  • Page 1 Owner’s Operation Manual REX™ Orbi-Linear™ Trainer Before Using this product, read this manual and follow all safety rules and operating instructions.
  • Page 2 Start WARNING! Heart rate monitoring systems may be inaccurate. Over exercise may result in serious injury. If you feel faint or pain stop exercising immediately SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 3: Table Of Contents

    KEYPAD FUNCTIONS BIOMECHANICAL POSITIONING ACCESSORIES HEART RATE TRANSMITTER STRAP PROGRAM INSTRUCTIONS 11-20 MAINTENANCE & SERVICE WARRANTY 22-26 CERTIFICATIONS WARRANTY CARD Order online 24/7 at www.SCIFIT.com SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 4: Safety Information

    Never drop or insert any object into any opening. Do not use outdoors or in a harsh environment where water is present (i.e. pool or spa areas). SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 5: Introduction

    Injuries to health may result from incorrect or excessive training. Failure to stop exercising can result in injury or death to yourself. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 6: Specifications

    Within U.S. & Canada 3 years parts, 1 year labor Outside U.S. 3 years parts, no labor 73” 1854 mm 55” 1397 mm 28” 711 mm SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 7: Set-Up & Installation

    To promote a healthy environment, wipe any sweat off of unit with a commercially manufactured wipe designed for the fitness industry, or a damp cloth. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 8: Assembly

    Use Phillips screw driver to secure the console to the console mount plate with the supplied (Qty. 4) (x 4) M5 x 12mm screws. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 9: Product Overview

    Fixed or swivel seat assembly Leveling base Optional heart rate endcaps Oversized contact grips foot bed with foot Transport wheels straps (optional) on REX7000 & REX70008 SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 10: Keypad Functions

    (see Program Instructions) workout parameters. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT Quick Start: This key provides a one-touch “Quick Start” into a workout with preset parameters.

  • Page 11: Biomechanical Positioning

    When seated properly the movement should promote mild torso rotation ideal for strengthening the abdominal regions and the back. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 12: Accessories

    Transmits heart rate directly to the console during the Optional on REX7000 & REX7008. Oversized straps workouts. keep the feet secure on the foot bed Order online 24/7 at www.SCIFIT.com SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 13: Heart Rate Transmitter Strap

    180 x .60 = 108 (min MHR) These values are based upon averages, always consult your physician to establish the proper Heart rate zone for your individual health condition. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 14: Program Instructions

    Work loads and duration are preset within the Set-Up mode. 15:00 Time (mm:ss) Level Weight (lbs) Fit-Quik Press Then Enter the workout duration with keys then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 15 Adjust the target watts with keys then press Time (mm:ss) 15:00 Target Watts Weight (lbs) Enter the user weight with keys then press to begin the workout. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 16 Target RPM Time (mm:ss) 15:00 Weight (lbs) Level Adjust the target RPM with keys Select 1 of 7 profiles with keys then press then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 17 Enter the user weight Target Heart Rate with keys then press Weight (lbs) to begin the workout. Enter the workout duration with keys then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 18 Stess Test First Target (Watts) with keys then press Stress Test Increments (Watts) Stress Test Interval (mm:ss) 5:00 to begin the workout. Select target wattage with keys then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 19 Select a random profile with keys to begin the workout. then press Profile Random Time (mm:ss) 15:00 Level Enter the workout duration with keys then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 20 TEST Press Then Program to begin workout Level Beginner Weight (lbs) Enter the user weight with keys then press to begin the workout. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 21 Level Beginner Weight (lbs) Program Weight (lbs) Select 1 of 4 levels with keys Select 1 of 3 programs with keys then press then press SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 22 This duration can be increased or decreased in the “Set-up” mode. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 23 Press either the [Up] or [Down] arrow keys to Utilization (Hours) 0.00 “Enable” or “Disable” the feature, then press the LCD Dimming ENABLED [Quick Start] key to save. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 24: Maintenance & Service

    Every 6 Mo. Club Maintenance CAUTION Contact your local waste management agency for specific requirements concerning recycling and disposal locations of batteries. Order online 24/ 7 at www.SCIFIT.com SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 25: Warranty

    FITNESS FOR PARTICULAR PURPOSE, AND IS IN LIEU OF ALL OTHER LIABILITIES OF SCIFIT INCLUDING DIRECT, INDIRECT, SPECIAL AND CONSEQUENTIAL DAMAGES OR PENALTIES EXPRESSED OR IMPLIED WHETHER ARISING OUT OF CONTRACT, NEGLIGENCE OR OTHER SORT. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 26 12 months Assist gloves 90 days USB keys and Lanyards 90 days (f) Fires, floods, and acts of God, are not covered under this warranty SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 27 TO SIGNING”. Shipping and Installation SCIFIT is not responsible for the repair or replacement of any unit or part damaged during transit or installation. The customer is responsible for inspection of each unit and part for damage for shipping damage at the time of installation. If the customer signs an unqualified receipt for freight or damage goods, the customer is solely responsible for the cost of the repair or replacement for such freight damage.
  • Page 28 The customer will have the option to request overnight or 2nd day parts shipping, but will be charged the difference between the ground shipment cost and the overnight or 2nd day cost. SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...
  • Page 29 Thank you in advance for your assistance! When requested by SCIFIT, defective parts must be returned to the SCIFIT factory within 20 days of receipt of replacement part. Otherwise SCIFIT will expect payment on the parts invoice net 30 days.

  • Page 30: Certifications

                             SCIFIT • Scientific Solutions for Fitness • SCIFIT • Scientific Solutions for Fitness • SCIFIT...

  • Page 31: Warranty Card

    SCIFIT SCIFIT SCIFIT SCIFIT...
  • Page 33 Important: Please keep this page for “Recalibration records” Model Number: Serial Number: Date of Purchase: Calibration Date Medical Units: Supplied By: SCIFIT Systems Inc. User Manual: #P4765C (9/2012) CLUB OR TECH DATE CERTIFICATION LOCATION CERTIFIED SERVICE COMPANY INITIALS Recalibration Recalibration...
