PN# 500-10420
Rev. A.5, 8/03
SECURITRON 32, 34, 62 AND 82 SERIES MAGNALOCK
TABLE OF CONTENTS AND GUIDE TO THIS MANUAL
There are numerous Magnalock versions and numerous different applications exist for them.
Accordingly, this manual provides a broad range of information- only a portion of which is
applicable to any individual use. This manual guide provides a brief summary of many of the
Sections which allows you to consult only the portions of the manual that apply to your
application.
SECTION 1. DESCRIPTION --------------------------------------------------------------------Page 1
SECTION 2. PHYSICAL INSTALLATION ---------------------------------------------------Page 1
This is the largest part of the manual with sections that explain the different types of physical
installations which vary according to door or gate types as well as Magnalock versions.
SECTION 2.1 SURVEY ---------------------------------------------------------------------------Page 1
This section concerns how to pre-plan the installation.
SECTION 2.2 INSTALLATION TOOL KIT --------------------------------------------------Page 1
This section explains an available accessory.
SECTION 2.3.1 STRIKE PLATE MOUNTING ----------------------------------------------Page 1
SECTION 2.3.2 MOUNTING THE MAGNET------------------------------------------------Page 3
The above three sections explain the most common Magnalock installation on a door that
swings away from the lock. They also include general mounting instructions and should
therefore be read for all installations.
This section explains installation of "F" type Magnalocks on inswinging doors.
The following seven sections provide specific advice depending on door type which includes
recommended bracketry.
SECTION 2.5.3 SOLID GLASS DOOR MOUNTING -------------------------------------Page 8
SECTION 2.5.4 DOUBLE DOOR MOUNTING ---------------------------------------------Page 10
SECTION 2.5.5 DM-62 DOUBLE 62 LOCK-------------------------------------------------Page 10
This section, which includes three drawings, covers outdoor use of the Magnalock on a
variety of gate types.
SECTION 2.7 USE OF DRESS COVERS ---------------------------------------------------Page 13
This section introduces the Dress Cover which is used after physical mounting to improve
installation appearance and tamper resistance.
SECTION 2.8 TAMPER PROOFING THE MAGNALOCK ------------------------------Page 14
This section should be read for any installation in a high vandalism area.
© Copyright, 2003, all rights reserved • Securitron Magnalock Corp., 550 Vista Blvd., Sparks NV 89434, USA
Tel: (775) 355-5625 • (800) MAGLOCK • Fax: (775) 355-5636 • Website: www.securitron.com
An ASSA ABLOY Group company
