, page 57. System info Exits the discussion application and returns you None to the login page. See Logout, page 57. Logout 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 47 Manage meeting recording. Stop recording (CCSD‑CURD only) Opens the master volume control slider. Controls Configure or Manage the discussion devices loudspeaker and Control meeting Unit audio output level. Master volume Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 48: Manage Discussion

    – Recording and playing back discussion, page 59. Master volume control Click the master volume control button to adjust the audio output level of the Discussion Devices and Control Unit. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 49: Prepare Discussion

    Discussion Device priority button is used. – Stop all speakers and remove all waiting participants: When selected all speakers and requests are cancelled when the Discussion Device priority button is used. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 50: Manage Recorder

    Recycle bin button (Only visible when a file is selected): Deletes the selected file from the used memory and overview. Note: For more information on recording and playing back audio files, refer to Recording and playing back discussion, page 59. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 51: System Settings

    50. – Prepare meeting: This right gives access to the prepare discussion pages. Refer to Prepare discussion, page 49. – Modify users: This right gives access to the users page. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 52 A total of 6 cameras can be connected to the CCS 1000 D Digital Discussion System. Click the Cameras button to open the camera settings page. – Overview camera: Sets the camera used as the overview camera. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 53 Note: Only possible if your PC/laptop or tablet device is connected via the wired Ethernet connection of the system. Notice! Ensure that the Bosch ONVIF Camera has firmware 5.80 or higher. ONVIF cameras ONVIF cameras are automatically detected, but you still need to: Enter a username and password if the camera has a username and password configured.
  • Page 54 (x-y): x = number of Discussion Devices currently connected to the system and initialized. y = historical number of Discussion Devices connected to the system. Click one of the square icons on the left of this page to locate a Discussion Device 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 55 Click the Date and time button to open the date and time settings page. Click the Change date and time settings button to select: – Time: Select the local time. – Date: Select the current date. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 56 Refer to – Configure Discussion Device, page 40 – Manage discussion, page 48 – Manage recorder, page 50 – Initialize Discussion Device, page 40 – Prepare discussion, page 49 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 57: Power

    Link to download the Open Source Software license terms System info is used by a technician. 7.5.10 Logout Click the Logout button on the homepage to log out from the discussion application. The login page is displayed. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 58: Restful Application Program Interface (Api)

    This function gives the possibility to retrieve and set microphone sensitivity of an individual device. The sensitivity range is from -6dB to +9dB. For more information on the Application Program Interface, refer to the API manual, which can be downloaded at: https://licensing.boschsecurity.com/software 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 59: Operation

    Connect a laptop or PC to the Control Unit, by using the micro USB connector at the rear of the Control Unit.. Under the detected drive for the Control Unit, create a txt file called ‘no-file-split’. Remove the file extension “.txt.” Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 60 USB connector at the rear of the Control Unit. Notice! Recordings cannot take place when the Control Unit is connected to a PC with the micro USB connector. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 61: Using The Microphone Button

    Your request to speak is first in the waiting list. – As soon as the active speaker disables their microphone button you will be allowed to speak. – Your microphone is active; you are allowed to speak. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 62: Using The Priority Button

    Web browser interface, page 42) is sounded at the same time. The chairperson’s microphone button (2) is used to activate and deactivate the microphone as required. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 63: Adjusting Headphones Volume

    Operation | en Adjusting headphones volume Figure 8.4: Device with chairperson‘s button fitted Use the rotary thumbwheel (3) on the side of the device to adjust the volume of the headphones, when connected. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 64: Troubleshooting

    Discussion Devices. – Decrease the volume of the Control Unit loudspeaker. – Increase the distance between the Discussion Devices and/or the Control Unit. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 65 Recording to the internal Internal memory full or USB – Check internal recording memory not possible. connected. LED indicator: Red/ green flashing indicates that the internal memory is full. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 66 Connect the USB memory stick to a PC, and transfer the files to a hard disk if necessary. USB memory stick damaged. – Check the read/write possibilities of the USB stick. 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 67 – For the Kramer MV‑6 switcher, set the TCP connection port number to 5000. – For the tvOne CORIOmatrix switcher, set the TCP connection port number to 10001. Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 68: Maintenance

    Inspect components Check all CCS 1000 D Digital Discussion System components for signs of wear and tear. Replacement Discussion Devices can be ordered from your Bosch representative, if required. Check all connectors and system cabling for damage. Check the Discussion Device microphone buttons for correct operation. The buttons should not be loose or remain pressed in when operated.

  • Page 69: Technical Data

    < 0.5% Audio inputs XLR nominal microphone input -56 dBV XLR maximum microphone input -26 dBV RCA nominal input -24 dBV (+/- 6 dB) RCA maximum input +6 dBV > 93 dBA Frequency response 30 Hz to 20 kHz <0.1% Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 70: Discussion Device

    Loudspeaker max. peak output power 4 W Acoustical Loudspeaker nominal output 72 dB SPL Participants loudspeaker frequency 200 Hz to 16 kHz (acoustical) response Microphone polar pattern Cardioid Participants microphone frequency response 125 Hz to 15 kHz Microphone nominal input 85 dB SPL 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 71: Flush Devices

    Minimum signal-to-noise ratio (dBA) > 75 dBA Sample rate (kHz) 44.10 kHz Maximum number of flush discussion devices supported per trunk Acoustic Nominal acoustic output level (dB SPL) 72 dB SPL (loudspeaker) Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...
  • Page 72 Weight (lb) (with short microphone) 1.19 lb Environmental Operating temperature (°C) 0 °C – 35 °C Operating temperature (°F) 32 °F – 95 °F Storage temperature (°C) -40 °C – 70 °C 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...

  • Page 73: Extension Unit

    Pearl light grey (RAL 9022) matt-gloss Environmental Operating temperature 5 ºC to +45 ºC (+41 ºF to +113 ºF) Storage and transport temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF) Relative humidity 5% to 98% non-condensing Bosch Security Systems B.V. 2024-09 | V3.0 | System manual...

  • Page 74: Support Services And Bosch Academy

    Troubleshooting – Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2024-09 | V3.0 | Bosch Security Systems B.V. System manual...
  • Page 76 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2024 Building solutions for a better life 202409191157...
