5. BIOS Setup
◆PCI Express Configuration
Configure the PCI Express bus settings.
Aptio Setup Utility - Copyright (C) 20xx American Megatrends, Inc.
Configuration
PCI Express Configuration
PCI Express Port 0
Speed
PCI Express Port 1
Speed
PCI Express Port 2
Speed
PCI Express Port 3
Speed
Figure 5.9 PCI Express Configuration
Table 5.8 PCI Express Configuration
Item
PCI Express Port 0
Speed
(PCI Express Port 0))
PCI Express Port 1
Speed
(PCI Express Port 1)
PCI Express Port 2
Speed
(PCI Express Port 2)
PCI Express Port 3
Speed
(PCI Express Port 3)
VPC-500 Series User's Manual
[Enabled]
[Auto]
[Enabled]
[Auto]
[Enabled]
[Auto]
[Enabled]
[Auto]
Version x.xx.xxxx. Copyright (C) 20xx American Megatrends, Inc.
Option
Enabled
Do not change this setting.
Disabled
Auto
Gen2
Do not change this setting.
Gen1
Enabled
Do not change this setting.
Disabled
Auto
Gen2
Do not change this setting.
Gen1
Enabled
Do not change this setting.
Disabled
Auto
Gen2
Do not change this setting.
Gen1
Enabled
Do not change this setting.
Disabled
Auto
Gen2
Do not change this setting.
Gen1
→←:Select Screen
↑↓:Select Item
Enter:Select
+/-:Change Opt.
F1:General Help
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Description
39
