- Page 1 Curved Glass Stainless Steel LAM2502 LAM2503 Chimney Extractor User & Installation Guide...
- Page 2 LAMONA Appliances Dear Customer, Congratulations on your choice of a LAMONA domestic appliance which has been designed to give you excellent service. The user manual will help you use your product quickly and safely. • Please read this user manual before installing and using the product.
-
Page 3: Table Of Contents
User manual LAM2502 LAM2503 Index Before using the extractor Safety General Safety for children Safety when working with electricity General information and operation Extractor layout Control panel layout Care and maintenance General Cleaning Grease Filters Carbon Filters Replacing the Lamps... -
Page 4: Before Using The Extractor
LAMONA Appliances Before using the Extractor • Make sure that you have removed all packaging, wrappings, stickers and films from the Extractor • It is recommended that you clean the extractor’s surface before using for the first time. Safety • Keep all ventilation slots clear of obstructions, This appliance is for domestic extraction as this may cause premature failure of the purposes only. It must not be used for other appliance purposes. -
Page 5: General Information And Operation
User manual LAM2502 LAM2503 General Information & operation Extractor layout Upper chimney section Recirculation vent Lower chimney section Fan and light controls Extractor body Grease filters Light Glass Canopy Control panel layout Extractor Power off Extractor power level 1 Extractor power level 2... -
Page 6: Care And Maintenance
LAMONA Appliances Care and maintenance Before cleaning or attempting any type of maintenance, always make sure that the electricity supply is disconnected. To avoid the possibility of fire, adhere strictly to all of the recommendations included in this booklet, paying particular attention to the grease filters to ensure grease deposits do not build up. -
Page 7: Carbon Filters
User manual LAM2502 LAM2503 The Carbon Filters Carbon filters have a limited life. We advise you to change them when there is a noticeable drop in performance. The intervals between changing the filter will depend entirely upon the amount of cooking you do, but on average they will last about 6 months. Please quote the part refrence number HJA2911 (pack of 2) when re-ordering. • To gain access to the carbon filters, first of all remove the grease filters as above. • Remove the old filters and install new charcoal filters by turning them gently Replacing the Lamps The extractor hood is fitted with x2 G4w halogen lamps that may need to be replaced periodically. To do this, ensure that the power is switched off and the lamps have had time to cool. -
Page 8: Installation
LAMONA Appliances Installation Methods of Extraction The very best method of clearing the kitchen of unwanted odours is by connecting the appliance to an exhaust duct and venting to the outside atmosphere via the ceiling or an exterior wall. (Suitable ducting kits may be purchased from the depot where you bought the extractor.) You do not need charcoal filters when... -
Page 9: Parts Identification
User manual LAM2502 LAM2503 PARTS IDENTIFICATION On opening your box you will find the extractor body, a two-piece telescopic decorative chimney, a bag of wall fixings and screws, two fixing brackets, a ducting connector and reducer. Main Extractor Body Extractor Body Bracket Lower Chimney Outlet Reducer Upper Chimney Rawl Plug Upper Chimney bracket 30mm Screw Lower Chimney Bracket 10. 10mm Screw Exclusive to Howdens Joinery.co Page _ 9... -
Page 10: Hanging Your Extractor
LAMONA Appliances Hanging Your Extractor This instruction must be strictly adhered to. Failure to comply could result in overheating and serious damage to your appliance. It is recommended that the installation is carried out by two people. Before drilling or chiselling the ceiling or wall, check for pipes and power cables. -
Page 11: Decorative Chimney Fitting
User manual LAM2502 LAM2503 Decorative Chimney Fitting Connect the extractor to the electricity supply (see electrical connections page). We recommend an isolation switch that is accessible after installation. The outlet reducer ‘7’ maybe required depending on your ducting kit (supplied separately). -
Page 12: Electrical Connections
LAMONA Appliances Electrical Connections IMPORTANT: Ensure that the electricity supply is switched off before connecting. Your appliance must be connected to fixed wiring via the use of a double pole switched fused spur outlet with at least 3mm contact separation, The isolation switch must be accessible after installation. (See technical data for fuse rating). We strongly recommend the appliance is connected by a qualified electrician The terminology DOUBLE POLE -/+ means that both the live and neutral supplies are switched and disconnected at the same time. -
Page 13: Technical Specification
User manual LAM2502 LAM2503 Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions Lamps fail to operate? • A replacement lamp is probably Disconnect the mains electricity supply before adjusting necessary, but first check that the or replacing the lamps. lamp is correctly fitted into its holder. The extractor lamps may become hot; therefore ensure (Remember that the lamps are not the bulb has cooled sufficiently before replacing. -
Page 14: Your Guarantee
LAMONA Appliances Your guarantee Product Guarantee Details (UK only) Your appliance has the benefit of a comprehensive manufacturer’s guarantee which covers the cost of breakdown repairs. (Details of which are shown on your Proof of Purchase Document). • Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE) •... -
Page 15: Exclusive To Howdens Joinery.co
User manual LAM2502 LAM2503 Notes Exclusive to Howdens Joinery.co Page _ 15... - Page 16 If supplied, please stick your self adhesive product rating plate here, or make a note of the product serial number below in the box below for future reference. Serial Number : ...................
