A68(W) IP Phone User Manual
2. Factory reset via Web:
a) Key in the IP address of phone with a browser,
b) Access the webpage of phone as the role of "admin", username/password is
admin/admin.
c) Select"Phone"
d) Select"Upgrade"
e) Click the button "Reset to Factory"
f) Click the button "OK"
3. Factory reset during starting:
a) Hold the key "*" and "#" while power on for 5 seconds
b) The phone will be reboot and resumed to factory default setting
6.2、Upgrade the firmware on safe mode
If the phone can't be started successfully, user is able to upgrade the firmware on post mode,
a) Setup a TFTP Server and set the PC's IP address as "192.168.1.200"
b) Copy the firmware file we supplied to the root menu of TFTP Server, modify the file's name
as A68(W).tar.gz and decompress it, then modify the corresponding file's name as
A68(W).kn, A68(W).fs, A68(W).fw, A68(W).lg
c) Ensure the TFTP Server and phoneare connected to the same network switch and both
reachable
d) Long Press the key "*" and "1" to upgrade the kernel file, long Press the key "*" and "2" to
upgrade the firmware file, long Press the key "#" to upgrade the App file, long Press the
key "*" and "4" to upgrade the logo file, and then plug in power until "upgrading..."
displayed on LCD
e) The phone will start downloading file from TFTP server
f) After downloading completed, the phonewill be automatically upgraded
