- Page 1 Flat Glass Chimney Extractor LAM2550 User Guide www.howdens.com/appliance-registration...
- Page 2 See back page for product serial number...
- Page 3 LAMONA Appliances Dear Customer, Congratulations on your choice of a LAMONA domestic appliance. The user manual will help you use your product quickly and safely. • Please read this user manual before installing and using the product. • Always follow the safety instructions.
-
Page 4: Table Of Contents
User manual LAM2550 Index Before Using the Extractor Safety General Safety for Children c i r y t i General Information and Operation Control Panel Layout Care and Maintenance General Cleaning Grease Filters Carbon Filters Replacing the Lamps Installation Methods of Extraction... -
Page 5: Before Using The Extractor
LAMONA Appliances Before Using the Extractor • Make sure that you have removed all packaging, wrappings, stickers and films from the extractor. • It is recommended that you clean the extractor’s surface before using for the time. Safety • Keep all ventilation slots clear of obstructions,... -
Page 6: General Information And Operation
User manual LAM2550 General Information & operation Upper Chimney Section Recirculation Vent Lower Chimney Section Fan and Light Controls Extractor Body Grease Filters Light Glass Canopy Control Panel Layout Extractor Power off Extractor Power Level 1 Extractor Power Level 2... -
Page 7: Care And Maintenance
LAMONA Appliances Care and Maintenance Before cleaning or attempting any type of maintenance, always make sure that the electricity supply is disconnected. The manufacturer declines all liability in cases where the instructions for the appropriate installation, maintenance and use of the extractor hood are not observed. -
Page 8: Carbon Filters
User manual LAM2550 The Carbon Filters Carbon have a limited life. We advise you to change them when there is a noticeable drop in performance. The intervals between changing will depend entirely upon the amount of cooking you do, but on average they will last about 6 months. -
Page 9: Installation
LAMONA Appliances Installation Methods of Extraction The very best method of clearing the kitchen of unwanted odours is by connecting the appliance to an exhaust duct and venting to the outside atmosphere via the ceiling or an exterior wall. Suitable Ducting kits part ref: APL2805/6/7 may be purchased from the depot where you bought the extractor. - Page 10 User manual LAM2550 Parts Identification On opening your box you will the extractor body, a two-piece telescopic decorative chimney, a bag of wall and screws, two brackets, a ducting connector and reducer. The glass for this extractor will be packed separately .
-
Page 11: Hanging Your Extractor
LAMONA Appliances Hanging Your Extractor This instruction must be strictly adhered to. Failure to comply could result in overheating and serious damage to your appliance. It is recommended that the installation is carried out by two people. Before drilling or chiselling the ceiling or wall, check for pipes and power cables. - Page 12 User manual LAM2550 • Remove the grease before trying to install. • The recommended height for the hood is 750mm above the worktop. This can be reduced to a minimum of 700mm if required. • Mark and drill the holes required to mount the extractor body.
-
Page 13: Decorative Chimney Fitting
LAMONA Appliances Decorative Chimney and Glass Fitting DO NOT: Operate the extractor Position. (**) Please use rawl plugs and screws appropriate to the type of wall (not supplied) 700 mm Minimum distance to worktop 750 mm Recommended distance to worktop Fitting the Glass •... -
Page 14: Electrical Connections
User manual LAM2550 Electrical Connections IMPORTANT: Ensure that the electricity supply is switched off before connecting. Your appliance must be connected to wiring via the use of a double pole switched fused spur outlet with at least 3mm contact separation. The isolation switch must be accessible after installation. (See technical data for fuse rating). -
Page 15: Troubleshooting
LAMONA Appliances Troubleshooting TROUBLESHOOTING GUIDE Symptoms Possible Cause Solutions • Motor temp has exceeded and • Switch off the extractor and allow it to cool down Light functions but fan thermal fuse has tripped. and the fuse will auto reset. -
Page 16: Your Guarantee
Call the Depot number on your Proof of Purchase Document supplied with the product / kitchen. Call the LAMONA Service Line on 0344 460 0006 * Product installed within a domestic kitchen or non-domestic kitchen where 8 or fewer people are using the appliance. - Page 18 Product serial number (Place sticker here) Issue v1 290518...
