eForce 150 User Log
Installation Date
Location User Name
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
February 2012
Door Description
Code Notes
24 80-0180-262 Rev. D
In programming mode, press the [*] key at any time to exit this mode. Wait
2 seconds before entering any code. The red LED will flash and a tone will
indicate that the programming mode has been exited.
The programming mode will exit automatically if an invalid code is entered
during programming (indicated by a red LED flash and a tone). The pro-
gramming mode can be reinitiated by pressing the [#] key.
®
The eForce 150 will always return to the standard user mode after the
programming mode is exited.

User Code Descriptions:

Note: In user mode, entries must be followed by the [*] key
Master Code:
The default Master code setting (1234) must be changed before program-
ming additional user codes. In addition to using this code to program Emer-
gency and Supervisor codes, the Master code can be used to unlock the
device. The code must be between 4 and 7 digits.
Emergency Code:
The default Emergency code setting (4321) must also be changed prior to
®
programming the eForce 150 features and codes, though it is not used in
®
programming the eForce 150. This code unlocks the device in all condi-
tions, including a low battery condition or "blackout". It will open the
®
eForce 150 for the preset time (10 sec. default). The code must be be-
tween 4 and 7 digits.
Supervisor Code:
The Supervisor code has no preset default, so it must be programmed by
the user if needed. It is used to unlock the eForce
battery conditions. It allows for programming every code except the Master
code, and is also required to delete codes. Normal and One Time user
codes (6-152) may be entirely deleted or partially deleted in a block . The
Emergency, Lockout, and Passage codes may be deleted singly rendering
these functions completely non-operational (they will not return to default
once deleted). The Supervisor code must be between 4 and 7 digits.
Lockout Code:
The Lockout code is used to restrict Normal User codes (6-152) from gain-
ing access. Entry of Lockout Mode is indicated by a green LED flash and
two tones, with a pause followed by two additional tones. Only the Master,
Emergency, and Supervisor codes can override the Lockout code. Entering
the Lockout code a second time will cancel the Lockout and allow access
with Normal User codes. Exit of Lockout Mode is indicated by a green LED
flash and two tones. The Lockout code must be between 4 and 7 digits.
80-0180-262 Rev. D
®
150, even under low
5 February 2012
