Summary of Contents for Hyundai HYTR36LI
-
Page 2: Table Of Contents
CONTENTS o’s Page N Section Description 1. GETTING TO KNOW YOUR MACHINE 3 – 4 2. MACHINE PARTS 4 – 6 3. SAFETY REQUIREMENTS 6 – 7 4. SAFETY REGULATIONS 7 - 9 5. BATTERY POWERED HEDGE TRIMMER 10 – 12 6. -
Page 3: Getting To Know Your Machine
1. GETTING TO KNOW YOUR MACHINE 1.1. How to read the manual. 1.1.1. Certain paragraphs in the manual contain particularly significant information and are marked with various levels of highlighting with the following meaning: Non- observance Indicates a hazard NOTE or Non-observance Read Manual will result in the... -
Page 4: Machine Parts
1.4.1.1.5. Use of the machine by more than one person. 1.4.1.2. Improper use of the machine will invalidate the warranty, relieve the manufacturer from all liabilities, and the user will consequently be liable for all and any damage or injury to himself or others. 2. -
Page 7: Safety Requirements
3. SAFETY REQUIREMENTS. 3.1. Your machine must be used carefully. 3.1.1. Symbols have therefore been placed on various parts of the machine to remind you of the main precautions to be taken. 3.1.2. Their meaning is explained below. You are also asked to carefully read the safety regulations in the specific chapter of this manual. - Page 8 The vibration value indicated was determined with a standardized tool and can be used to make comparisons with other electric equipment as well as temporary estimates of the load through the vibrations. 4.1. General power tool safety. Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
- Page 9 4.1.4.3. Prevent unintentional starting. Ensure that the machine is switched OFF before inserting the battery, picking up or carrying the power tool. Carrying the power tool with your finger on the switch or fitting battery with the switch ON can cause accidents. 4.1.4.4.
-
Page 10: Battery Powered Hedge Trimmer
5. BATTERY POWERED GRASS/EDGE TRIMMER Cutting elements continue to rotate after motor is switched off. Wear protective glasses or goggles. The safety rules must be observed during machine use. Before starting the machine, read the instructions regarding personal safety and the safety of unauthorized persons. - Page 11 5.3.2. Do not use the machine if you are unable to hold it with both hands or keep it steady on your legs while working. 5.3.3. The machine must never be used by more than one person. 5.3.4. Never use the machine if the user is tired or unwell, or has taken medicine, drugs, alcohol or any substances which may slow the users’...
-
Page 12: Operating Instructions
5.7.1.7. Never use the battery charger in zones where flammable vapours or substances are present. 5.7.1.8. Recharge batteries at a temperature of between 10° and 40 °C only. 5.7.1.9. Never store batteries in environments with temperatures of over 40 °C. 5.7.1.10. - Page 13 6.3. Mounting the guard (Fig 2). The guard must be fitted correctly to respect the safety requirements and the correct position of the line cutting knife. IMPORTANT Once mounted, the guard should never be removed. 6.3.1. Remove the screw (1). 6.3.2.
- Page 14 6.5. Charging the battery. Check that the socket mains voltage is the same as that indicated on the battery charger plate. 6.5.1. Remove the battery from the machine, 6.5.2. To recharge the battery, 6.5.2.1. Connect the battery charger (1) to a mains power socket; a green power light (3) will come on indicating there is voltage.
- Page 15 6.7. Managing the battery. 6.7.1. The battery must be kept in environments where the temperature is not in the range of 0°C +45°C. If the machine is stored in places where the temperature could exceed those limits, please remove the battery and keep it in a suitable place. 6.7.2.
- Page 16 6.9.3. Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property. 6.9.4. Always wear suitable clothing when using the machine. Your dealer can provide you with all the information on the most suitable accident-prevention devices to guarantee your safety. 6.9.5.
- Page 17 6.10.1. The battery is fitted with a protection system which prevents it from running completely flat. 6.10.2. The power tool will automatically switch OFF when the battery is flat. If this happens, it must be promptly recharged. 6.11. Ergonomic and functional adjustments (Fig. 6). Adjustments must be made after removing the battery from its compartment.
-
Page 18: Maintenance
6.12.4. Cutting near fences/foundations 6.12.4.1. Slowly approach the cutting line head to fences, posts, rocks, walls, etc. without hitting them hard. 6.12.4.2. If the line strikes a solid object it could break or become worn; if it gets tangled in a fence it could break abruptly. -
Page 19: Troubleshooting
7.2. Motor cooling. 7.2.1. To avoid overheating and damage to the motor, always keep the cooling air vents clean and free of grass and debris. 7.3. Head coil replacement (Fig 8). 7.3.1. Press the two side buttons (1) and remove the cover (2). 7.3.2. -
Page 20: Specification
9. SPECIFICATION HYTR36Li Grass Trimmer Battery charger supply vac/hz 230/50 Battery type Samsung Lithium ion Battery voltage vdc Battery capacity Ah Charging time h Cutting width mm Line type M x mm 5 x 1.6 Net weight including battery kg... -
Page 21: Declarations Of Conformity
12. DECLARATIONS OF CONFORMITY 12.1. Genpower Ltd confirms that this Hyundai product conform to the following CE Directives; 12.1.1. 2006/42/EC Machinery Directive 12.1.2. 2004/108/EC EMC Directive 12.1.3. 2000/14/EC, Amended by 2005/88/EC (as amended)
