Alpha/Numeric Displays; Cylinder Pressure/Depth Display - Oceanic Dive Computer Pro Plus 2 Operating Manual

N
2
FEET
MAX
O PSI
2
0 5 10 20
ATR
Cylinder Pressure (Fig 6a) is displayed any time the Pro Plus
2 is connected to a pressurized cylinder and in an active
operating mode.
Values of pressure are displayed numerically from 10 PSI (.5
BAR) up to 5000 PSI (352 BAR) in increments of 10 PSI (.5
BAR).
During a dive, the Current Depth display (Fig. 6b), indi-
cates depths from 0 to 330 feet (99.9 meters) in 1 foot (.1
meter) increments.
By pressing the Left (Advance) button, the Maximum
Depth reached during that dive will be displayed in the
center/left portion of the display (Fig. 6c).
During a Decompression Dive, the required Ceiling Stop
Depth is displayed in the center of the screen. Maximum
Depth can be viewed by pressing the Left (Advance) button.
